StarTech.com USB300WN2X2D Manual del sistema

USB 802.11N Dual Band Wireless Network Adapter – 300 Mbps High Power 2T2R Wi-Fi 2.4/5GHz

StarTech ID: USB300WN2X2D

The USB300WN2X2D dual-band Wireless-N USB Network Adapter allows a USB-enabled computer to connect

to a WiFi network on the 2.4GHz or 5GHz frequency. The adapter can be used for connecting to Wireless-A, B, G

or N networks, and features dual 5dBi high gain antennas, as well as powered amplifiers to ensure optimized

reception capable of supporting up to 300Mbps of data bandwidth over distances up to 3 times greater than a

standard WiFi adapter.

This versatile dual band network adapter features a 2T2R (2 transmitter, 2 receiver), Multiple Input/Multiple

Output (MIMO) design, and can connect to older wireless access points (that may only operate on a 2.4GHz

frequeny), as well as newer WAPs that support the less congested 5 GHz range.

Backed by a StarTech.com 2-year warranty, with free lifetime technical support, the USB300WN2X2D is

designed to provide a dependable, long-lasting wireless access solution

Applications

Connect to a WiFi network while on the go, from a laptop

Replace or upgrade the wireless capabilities of a desktop or laptop computer

Access a nearby wireless network from an outdoor location

Connect to a 5 GHz WiFi network, which will not receive interference from common wireless devices, such

as as cordless phones

Connect to WiFi networks in areas with lots of obstructions or near the maximum range of the WiFi access

point

Connect a computer to a network, where cables cannot be used, such as outdoors

intrl.startech.com

Features

2 Transmitter/2 Receiver (2x2:2) antenna configuration, with MIMO support

2.4/5 GHz dual band frequency support

Dual detachable 5dBi dual band antennas

Compliant with IEEE 802.11n standard, with transfer rates up to 300Mbps

Backward compatible with IEEE 802.11b/g standards, for up to 11/54Mbps connections respectively

Supported security features: WEP (64-128-bit), WPA and WPA2

Support for WMM/WMM-PS Quality of Service (QoS)

Powered directly from single or dual USB ports

Includes a monitor clip for mounting to the back of a laptop display

intrl.startech.com

Technical Specifications

Warranty 2 Years

Bus Type USB 2.0

Chipset ID Ralink RT3572L

Interface USB 2.0

Antenna

Configuration

2x2:2 (TxR:S)

Industry Standards IEEE 802.11b, IEEE 802.11g, IEEE802.11n

Connector Type(s) 1 - USB Mini-B (5 pin) Female

Connector Type(s) 2 - RP-SMA (Coax; Reverse Polarity SubMiniature A) Female

Bandwidth 20/40 MHz

Frequency 2.4/5.0 GHz

Supported Protocols CSMA/CA

Type and Rate USB 2.0 - 480 Mbit/s

Security Features TKIP/AES

Security Features WEP Data Encryption

Security Features WPA Data Encryption

OS Compatibility Windows XP (32/64-bit)/ Server 2003 (32/64-bit)/ Server 2008 R2/ Vista (32/64-bit)/ 7

(32/64-bit)/ 8 (32/64-bit)

Linux kernel 2.6.32 or later

Color Black

Enclosure Type Plastic

Product Height 0.7 in [18 mm]

Product Length 3.5 in [88 mm]

Product Weight 1.2 oz [35 g]

Product Width 2.2 in [56 mm]

LED Indicators 1 - Link/Activity

Power Adapter

Included

USB Powered

Humidity 10% ~ 90% RH

Operating

Temperature

0°C to 60°C (32°F to 140°F)

Storage Temperature -20°C to 70°C (-4°F to 158°F)

Package Quantity 1

Shipping (Package)

Weight

6.9 oz [195 g]

intrl.startech.com

Included in Package 1 - USB WiFi Adapter

Included in Package 1 - Mini USB Y Cable

Included in Package 2 - Dual Band Antenna

Included in Package 1 - Monitor Clip

Included in Package 1 - Driver CD

Included in Package 1 - Instruction Manual

Certifications, Reports and Compatibility

intrl.startech.com
