Stacey i3 Livelink Manual de usuario
Instruction Manual
2
3
Contents
Safety Information Page 4
Visual Guide Page 5
Installing iButton Reader Panel Page 6
Installing Recoilers Page 7
Setting up the i3 Alarm Unit Page 9
Calibration Page 9
Attaching MultiSensors Page 12
Arming the alarm Page 14
Resetting the alarm after activation Page 15
Adding User iButton Keys Page 16
Removing User iButton Keys Page 17
Remerchandising Page 18
Removing MultiSensors Page 19
Fault Finding Page 20
Daily Maintenance Checks Page 20
iButton Reader Display Messages Page 21
Technical Specications Page 22
4
Safety Information
· Use the power supply and lead supplied for this product.
· Use correct fuse.
· Do not remove cover.
· If you use this product in a manner other than that specied, the safety of
this product may be impaired.
· Use this product in a warm, dry place free from excess moisture.
· Do not obstruct the ventilation openings. Keep the product well
ventilated with a minimum 10cm space all around.
· This product will become warm when used for a long period of time. This
is normal and does not indicate a problem.
RISK OF ELECTRIC SHOCK
Caution: To reduce the risk of electric shock do not remove the cover
from this product. There are no user serviceable parts. Refer servicing to
qualied persons.
The crossed out wheeled bin symbol means that within the European
Union, this product must be taken to a separate collection point for
recycling at this product’s end of life. This product, or any other product
bearing this mark, must not be disposed of in general waste.
5
Visual Guide
www.stacey-europe.com
Mains power socketDIP SwitchesNot used
RS232 and Aux
Used to connect i3 Livelink
to Live InfoCentre
Alarm PortsiButton Reader Socket
iButton earth
connector
i3 Livelink Alarm Unit
iButton Reader Panel
iButton Reader
Program Button
iButton Reader Display iButton Earth Lead
iButton Ribbon Cable
Ventilation
Holes
Ventilation Holes
6
Installing iButton Reader Panel
www.stacey-europe.com
www.stacey-europe.com
> Cut a rectangular hole 57mm x 42mm where you wish to position the
iButton Reader Panel.
57mm
42mm
> Feed the cables through the hole, and slot the panel into place.
> Fix the iButton Reader Panel using two screws through the holes located in the
back plate. These are accessed by lifting the aps on either side of the reader
face.
> Remove the backing from the aps to expose the adhesive.
> Stick the aps to the backing plate to cover the xing screws. Hold the aps in
place for a few seconds to allow the adhesive to set.
7
Installing Recoilers
> Drill a hole 22mm diameter where the Recoiler and Cradle are to be positioned
> Drill a pilot hole 3mm in diameter 33.5mm below the centre of the Recoiler hole.
> Tie a loose knot in the retractable wire.
> Unscrew the Recoiler insert and slide apart.
> Thread Recoiler cable from behind the display, through the large hole. Holding
the cable, push the neck of the Recoiler into the hole until it is rmly in
place. Do not let go of the cable.
If using an alternative Display Option (e.g LivePost or Cable Cartridge) follow the separate installation
instructions as supplied with the Display Option, and move on to the next section of this manual.
33.5mm
Ø 22mm
Ø 3mm
8
Installing Recoilers
> Thread the cable through the Cradle, and align Cradle with hole and engage the
peg of the Cradle into the pilot hole.
> Reassemble two halves of Recoiler insert over the Recoiler cable so that the
cable goes through the centre of the
completed insert.
> Screw the insert in to the neck of the Recoiler. Tighten with a Recoiler spanner
until the Cradle and Recoiler are held in place.
> Untie the knot and allow the cable to retract.
9
Setting up the i3 Alarm Unit
> Connect the mains lead plug to the mains socket on
the alarm unit.
Before commencing please ensure that NO plugs or leads are inserted into alarm box.
When positioning the i3 Alarm Unit, make sure the ventilation holes are unobstructed, and there is at
least 10cm of space all around the unit to allow for air ow.
> Connect the iButton Ribbon Cable and the iButton
earth lead to the alarm unit.
> Position the switches on the DIP switch as follows:
1,2,3,4 in the down position
5,6 in the up position
www.stacey-europe.com
> Press and hold the Program button on the iButton Reader panel. At the
same time turn on the mains power.
Calibration
10
Setting up the i3 Alarm Unit
www.stacey-europe.com
> The unit will chirp 5 times when the power is connected. When the chirps have sounded,
release the Program button.
> The iButton Reader display will now show E.
> Disconnect the power
> Position all of the DIP switches in the up position.
> After 5 seconds reconnect the power.
> The unit is now calibrated. You will only need to carry out the proceedure during the rst installation
> Disconnect the power to continue the installation.
