ST X-NUCLEO-STMODA1 Manual de usuario

Version 1.0 (Apr 20, 2018)

Quick Start Guide

STMod+ connector expansion board for STM32 Nucleo

(X-NUCLEO-STMODA1)

Quick Start Guide Contents 2

X-NUCLEO-STMODA1: STMod+ connector expansion board for STM32

Nucleo

Hardware overview

Setup & Demo Examples

Documents & Related Resources

STM32 Open Development Environment: Overview

Arduino UNO R3 connector

Bipolar stepper motor driver expansion board

Hardware overview 3

X-NUCLEO-STMODA1 Hardware Description

•The X-NUCLEO-STMODA1 is a passive

adaptation board between Arduino Uno and

STMod+ connectors.

•It provides an easy-to-use solution for expanding

the Arduino UNO based ST ecosystem with

devices using STMod+ connector.

•The X-NUCLEO-STMODA1 includes a

comprehensive set of jumpers that allows to

modify the way the connector mapping is

operated, allowing to be compatible with a wider

range of STM32 Nucleo board.

•Since fully passive, no software is associated.

STMod+ connector

Key Products on board

STMod+ connector

Connector used by the Cellular modem Latest info available at www.st.com

X-NUCLEO-STMODA1

Quick Start Guide Contents 4

X-NUCLEO-STMODA1: STMod+ connector expansion board for STM32

Nucleo

Hardware and Software overview

Setup & Demo Examples

Documents & Related Resources

STM32 Open Development Environment: Overview

•1x Discovery kit IoT node, low-power wireless, BLE, NFC, SubGHz, Wi-Fi

(B-L475E-IOT01)

•1x STMod+ connector expansion board for STM32 Nucleo

(X-NUCLEO-STMODA1)

•1x Cellular STMod+ modem with its antenna

(modem used in P-L496G-CELL02)

•1x LTE Antenna (Taoglas TG.08.0113)

•1x Laptop/PC with MS Windows 7 or 8

•1x external DC power supply with two electric cables (*)

•1x USB type Ato micro-B USB cable

B-L475E-IOT01

Setup & demo examples

Hardware prerequisites 5

Micro USB Cable X-NUCLEO-STMODA1

Cellular STMod+ modem LTE Antenna

Setup & demo examples

Software prerequisites

•STSW-LINK009: ST-LINK/V2-1 USB driver

•STSW-LINK007: ST-LINK/V2-1 firmware upgrade

•A Windows PC with one of the supported development toolchains:

- KEIL: MDK-ARM

- IAR: EWARM

- GCC-based IDE: System Workbench for STM32

•Software package for the full cellular kit not yet available

Assembling the cellular dev-kit 7

1Stack the X-NUCLEO-STMODA1 to the B-L475E-IOT01. Verify that jumper setting that

match their default value (set for B-L475E-IOT01), looking at the X-NUCLEO-STMODA1

User manual or look at following slide

Example of use of the X-NUCLEO-STMODA1 adaptation shield

2Connect the modem using the STMod+ connector to the X-NUCLEO-STMODA1, and

connect the LTE antenna using the SMA connector.

3Connect Micro-USB cable using the connector on the B-L475E-IOT01 on the left the

closest to the modem and the USB-A to the PC

Jumper Default Setting 8

JP1

1-2 LEFT JP9 ON

JP2

1-2 LEFT JP10 OFF

JP3

1-2 DOWN JP11 ON

JP4

1-2 DOWN JP12 OFF

JP5

1-2 DOWN JP13 ON

JP6

ON JP14 ON

JP7

ON JP15 ON

JP8

OFF

JP6

JP8

JP13

JP11

JP7

JP9

JP10

JP12

JP3 JP4 JP5

JP1 JP2

JP14

JP15

Documents & related resources

X-NUCLEO-STMODA1

•Gerber files, BOM, and schematics

•DB3589 :STMod+ connector expansion board for STM32 Nucleo - data brief

•UM2400:Getting started with the X-NUCLEO-STMODA1 expansion board for STM32 Nucleo –User Manual

All documents are available in the DESIGN tab of the related products webpage

Consult www.st.com for the complete list

Quick Start Guide Contents 10

X-NUCLEO-STMODA1: STMod+ connector expansion board for STM32

Nucleo

Hardware and Software overview

Setup & Demo Examples

Documents & Related Resources

STM32 Open Development Environment: Overview
