StarTech.com PEX867WAC22 Manual de usuario

Manual Revision: 05/08/2020

User Manual

For the latest information and specications visit

www.startech.com/PEX867WAC22

PCI Express to AC1200 Wireless-AC

Network Card

Actual product may vary from photos

SKU#: PEX867WAC22

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdi󱐯erentfromthatto

whichthereceiverisconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003

du Canada. This device complies with Industry Canada licence-exempt RSS

standard(s). Operation is subject to the following two conditions: (1) This device

may not cause interference, and (2) This device must accept any interference,

including interference that may cause undesired operation of the device.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Le présent appareil est conforme aux CNR d’Industrie Canada applicables

aux appareils radio exempts de licence. L’exploitation est autorisée aux deux

conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2)

l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

IC Radiation Exposure Statement:

This equipment complies with IC RSS-102 radiation exposure limit set forth for

an uncontrolled environment. This equipment should be installed and operated

with minimum distance 20cm between the radiator and your body.

Déclaration d’exposition à la radiation:

Cet équipement respecte les limites d’exposition aux rayonnements IC dénies

pour un environnement non contrôlé. Cet équipement doit être installé et mis

en marche à une distance minimale de 20 cm qui sépare l’élément rayonnant de

votre corps.

L’émetteur ne doit ni être utilisé avec une autre antenne ou un autre émetteur ni

se trouver à leur proximité.

FCC ID:VYTLP-9094

IC:11232A-PEX867WAC22

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiringterminationsshouldnotbemadewiththeproductand/or

electriclinesunderpower.

• Cables(includingpowerandchargingcables)shouldbeplacedand

routedtoavoidcreatingelectric,trippingorsafetyhazards.

Mesures de sécurité

• Lesterminaisonsdecâblâgenedoiventpasêtree󱐯ectuéeslorsquele

produitet/oulescâblesélectriquessontsoustension.

• Lescâbles(ycomprislescâblesd’alimentationetdechargement)

doiventêtreplacésetacheminésdefaçonàévitertoutrisque

électrique,dechuteoudesécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• Iterminialideilielettricinondevonoessererealizzateconilprodotto

e/olelineeelettrichesottotensione.

• Icavi(inclusiicavidialimentazioneediricarica)devonoessere

posizionatiestesiinmododaevitarepericolidiinciampo,rischidi

scosseelettricheopericoliperlasicurezza.

Säkerhetsåtgärder

• Monteringavkabelavslutningarfårintegörasnärproduktenoch/eller

elledningarnaärströmförda.

• Kablar(inklusiveelkablarochladdningskablar)skadrasochplaceraspå

såsättattriskförsnubblingsolyckorochandraolyckorkanundvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................3

Product Diagram ....................................................................................5

Product Information ..............................................................................6

Package Contents ..................................................................................................................................... 6

Requirements ............................................................................................................................................. 6

Hardware Installation............................................................................7

Installing the Low Prole Bracket........................................................................................................ 7

Hardware Installation .............................................................................................................................. 8

Attaching the Dual Band Antennas.................................................................................................... 9

Downloading the Driver......................................................................................................................... 9

Verifying Installation................................................................................................................................ 10

Operation ................................................................................................10

Specications..........................................................................................11

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Component Description

1LED Indicator • Flashing: Indicates

activity 2.4 to 5GHz.

2Antenna Connectors • Used to connect the

5 dBi Dual Band

Antennas to the

Network Card.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

3PCIe Connector • Connects the Network

Card to the PCI Express

Slot on the Host

Computer.

Product Information

Package Contents

• PCI Express Wireless-AC Card x 1

• 5 dBi Dual Band Antennas x 2

• Antenna Stand x 1

• Low Prole Bracket x 1

• User Manual x 1

Requirements

For the latest requirements, please visit www.startech.com/

PEX867WAC22

• Computer with an available PCI Express® slot (x4, x8, or x16)

Tools

• Small Phillips® Head Screwdriver

• Windows® 8, 7, Vista, or XP

• Windows Server® 2012, 2008 R2, or 2003

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Hardware Installation

Installing the Low Prole Bracket

By default the Full Prole Bracket is attached to the Network

Card. Depending on your system conguration you may need

to remove the Full Prole Bracket and replace it with the Low

Prole Bracket (included).

1. Using a Small Phillips Head Screwdriver (sold separately),

remove the two Bracket Screws securing the Full Prole

Bracket to the Network Card.

2. Align the Screw Holes on the Network Card with the Screw

Holes on the Low Prole Bracket. Making sure the Network

Card is sitting on top of the Screw Holes on the Low Prole

Bracket.

3. Insert the Bracket Screws through the Network Card and

into the Screw Holes on the Low Prole Bracket.

4. Using the Small Phillips Head Screwdriver, tighten the

Bracket Screws, being careful not to over-tighten.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Hardware Installation

Warning: Network cards can be damaged by static elec-

tricity. Make sure that you are properly grounded before

you open the computer case or touch the Network Card.

You should wear an anti-static strap when you install any

computer components. If an anti-static strap is not available,

discharge any built-up static electricity by touching a large

grounded metal surface for several seconds. Only handle

the Network Card by its edges and do not touch the gold

connectors.

1. Turn o the Computer and disconnect any Peripheral

Devices that are connected (e.g. printers, external hard

drives, etc.).

2. Unplug the Power Cable from the back of the Computer.

3. Remove the Cover from the Computer Case.

Note: Consult the documentation that came with the Com-

puter for details on how to remove the cover safely.

4. Locate an open PCI Express Slot (x4, x8, or x16) and remove

the corresponding Metal Cover Plate from the back of the

Computer Case.

5. Gently insert the Network Card into the open PCI Express

Slot and fasten the Bracket to the back of the Computer

Case.

6. (Optional) Connect a 15 Pin SATA Power Connector from

the Power Supply to the SATA Power Connector on the

Network Card.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

7. Place the Cover back onto the Computer Case.

8. Reconnect all of the Peripheral Devices that were

disconnected in step 1.

9. Place the Cover back onto the Computer Case.

10. Reconnect the Power Cable to the back of the Computer.

Attaching the Dual Band Antennas

1. Screw the 5 dBi Dual Band Antennas onto the Antenna

Connectors on the sides of the Antenna Stand.

2. Screw the Antenna Cables on the Antenna Stand to the

Antenna Connectors on the Network Card.

- or -

3. Screw the 5 dBi Dual Band Antennas directly to the

Antenna Connectors on the Network Card.

Downloading the Driver

When the Network Card is installed the drivers should install

automatically. If the drivers do not automatically install,

navigate to www.startech.com/PEX867WAC22 to download

the appropriate driver package.

1. Click on the Support tab, under Drivers, select the

appropriate driver package for the Operating System

running on the Host Computer.

2. When you have downloaded and unzipped the driver. Click

on the Installation Guide PDF and follow the instructions.

Otros manuales para PEX867WAC22

Tabla de contenidos

Otros manuales de Adaptador de StarTech.com

StarTech.com

StarTech.com ESATAPLT2M Manual del sistema

StarTech.com

StarTech.com TB2USB3GE Manual de usuario

StarTech.com

StarTech.com USB External Sound Card Adapter Manual de usuario

StarTech.com

StarTech.com 8STUSB312SAT3CB Manual de usuario

StarTech.com

StarTech.com ICUSB232SM3 Manual de usuario

StarTech.com

StarTech.com USB31GEVG Manual de usuario

StarTech.com

StarTech.com ICUSB2321F Manual de usuario

StarTech.com

StarTech.com USB32000SPT Manual de usuario

StarTech.com

StarTech.com ST2000PEXPSE Manual del sistema

StarTech.com

StarTech.com US1GA30SFP Manual de usuario

StarTech.com

StarTech.com CDP2HD4K60SA Manual de usuario

StarTech.com

StarTech.com DP2VGDVHD Manual de usuario

StarTech.com

StarTech.com PEX433WAC11 Manual de usuario

StarTech.com

StarTech.com Thunderbolt TB3DKM2DPL Manual de usuario

StarTech.com

StarTech.com ECESATUSB1 Manual de usuario

StarTech.com

StarTech.com USB32HD2 Manual de usuario

StarTech.com

StarTech.com S322SAT3R Manual de usuario

StarTech.com

StarTech.com USB2DVIE3 Manual de usuario

StarTech.com

StarTech.com PCI330USB2 Manual de usuario

StarTech.com

StarTech.com 8ST102BUSBCMULTIP Manual de usuario

StarTech.com

StarTech.com ICUSB2321X Manual de usuario

StarTech.com

StarTech.com USB32VGAPRO Manual de usuario

StarTech.com

StarTech.com MDVIDVIMF Manual de usuario

StarTech.com

StarTech.com USB2VGAPRO2 Manual de usuario

Manuales populares de Adaptador de otras marcas

PCB Piezotronics

PCB Piezotronics 090B274 Manual de usuario

Auvidea

Auvidea J20 Manual del producto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manual de usuario

Akribis

Akribis ITF-21-BISS-MIT Manual de usuario

Tenda

Tenda W54U Manual de usuario

ROHO

ROHO AGILITY Manual de usuario

PROLiNK

PROLiNK WN2001 Manual de usuario

Hawking

Hawking HUF2 Manual de usuario

Airlink101

Airlink101 AWLC4030 Manual de usuario

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manual de usuario

Philips

Philips SWA4554S/10 Manual de usuario

JVC

JVC TS-C9D2B Manual de instrucciones

NETGEAR

NETGEAR A6100 Manual de usuario

D-Link

D-Link DWA-121 Manual de usuario

Philips

Philips SWA2037 Manual de usuario

Basalte

Basalte 0610-20 Manual de usuario

Yealink

Yealink EHS40 Manual de usuario

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manual de usuario
