StarTech.com 35FCREADREM Manual

7-in-1 Portable Card Reader/Writer

with 2 USB 2.0 Ports

35FCREADREM

Instruction Guide

The Professionals’ Source For Hard-to-Find Computer Parts

USB 22.0 FFLASH CARD

READER

* Actual product may vary from photo

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Using Your Card Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Introduction

Thank you for purchasing a StarTech.com 3.5” bay multi-panel. This multi-purpose panel

fits into an open 3.5” bay and provides you two convenient USB 2.0 ports as well as an

ejectable 7-in-1 flash card reader. The 35FCREADREM works with CompactFlash

memory cards, IBM-Microdrives, SmartMedia memory cards, Memory Stick cards,

MemoryStick Pro cards, SecureDigital memory cards, and Multi-Media cards. The

ejectable card reader plugs into any USB port and uses no external power source, letting

you transport your cards between computers and laptops safely and easily. The interface

makes it easy to transfer files, images, and music between your computer and your MP3

player, digital camera, cell phone, or PDA.

Features

•Supports seven different types of flash cards: CompactFlash memory cards, IBM-

Microdrives, SmartMedia memory cards, Memory Stick cards, MemoryStick Pro

cards, SecureDigital memory cards, and Multi-Media cards

•Allows easy card transport with ejectable card reader

•Powered by USB bus, no external power source is needed

•Supports drag and drop between cards

•Reads and writes any files suited for PC or Mac computers

•Fits into any 3.5” drive bay

•Provides two front USB 2.0 ports

•Backed by StarTech.com’s one-year warranty

Before You Begin

To ensure a quick and easy installation, please read through this section carefully before

attempting to install the multi-panel.

WARNING! Flash cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer case or

touching your card. StarTech.com recommends that you wear an anti-static strap when

installing any computer component. If an anti-static strap is unavailable, discharge

yourself of any static electricity build-up by touching a large grounded metal surface

(such as the computer case) for several seconds.

System Requirements

•Windows 98SE (or higher) with a Pentium-class (or compatible) processor, or Mac OS

X with a Power PC (or above).

•An open USB port

•ACD drive

Contents

This package should contain:

•1x ejectable 7-in-1 card reader with 3.5” drive bracket

•1x motherboard connection cable

•1x rear bracket cover

•1x driver disk

Installation

This section will guide you through the installation of your multi panel and the related

software. Please read through the instructions carefully and complete each step in the

order listed.

Depending on your OS and the configuration of your system, the instructions below may

not be identical to what you see on your screen.

Installing the Panel

1. Make sure that your system is unplugged and you are grounded.

2. Remove the cover of your system and remove the cover from a 3.5” drive bay (see

your computer's user manual for details, if necessary).

3. Gently insert the panel into the open 3.5” bay (after threading the attached USB cable

into the computer) until it is flush with the front of the case. Make sure the bracket is

lined up with the screwholes in the case, and screw the panel into place.

4. Thread the attached USB cable out the back of your computer and plug it into a USB

port. You can use the metal rear bracket cover to hold the cable in place. Just screw

the bracket cover into an open I/O bracket on the rear of your computer.

Note: If you want to use the front USB 2.0 ports on the panel, you will need to use the

motherboard connection cable. If you do not want to use the front ports, you can skip

ahead to step 7.

5. Connect the single end of the connection cable to the pins on the multi panel. The

connectors are constructed so that it is difficult to connect the cable incorrectly.

6. Connect the other end of the cable to your motherboard’s USB connectors. The pins

on the cable come in two groups of four wires. The connectors on the cable are:

Note: The location and layout of your motherboard’s

USB connectors depend on your motherboard

manufacturer. The improper connection of wires to the

motherboard can result in damage to the motherboard

and/or your 35FCREADREM. Make sure you consult

your motherboard manufacturer if you are unsure of

the layout of your motherboard.

Connector Color

Data + Green

GND Black

Data - White

VCC Red

7. Put your case’s cover back on and power on your computer.

8. Your computer will display a message saying new hardware has been found.

Windows 98SE and 2000 users Follow the onscreen prompts and direct Windows to

the appropriate folder on the driver disk. Windows will install the necessary drivers.

Follow any on-screen prompts to complete the installation.

Using Your Card Reader

The LEDs on the card reader are your best indication of the reader’s activity.

•The solid Power LED indicates that the card reader is powered.

• A flashing Access LED indicates that there is data being transferred to or from the

card.

Inserting a Card

1. Turn on your computer.

2. Insert your memory card into the proper slot on the card reader.

3. Mac users: A new icon will appear on your desktop.

Windows users: A new icon will appear in “My Computer.”

4. The card can now be accessed as an extra disk.

Removing a Card

1. Make sure that none of the LEDs on the front of the card reader are flashing. If you

remove the card when the LEDs are flashing, data may be lost from your card.

2. Mac users should drag the memory card icon to the Trash bin.

Windows users should right-click on the drive icon and choose to eject the card.

3. Physically remove the card from the reader.

Using the Reader With the Bracket

To insert the reader into the bracket, slide the reader into the bracket until it clicks into

place. Press the button on the front of the bracket to release the ejectable card reader.

Using the Reader Without the Bracket

You can plug the ejectable card reader directly into your computer’s USB port or into a

USB hub.

1. With your PC turned off, plug the card reader into a free USB port. Turn on your

computer.

2. A message will be displayed saying that new hardware has been found. Windows

will automatically install the necessary drivers.

3. When the installation is complete, there will be four new “Removable Disk” icons

visible in “My Computer.”

Removing the Card Reader

Use this procedure to permanently uninstall the card reader.

Windows users

1. Make sure there is no card reader connected to the USB port.

2. Click on the “Uninstaller” icon in the taskbar.

3. Click on “USB Storage Device - Change/Remove.”

4. Remove all installed components and click Next.

5. Choose to restart your computer and click Finish.

Mac users

1. If there is a memory card connected to the card reader, drag the memory card icon

into the Trash. Wait until the icon has disappeared.

2. Disconnect the card reader.

Troubleshooting

The card reader is not detected.

The reader has not been properly connected or is not receiving enough power. Make sure

that the reader’s USB cable is firmly seated in the USB port. If you are connecting the

card reader to a hub, make sure that it is a powered hub.

The card doesn’t fit in the reader.

Make sure you are installing the card in the proper slot and that the card is facing the

right direction. Check with the card manufacturer’s instructions.

Adrive letter is shown for the card, but it can’t be accessed.

The card has not been formatted or is formatted incorrectly. Follow the instructions

provided by the manufacturer of your digital media device (i.e., your MP3 player, digital

camera, etc.) to format the card using your digital media device.

No icon appears when a card is inserted into the reader (Mac OS X).

The card may have been formatted in Windows’ FAT-32 format. Using a PC or digital

device, re-format the card using the OS X-compatible FAT or FAT-16 format.

Technical Specifications

USB Ports 2 x 4 pin USB (Type A)

Standards USB 2.0

Data Transfer Rate USB 2.0 devices: Up to 480 Mbits/sec

USB 1.1 devices: Up to 12 Mbits/sec

Flash Cards: 700 Kbits/sec to 480 Mbits/sec

Compatibility: Compact Flash I & II Card

IBM Micro Drive

Smart Media Card

Secure Digital Card

Multi-Media Card

Memory Stick

MS Pro Card

LED Indicators Power & Activity

System Requirement An available 3.5” bay

98SE/2000/ME/XP or Mac OS X

Technical Support

The following technical resources are available for this StarTech.com product:

On-line help:

We are constantly adding new information to the Tech Support section of our web site. To

access this page, click the Tech Support link on our homepage, www.startech.com. In the

tech support section there are a number of options that can provide assistance with this

product.

Knowledge Base - This tool allows you to search for answers to common issues using

key words that describe the product and your issue.

FAQ - This tool provides quick answers to the top questions asked by our customers.

Downloads - This selection takes you to our driver download page where you can

find the latest drivers for this product.

Call StarTech.com tech support for help:

USA/Canada: 1-519-455-4931

UK/Ireland/Europe: 00-800-7827-8324

Support hours: Monday to Friday 9:00AM to 5:00PM EST (except holidays)

Warranty Information

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted,

following the initial date of purchase. During this period, the products may be

returned for repair, or replacement with equivalent products at our discretion. The

warranty covers parts and labor costs only. StarTech.com does not warrant its products

from defects or damages arising from misuse, abuse, alteration, or normal wear and

tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the actual

price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Otros manuales para 35FCREADREM

Tabla de contenidos

Otros manuales de Lector de tarjetas de StarTech.com

StarTech.com

StarTech.com HB30A4AIB Manual de usuario

StarTech.com

StarTech.com 35BAYCF2IDE Manual de usuario

StarTech.com

StarTech.com 35FCREAD20 Manual de usuario

StarTech.com

StarTech.com SDMSDRWU3AC Manual de usuario

StarTech.com

StarTech.com 35FCREAD Manual del sistema

StarTech.com

StarTech.com 52535FCREADB Manual de usuario

StarTech.com

StarTech.com 2SD4FCRU3 Manual de usuario

StarTech.com

StarTech.com 35FCREADBK2 Manual de usuario

StarTech.com

StarTech.com FCREADMICRO Manual de usuario

StarTech.com

StarTech.com 35FCREADBK3 Manual de usuario

StarTech.com

StarTech.com MSDREADU3C Manual de usuario

StarTech.com

StarTech.com FCREADU3HC Manual de usuario

StarTech.com

StarTech.com FCREADU2OTGB Manual de usuario

StarTech.com

StarTech.com FCREADHCU3 Manual de usuario

StarTech.com

StarTech.com SDMSDRWU3AC Manual de usuario

StarTech.com

StarTech.com FCREADHC Manual de usuario

StarTech.com

StarTech.com 35FCREADREM Manual del sistema

StarTech.com

StarTech.com 525FCREAD Manual

StarTech.com

StarTech.com 525FCREADREM Manual del sistema

StarTech.com

StarTech.com 525FCREADAL Manual del sistema

StarTech.com

StarTech.com HB30A4AIB Manual de usuario

StarTech.com

StarTech.com 2SD4FCRU3C Manual de usuario

StarTech.com

StarTech.com 52535FCREADB Manual del sistema

StarTech.com

StarTech.com 2SD4FCRU3C Manual de usuario

Manuales populares de Lector de tarjetas de otras marcas

Lindy

Lindy 43185 Manual de usuario

Lindy

Lindy 43185 Manual de usuario

ViziT

ViziT RD-4F Manual de usuario

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Manual de usuario

AVID ID

AVID ID AVID1043 Manual de usuario

Conrad

Conrad PCMCIA Manual de usuario

Rosslare

Rosslare DR-6255 Manual de usuario

Lindy

Lindy 51541 Manual de usuario

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Manual de usuario

Johnson Controls

Johnson Controls Kantech tyco ioSmart Manual de usuario

ACS

ACS ACR122L Manual de usuario

Secukey

Secukey S2-MF Manual de usuario

Elecom

Elecom MR-SMC07 series Manual de usuario

Alien

Alien ALR-9800 Manual de usuario

ACS

ACS ACR310 Manual de usuario

Datamars

Datamars R-IN1300 MID Manual de usuario

Alarm Lock

Alarm Lock AL-PRE2 Manual de usuario

xpr

xpr B100PROX-AH Guía del usuario
