SF-HC25C3HeightController
4
2.Overview
2.1Technicalfeatures
SF-HC25C3plasma cuttingtorchheightcontrollerisaftermany yearsof
practiceandseveralgenerationsofrelatedproductsintoplay.
Thisproductadoptsthe32-bitarmasthecore, twogroupsofthree digitaltube
display, adoptsdigitalcontrol mode.Donotcontain linearadjustmentdevice
internal,greatly improvingthestability.
Velocity parameterscanbemodified, accordingtotheliftingmechanism with
powersupply and any modification.
Circuitadoptsthetechnology ofthepatch. Thereisnotinternaladjustment
device,full digitalcontroltechnologytoensurethattheproducthashigh
reliability.
Operation simple, twogroupsofdigitaltubedisplay settingarcvoltageandthe
arcpressurerespectively,conciseand straightforward. Settingparameters
operatingintotalofthree knobs.
Interfacesimply andcontrol convenient, itsuitableforall plasma cutting
numericalcontrol system,canalso beusedalone.
Itadoptstheproximity switchinitialalignmentmethod.
PWMoutput, speedadjustableoflevel255, control ofmotorspeedprecise,
severalcurrentsetting, shortcircuitprotection.
Cuttingwiththefunction ofcollision. Whencutlipstouchthesteelplate,the
controllercanquickly cutraisea certain distance, effectiveprotection ofnozzle.
All inputand outputadoptphotoelectricisolation, plasma voltagefeedback using
linearphotoelectricisolated, independentpowersupply,canverygood
compatibility withthepartialpressureofvariousbrandsofimportedplasma
powersupply.
