StarTech.com MPEX1394B3 Manual de usuario
Manual Revision: 05/12/2020
User Manual
For the latest information and specications visit
www.startech.com/MPEX1394B3
Mini PCI Express FireWire Adapter Card
Actual product may vary from photos
SKU#: MPEX1394B3
1
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Compliance Statements
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorientorrelocatethereceivingantenna
• Increasetheseparationbetweentheequipmentandreceiver
• Connecttheequipmentintoanoutletonacircuitdierentfromthatto
whichthereceiverisconnected
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du
Canada.
CAN ICES-3 (B)/NMB-3(B)
Use of Trademarks, Registered Trademarks, and other
Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and
other protected names and/or symbols of third-party companies not related in
any way to StarTech.com. Where they occur these references are for illustrative
purposes only and do not represent an endorsement of a product or service
by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com
hereby acknowledges that all trademarks, registered trademarks, service marks,
and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.
2
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Safety Statements
Safety Measures
• Wiringterminationsshouldnotbemadewiththeproductand/or
electriclinesunderpower.
• Cables(includingpowerandchargingcables)shouldbeplacedand
routedtoavoidcreatingelectric,trippingorsafetyhazards.
Mesures de sécurité
• Lesterminaisonsdecâblâgenedoiventpasêtreeectuéeslorsquele
produitet/oulescâblesélectriquessontsoustension.
• Lescâbles(ycomprislescâblesd’alimentationetdechargement)
doiventêtreplacésetacheminésdefaçonàévitertoutrisque
électrique,dechuteoudesécurité
安全対策
• 電源が入っている状態の製品または電線の終端処理を行わないでくださ
い。
• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し
を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう
にしてください。
Misure di sicurezza
• Iterminialideilielettricinondevonoessererealizzateconilprodotto
e/olelineeelettrichesottotensione.
• Icavi(inclusiicavidialimentazioneediricarica)devonoessere
posizionatiestesiinmododaevitarepericolidiinciampo,rischidi
scosseelettricheopericoliperlasicurezza.
Säkerhetsåtgärder
• Monteringavkabelavslutningarfårintegörasnärproduktenoch/eller
elledningarnaärströmförda.
• Kablar(inklusiveelkablarochladdningskablar)skadrasochplaceraspå
såsättattriskförsnubblingsolyckorochandraolyckorkanundvikas.
3
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Table of Contents
Compliance Statements........................................................................1
Safety Statements..................................................................................2
Product Diagram ....................................................................................4
Product Information ..............................................................................5
Package Contents ..................................................................................................................................... 5
Requirements ............................................................................................................................................. 5
Installation ..............................................................................................6
Hardware Installation .............................................................................................................................. 6
Driver Installation ..................................................................................7
Specications..........................................................................................7
4
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Diagram
Components Description
1LP4 Power Connector • Connects to the System
Power Supply to power
the Mini Adapter Card.
2Mini PCIe Adapter Card • Designed for use in
small form factor
computer systems (e.g.
Mini-ITX).
39-Pin FireWire 800
Connectors
• Connect Peripherals to
the Mini Adapter Card.
46-Pin FireWire 400
Connector
• Connect a Peripheral to
the Mini Adapter Card.
123
4
5
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Information
Package Contents
• Mini PCI Express FireWire card x 1
• Internal Data Cable x 1
• 4-pin LP4 Adapter Cable x 1
• Full Prole Installation Bracket x 1
• Video Editing Software CD x 1
• User Manual x 1
Requirements
• PCI Express enabled system with available full length Mini PCI
Express slot.
• Case/Chassis with available Low or Full prole expansion card
slot.
Operating System
• Windows® 2000, XP, Vista, 7, 8, 8.1, or 10
• Windows Server® 2003, 2008 R2, 2012, or 2016
• Mac OS® 10.6 to 10.12
• Linux 3.5.x to 4.4.x LTS Versions Only
Tools
• Small Phillips® Head Screwdriver
6
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Hardware Installation
Installing the Full Prole Bracket
By default the Low Prole Bracket is attached to the Mini
Adapter Card. Depending on your system conguration you
may need to remove the Low Prole Bracket and replace it
with the Full Prole Bracket (included).
1. Using a Small Phillips Head Screwdriver (sold separately),
remove the two Bracket Screws securing the Low Prole
Bracket to the Mini Adapter Card.
2. Align the Screw Holes on the Mini Adapter Card with the
Screw Holes on the Low Prole Bracket. Making sure the
Mini Adapter Card is sitting on top of the Screw Holes on
the Full Prole Bracket.
3. Insert the Bracket Screws through the Mini Adapter Card
and into the Screw Holes on the Full Prole Bracket.
4. Using the Small Phillips Head Screwdriver, tighten the
Bracket Screws, being careful not to over-tighten.
7
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Installing the Mini Adapter Card
Warning! Mini Adapter Cards, like all computer equipment,
can be severely damaged by static electricity. Be sure that
you are properly grounded before opening your computer
case or touching the Mini Adapter Card. StarTech.com recom-
mends that you wear an anti-static strap when installing any
computer component. If an anti-static strap is unavailable,
discharge yourself of any static electricity build-up by touch-
ing a large grounded metal surface (such as the computer
case) for several seconds. Handle the Mini Adapter Card by its
edges and not the gold connectors.
1. Turn o the Host Computer and disconnect any Peripheral
Devices that are connected (e.g. printer, external hard drives,
etc.).
2. Unplug the Power Cable from the back of the Host
Computer.
3. Remove the Cover from the Host Computer’s Case.
Note: Consult the documentation that came with the Host
Computer for details about how to remove the Cover safely.
4. Align the PCIe Connector Gap on the Mini Adapter Card
with the notch on the Mini PCI Express slot on the Host
Computer’s Mother Board.
5. Gently insert the Mini Adapter Card (mini card) into a Mini
PCI Express Slot on the Host Computer’s Mother Board.
6. Securely fasten the Mini Adapter Card to the Host
Computer’s Motherboard.
8
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Note: Dierent systems may have dierent methods for
installing Mini Adapter Cards, so please refer to documen-
tation for your system/board for more specic installation
instructions for your particular application.
7. Connect the LP4 Power Connector on the Mini Adapter
Card to an LP4 connector on the System Power Supply.
8. Locate an open Expansion Card Slot (e.g. PCI, PCI Express,
etc.) and remove the Metal Cover Plate on the rear of the
Host Computer’s Case/Chassis.
9. Place the expansion card bracket from the Mini Adapter
Card in the opening and fasten the card’s bracket to the rear
of the case.
10. Place the Cover back onto the Computer Case.
11. Reconnect the Power Cable to the back of the Computer.
12. Reconnect all of the Peripheral Devices that were
disconnected in step 1.
13. Connect Peripheral Devices to the FireWire Connectors on
the Mini Adapter Card.
Driver Installation
No driver or software installation is required for supported
operating systems, as this card is natively supported.
9
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Specications
Host Interface • PCI Express Mini Card
revision 1.2
Form Factor
• Full Length Mini PCIe
• Full/Low Prole Card
Bracket
Supported Standards • IEEE 1394b / 1394-2002 /
1394-1995
Chipset ID • Texas Instruments -
XIO2213B
External Connectors • 2 x 9-pin FireWire female
• 1 x 6-pin FireWire female
Internal Connectors • 1 x LP4 Power male
Maximum Data
Transfer Rate
• FireWire800: 800 Mbps
• FireWire400: 400 Mbps
Operating Temperature • 0°C ~ 70°C (32°F ~ 158°F)
Storage Temperature • -54°C ~ 150°C (-65°F ~
302°F)
