MN2580W Access Point Specifications (subject to change without notice)
MN2580W
MoCA 2.5 Access Point with 802.11ac Wi-Fi and TV Extension
MN2580W has one-year Limited Hardware Warranty and 90-day free software updates after purchase. This Limited Warranty Statement gives the customer specific
legal rights. The customer may also have other rights which vary from State to State in the United States, from province to province in Canada, and from country to country
elsewhere in the world. To the extent that this Limited Warranty Statement shall be deemed modified to be consistent with such local law. Under such local law, certain
disclaimers and limitations of this Warranty Statement may not apply to the customer.
MoCA Configuration (Optional)
Connect the LAN1 port of the Access Point and the Ethernet port of a
computer with an Ethernet cable.
Power on the Adapter.
Configure the IP address of the computer to be 192.168.144.100.
Launch the Web browser from the computer and type
http://192.168.144.200 to login with
user name: admin, password: maxlinear
On the (Maxlinear) Web management pages of theAdapter, current
configurations and operational status, such as frequency range,
transmission rate, IP address and otherAdapter information can be
changed and reviewed.
Warranty
Frequency Range
Dimension W x D x H
Weight
LED
Connectors
Temperature
Opera�ng/Storage Humidity
FCC Cer�ficate
RoHS
MTBF
AFR in Con�nuous Opera�on
Rough Handling Shock
Non-Condensing; Altude < 2000 m
Operaon 20% to 85%; Storage 5% to 95% non-condensing
CISPR PUB. 22, FCC Part 15 Subpart B
RoHS 2.0 Standard 2011/65/EU, Amendment 2015/863/EU
> 300,000 hours Telcordia SR-332
7.1" x 5.1" x 1.2" (180 mm x 130 mm x 30 mm)
Operang 22°F to 113°F (0°C to 40°C)
Storage -4°F to 185°F (-20°C to 60°C)
LAN 1 - LAN 4 (Link/Acvity green), Coax (MoCA green)
Wi-Fi 2.4 GHz (green), Wi-Fi 5 GHz (green)
DC Input, 4 x 1000Base-T RJ 45, MoCA 75F, TV 75F, MPS Paring
VLANs, 802.11p, IGMP v1/2/3, 128-bit AES Encrypon
Web Based Conguraon via 1000Base-T Connecon
100 - 240 VAC, 50/60 Hz; 12 VDC, max. 1A, 1.3 mm PSU Wall Plug
4 x 1000 Base-T MDI/MDIX, 802.11 a/b/g/n/ac
Radio Frequency Diplexer/ TV
Maxlinear MXL3710; 32 Mbit SPI Flash
1125 MHz to 1675 MHz Congurable Extended D Band
+7dBm; 5 x 100MHz Channels
Low Pass: 5 MHz to 1002 MHz
High Pass: 1125 MHz to 1675 MHz
Low Pass: 14 dB, High Pass: 12 dB Relave to 75
Low Pass: -2 dB, High Pass: -2.5 dB
2.4 GHz 2x2 MIMO 802.11n; max. speed 300 Mbps
5 GHz 2x2 MIMO 802.11ac; max. speed 867 Mbps
ecurity
odula�on
peed
WPA-PSK/WPA-PSK2 Encrypon
Wireless Access Control (Blacklist vs. Whitelist)
SSID Hiding
Smart Unauthorized Access Prevenon
802.11b: DSSS - DBPSK (1 Mbps), DQPSK (2 Mbps), CCK (5.5/11
Mbps)
802.11 a/g: OFDM - BPSK (6/9 Mbps), QPSK (12/18 Mbps), 16QAM
(24/36 Mbps)
802.11n: MIMO-OFDM - BPSK, QPSK, 16QAM, 64QAM; Rate Set -
MCS0 o MCS15
802.11ac: MIMO-OFDM - BPSK, QPSK, 16QAM, 64 QAM, 256QAM;
Rate Set - MCS0 to MCS9 (2 streams)
Wi-Fi Access Point Configuration
Locate the default 2.4GHz and 5GHz SSIDs and password label on the unit.
For example
2.4G SSID mt7603e-1234
5G SSID mt7612e-1234
password 1234567890
Power on the Access Point.
Use a computer or smart device to join any SSID of the Access Point.
Launch the Web Browser from the computer or smart device and type
http://192.168.1.1 to login with
user name: root, password: root.
On the (MediaTek) Web management pages of theAccess Point, following
settings can be changed and reviewed.
Status Firewall (IPv4 and IPv6), Overview, Route, Realtime Graphs,
Process, Kernal
System Administration, Firmware/Software, LED, Scheduled Task,
Startup, System
Network DHCP & DNS, Firewall, Interface, Wi-Fi, QoS, Static Route,
Switch. Diagnostics
