rotate check the camera has matching
resistor or not
install resistor for the fast dome
camera
the distance between control
keyboard and speed dome is too
far
Using twisted-pair RS485 line or
overstriking RS485 cable
non-standard operation power off and restart
7. Housing cleaning
A. To ensure clear image, users should clean the housing cover regularly .When clean it
please wear glove to avoid being scratched, your sweat may erode the housing cover .
B. Use dry cloth to clean the inside and outside of the housing cover .
C. Please use neutral detergent to get rid of the solidity on the housing cover .
8. Speed dome Maintenance
A. Check speed dome power supply regularly to avoid plug is not in the socket.
B. Make sure voltage of the speed dome and monitor center is stable.
C. Mark the speed dome located in low position , remind unprofessional persons not to
touch it .
D. Ask professional persons to manage all the monitor equipments, unprofessional staff are
forbidden to operate the equipments.
E. Make monitor equipments power off at night if no person watch the equipment.
Annex ：prevent lightning strike
This product adopts the TVS board prevent lightning technical，Can effective prevent a
variety of pulse signals that the power lower than 1.5KW,like the instantaneous lightning
strike、surge etc damage the camera.but, For the outdoor installation should be according
the actual situation, on the assumption that under the guarantee the safety of electric do
the necessary protective measures: (attached photo)
A keep at least 50 meter distances between Signal transmission lines or equipment
and high voltage power cables
B Outdoor wiring try to choose to walk along the roof line
C For open spaces should adopt the seal steel pipe buried cable,and for steel pipe
adopt one point earthing, Absolutely forbidden to adopt an aerial wiring
D In the Thunderstorms region or high voltage area（such as substation ）, Must take
an extra large prevent ray equipment and install lightning rod etc,the line of the prevent
thunder and the grounding design must be full consider combine with the building, and
meet the requirements of national and industry standards.
E system should be equipotential grounding,grounding equipment should be meet dual
requests of system anti-interference and electrical safety, and can’t shorted or mixed up
with the zero line of strong power system,when system grounding alone, grounding
impedance<=4Ω,grounding line Cross-Section should be <=25mm2
