CMVBMOD
Cable Manager
*actual product may vary from photos
Instruction manual
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
PHILLIPS® is a registered trademark of Phillips Screw Company in the United States or other
countries.
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction manual
i
Table of Contents
Product diagram ....................................................................................1
Application photo..................................................................................................................................... 1
Product dimensions...............................................................................2
Package contents ...................................................................................3
Requirements .........................................................................................3
Install the cable manager .....................................................................3
Technical support...................................................................................4
Warranty information............................................................................4
Instruction manual
1
Product diagram
Mounting plate
Cable channel
(4 per segment)
Weighted base
Application photo
Cable slot
(4 per segment)
Instruction manual
2
Product dimensions
18 mm
36 mm
68 mm
34 mm
53 mm
29 mm
20.1 mm
1290 mm
70 mm
109.5 mm
129 mm
Instruction manual
3
Package contents
• 1 x cable manager (ships unassembled)
• 2 x M5x20 mm screws
• 1 x quick-start guide
Requirements
• Phillips type screwdriver
Requirements are subject to change. For the latest requirements, please visit
www.StarTech.com/CMVBMOD.
Install the cable manager
1. To attach the weighted base, select one of the segments without the mounting
plate and connect it to the weighted base.
2. Connect the other segment without the mounting plate to the segment you
connected to the weighted base.
3. Connect the remaining segment to the middle segment.
4. If you want to insert your cables before you attach the cable organizer to the desk,
thread the cables through any of the four channels in the cable organizer.
5. Position the mounting plate on the underside of a desk or table in a location that is
suitable for your setup.
6. Insert the two M5x20 mm screws through the holes in the desk attachment and into
the desk, and use a Phillips type screwdriver to tighten the screws in place.
7. To insert your cables, do one of the following:
• At the top of the cable organizer, thread the cables through any of the four
channels in the cable organizer and out the bottom of the weighted base.
• Snap the cables into any of the cable slots in each of the segments in the cable
organizer.
Instruction manual
4
Technical support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty information
This product is backed by a ve-year warranty.
StarTech.com warrants its products against defects in materials and workmanship
for the periods noted, following the initial date of purchase. During this period,
the products may be returned for repair, or replacement with equivalent
products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need. From
the latest technology to legacy products — and all the parts that bridge the old and
new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they need
to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to
the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products and
to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology
parts. StarTech.com was founded in 1985 and has operations in the United States,
Canada, the United Kingdom and Taiwan servicing a worldwide market.
