Introduction

The X-NUCLEO-OUT08A1 industrial digital output expansion board for STM32 Nucleo provides a powerful and flexible

evaluation and development environment for 2 A (typ.) digital output modules, featuring the safe driving and smart diagnostic

capabilities of the IPS160HF single high-side switch.

The X-NUCLEO-OUT08A1 interfaces with the microcontroller on the STM32 Nucleo via 3 kV optocouplers driven by GPIO pins

and Arduino™ UNO R3 (default configuration) and ST morpho (optional, not mounted) connectors.

The expansion board should be connected to either a NUCLEO-F401RE or NUCLEO-G431RB development board, and can

also be stacked with another X-NUCLEO-OUT08A1 or X-NUCLEO-OUT10A1.

Two X-NUCLEO-OUT08A1 expansion boards allows you to evaluate a dual channel digital output module with 2 A (typ.)

capability each, or a 2 A (typ.) single channel safety digital output module. In the second scenario, the first shield output is

connected to the supply of the second one. Dedicated on-board hardware can be enabled or disabled to activate fast discharge

of high capacitive loads, output voltage sensing and additional surge pulse output line protection.

Figure 1. X-NUCLEO-OUT08A1 expansion board

Getting started with X-NUCLEO-OUT08A1 industrial digital output expansion

board for STM32Nucleo

UM2715

User manual

UM2715 - Rev 1 - June 2020

For further information contact your local STMicroelectronics sales office.

www.st.com

1Getting started

1.1 Overview

The X-NUCLEO-OUT08A1 industrial digital output expansion board, embedding the IPS160HF intelligent power

switch (IPS), is designed to meet the application requirement in terms of galvanic isolation between user interface

(or logic side) and power interface (or process side).

This requirement is satisfied by an optical isolation implemented through two couples of optocouplers:

1. The first couple includes:

a. ISO1: for signal forwarding to the device

and

b. ISO2: for diagnostic signal (DIAG pin) feedback

2. The second couple incudes:

a. ISO3: for the additional output voltage feedback signal

and

b. ISO4: for the additional circuitry driving Q1 to allow fast discharge of the output rail

The main features of the X-NUCLEO-OUT08A1 expansion board are:

• Based on IPS160HF single high-side switch, which features:

– Operation up to 60 V/2.4 A

– Low power dissipation (RON(MAX) = 120 mΩ)

– Fast decay for inductive loads

– Open load detection and diagnostics

– Overload and overheating protections with thermal shut-down and cut-off

– PowerSSO-12L package

• Application board operating range: 12 to 33 V/0 to 2.4 A

• Extended voltage operating range (J1 open) up to 60 V

• Status and diagnostic LEDs

• 3 kV galvanic isolation

• Supply rail reverse polarity protection

• Ready for Safety Digital Output Architecture

• EMC compliance with IEC61000-4-2, IEC61000-4-3, IEC61000-4-5

• Wide application development potential in STM32 Nucleo development environment

• Equipped with Arduino™ UNO R3 connectors

• CE certified

• RoHS and China RoHS compliant

1.1.1 Digital section

The digital section is associated with the STM32 interface and digital supply voltage to and from the X-NUCLEO-

OUT08A1 expansion board.

The digital and power sections are isolated by 3.3 mm creepage. Communication between the two sections is

guaranteed by ISO1, ISO2, ISO3 and ISO4 optocouplers.

UM2715

Getting started

UM2715 - Rev 1 page 2/15

Figure 2. X-NUCLEO-OUT08A1 expansion board: digital interface components

The four Arduino® UNO R3 connectors:

• allow expansion board communication with the STM32 Nucleo development board accessing STM32

peripheral and GPIO resources;

• provide digital supply voltage between the STM32 Nucleo development board and the X-NUCLEO-

OUT08A1 expansion board, in either direction.

Normally, the STM32 Nucleo development board supplies the expansion board by 3v3 or 5v0 (JP5 pins 1-2

closed) generated by the USB. You can select the preferred voltage on the expansion board via SW2 (3v3 by

closing pins 1-2; 5v0 by closing pins 2-3).

Alternatively, it is possible to supply the STM32 Nucleo development board by the expansion board. In this case,

an external supply voltage (7-12 V) should be connected to CN2 connector (not mounted by default) on the

expansion board and the ground loop should be closed by mounting D2 (that enables reverse polarity protection)

or by closing J3 (without reverse polarity).

To supply the VIN voltage rail is necessary to:

• close jumper JP5 between pins 2 and 3 and open jumper JP1 on the NUCLEO-F401RE

• open jumper JP5 between pins 1 and 2 and close jumper JP5 between pins 3 and 4 on the NUCLEO-

G431RB

1.1.2 Power section

The power section involves the power supply voltage (CN1, pin 1 VCC, pin 2 GND), load connection (between

CN1 pin 3 and CN1 pin 2) and electromagnetic compatibility (EMC) protection (U2).

UM2715

Overview

UM2715 - Rev 1 page 3/15

Figure 3. X-NUCLEO-OUT08A1 expansion board: power stage components

For EMC:

• the transient voltage suppressor (U2), enabled by closing J1, is placed between VCC and GND tracks to

protect the IPS160HF against surge discharge on the supply rail path up to ±1 kV/2Ω coupling;

• in common mode surge testing, two single-layer capacitors (C1 and C2 - not included) must be soledered at

the predisposed locations;

• the IPS160HF output stages do not require additional EMC protections with respect to IEC61000-4-2 (± 10

kV contact, ±16 kV air), IEC61000-4-4 (± 4 kV), IEC61000-4-5 (± 3.5 kV) standards.

1.2 Hardware requirements

The X-NUCLEO-OUT08A1 expansion board is designed to be used with the NUCLEO-F401RE or NUCLEO-

G431RB STM32 Nucleo development boards.

To function correctly, the X-NUCLEO-OUT08A1 must be plugged onto the matching Arduino® UNO R3 connector

pins on the STM32 Nucleo board as shown below.

UM2715

Hardware requirements

UM2715 - Rev 1 page 4/15

Figure 4. X-NUCLEO-OUT08A1 and STM32 Nucleo stack

1.3 System requirements

To use the STM32 Nucleo development boards with the X-NUCLEO-OUT08A1 expansion board, you need:

• a Windows PC/laptop (Windows 7 or above)

• a type A to mini-B USB cable to connect the STM32 Nucleo board to the PC when using a NUCLEO-

F401RE development board

• a type A to micro-B USB cable to connect the STM32 Nucleo board to the PC when using a NUCLEO-

G431RB development board

• the X-CUBE-OUT8 firmware and software package installed on your PC/laptop

1.4 Board setup

Step 1. Connect the X-NUCLEO-OUT08A1 to the NUCLEO-F401RE or NUCLEO-G431RB development board

through the Arduino connectors.

Step 2. Connect the X-NUCLEO-OUT08A1 power section (see Section 1.1.2 Power section).

Step 3. Connect the load between CN1 pins 2 and 3.

Step 4. Connect the mini-USB (for NUCLEO-F401RE) or micro-USB (for NUCLEO-G431RB) cable between

your PC and the STM32 Nucleo board.

Step 5. Download the selected firmware (STSW-OUT8F4 for NUCLEO-F401RE or STSW-OUT8G4 for

NUCLEO-G431RB) onto the microcontroller.

Step 6. Provide the digital supply voltage (see Section 1.1.1 Digital section).

Step 7. Reset the example sequence by pushing the black button on the STM32 Nucleo board.

UM2715

System requirements

UM2715 - Rev 1 page 5/15

Step 8. Push the blue button on STM32 Nucleo board to choose among the examples provided in the default

firmware package.

Note: When using two boards stacked (e.g. dual channel digital output or single channel safety digital output

application), you have to move some signal enabler resistors from DEFAULT to ALTERNATE position. You can

refer to the expansion board schematic and/or to the table below (where board 0 mounts all the resistors in their

DEFAULT position).

Table 1. Pin position when using a board stack

Board 0 Board 1

IN1 Nch_DRV DIAG OUT_FB IN1 Nch_DRV DIAG OUT_FB

R101 R102 R103 R104 R111 R134 R112 R131

UM2715

Board setup

UM2715 - Rev 1 page 6/15

2Schematic diagrams

Figure 5. X-NUCLEO-OUT08A1 circuit schematic (1 of 2)

IN1

DIAG

R121 100 (N.M.)

R125 100 (N.M.)

Arduino Connectors

OUT_FB

PA9

OUT1

Nch-DRV

R101 100

Nch-DRV

214

109

CN5

SSQ-110-04-F-S

Alternate Nucleo Supply

7V - 12 V

DIAG

Not Assembly

OUT_FB

PB5

PC7

ALTERNATE USE

R124 100 (N.M.)

PB0

PC0

PA5

R104 100

Nch-DRV

CN9

SSQ-108-04-F-S

3V3

R133 100 (N.M.)

Nch-DRV

R111 100 (N.M.)

Analog supply

8V - 60 V

OUT_FB

VIN

R103 100

2.2uF

PA1

PB4

PA3

ALTERNATE USE

OUT_FB

R102 100

TP9

5001

OUT_FB

DIAG R112 100 (N.M.)

R123 100 (N.M.)

IN1

OUT_FB

DIAG

default open

VIN

EARTH

D2 BAT48 (N.M.)

IN1

ALTERNATE USE

DEFAULT

ALTERNATE USE

Nch-DRV

IN1

47uF (N.M.)

DIAG

CN7

SSQ-119-04-L-D (N.M.)

DEFAULT

ALTERNATE USE

DIAG

TP8

5001

IN1

ALTERNATE USE

Nch-DRV

3v3

CN6

SSQ-108-04-F-S

4700pF

STPS1H100A

VCC

GND

SM15T39CA

OUT1

PA7

PC1

ALTERNATE USE

5v0

AVDD

IOREF

R122 100 (N.M.)

Morpho Connectors

(N.M.)

R131 100 (N.M.) IN1

default closed

default open

CN2

Con2

R130 100 (N.M.)

4700pF

R132 100 (N.M.)

CN1

Con3

PB8

PA10

PA4

PA2

PB9

PA0

PB10

CN8

SSQ-106-04-F-S

PA8

PA6

PB6

(7V-12V NUCLEO supply voltage)

R134 100 (N.M.)

VCC

ESDA15P60-1U1M (N.M.)

CN10

SSQ-119-04-L-D (N.M.)

NRST

PB3

DEFAULT

UM2715 - Rev 1 page 7/15

UM2715

Schematic diagrams

Figure 6. X-NUCLEO-OUT08A1 circuit schematic (2 of 2)

NC1

3DIAG

VCC

3v3

ANY

R15

TP7

STPS1H100A

R13

27K

con8-2x4-strip-male

10nF

default closed

(open load detection = active)

con8-2x4-strip-male

2.2K

ANY

ACPL-217-50AE

R11

Vcc_TAB

OUT1

TR3

27K

con3-strip-male

Nch-DRV

100nF

R96.8k

VCC

TP3

OUT2

OUT3 10

22k

SW2

2.2K

J14

OUT1

0.1uF

R14

27K

ACPL-217-50AE

ISO2

1Vcc1

IPS160HF

VCC

5001

J13

68k

CoD

390

GND 7

OUT4 11

5001

ACPL-217-50AE

ISO4

ISO3

47nF

SW1

con3-strip-male

BAT41ZFILM

TP6

RED

Vcc2

1.5k

NC2

2.2K

R12

R16

TDZ6V2J,115

SM15T10AY

STN2NF10

DIAG

R10

6.8k

OUT1

5v0

5001

default: closed

default:

close 1-2

default:

closed

default:

CLOSE 2-3

default:

3-4 = CLOSE

default:

1-2, 5-6, 7-8 = OPEN

closed

default:

open

default:

3-4 = CLOSE

150060VS75000

ACPL-217-50AE

IN1

ISO1

1-2, 5-6, 7-8 = OPEN

22k

OUT_FB

390

UM2715 - Rev 1 page 8/15

UM2715

Schematic diagrams

3Bill of materials

Table 2. X-NUCLEO-OUT08A1 bill of materials

Item Q.ty Ref. Part/Value Description Manufacturer Order code

1 2 C1, C2 4700 pF Capacitors Vishay Vitramon HV1825Y472KXHATHV

2 1 C3 2.2 µF Capacitor AVX 12061C225KAT2A

3 1 C4 100 nF Capacitor Wurth Electronics

Inc. 885012207128

4 1 C5 10 nF Capacitor Murata Electronics

North America GRM188R71H103KA01D

5 1 C6 47 nF Capacitor Murata Electronics

North America GCM188R71H473KA55D

6 1 C7 0.1 µF Capacitor Kemet C0603C104K5RACTU

7 1 C8 47 µF Capacitor Wurth Electronics

Inc. 860040875002

8 1 CN1 Con3 Fixed terminal

block

Wurth Electronics

Inc. 691214110003

9 1 CN2 Con2 Fixed terminal

block

Wurth Electronics

Inc. 691214110002

10 1 CN5 SSQ-110-04-F-S Connector Samtec Inc. SSQ-110-04-F-S

11 2 CN6, CN9 SSQ-108-04-F-S Connectors Samtec Inc. SSQ-108-04-F-S

12 2 CN7, CN10 SSQ-119-04-L-D

(N.M.) Connectors Samtec Inc. SSQ-119-04-L-D

13 1 CN8 SSQ-106-04-F-S Connector Samtec Inc. SSQ-106-04-F-S

14 2 D1, D7 STPS1H100A 100 V, 1 A power

Schottky rectifier ST STPS1H100A

15 1 D2 BAT48 (N.M.)

40 V, 350 mA axial

general purpose

signal Schottky

diode

ST BAT48JFILM

16 1 D3 BAT41ZFILM

100 V, 200 mA

surface mount

general purpose

signal Schottky

diode

ST BAT41ZFILM

17 1 D5 150060RS75000 LED Wurth Electronics

Inc. 150060RS75000

18 1 D6 150060VS75000 LED Wurth Electronics

Inc. 150060VS75000

19 1 D8 TDZ6V2,J115 Zener diode Nexperia USA Inc. TDZ6V2,J115

20 4 ISO1 ISO2 ISO3

ISO4 ACPL-217-50AE Optocouplers Broadcom Ltd. ACPL-217-50AE

21 8 J1, J2, J3, J4, J5,

J7, J8, J9

Strip 2x1 pitch

2.54 mm., con2-

strip-male

Jumpers Sullins Connector

Solutions STC02SYAN

22 2 J13, J14

con8-2x4-strip-

male pitch 2.54

Connectors Amphenol ICC 67996-408HLF

UM2715

Bill of materials

UM2715 - Rev 1 page 9/15

Item Q.ty Ref. Part/Value Description Manufacturer Order code

23 1 Q1 STN2NF10

N-channel 100 V,

0.23 Ohm, 2.4 A

STripFET(TM) II

power MOSFET

ST STN2NF10

24 2 R1, R2 27 K Resistors Yageo RC0603FR-0727KL

25 2 R3, R4 2.2 K Resistors Yageo RC0603FR-072K2L

26 2 R5, R6 390 Resistors Yageo RC0603FR-07390RL

27 2 R7, R8 15 k Resistors Yageo RC0603FR-0715KL

28 2 R9 R10 6.8 k Resistors Yageo RC0603FR-076K8L

29 1 R11 1 k Resistor Yageo RC0603FR-071KL

30 3 R12, R13, R14 22 k Resistors Yageo RC0603FR-0722KL

1 R15 68 k Resistor Yageo RC0603FR-0768KL

32 1 R16 10 k Resistor Yageo RC0603FR-0710KL

33 4 R101, R102,

R103, R104 100 k Resistors Yageo RC0603FR-07100RP

34 12

R111, R112,

R121, R122,

R123, R124,

R125, R130,

R131, R132,

R133, R134

100 k (N.M.) Resistors Yageo RC0603FR-07100RP

35 2 SW1, SW2 con3-strip-male Switches Any Any

36 5 TP3, TP6, TP7,

TP8, TP9 5001 Test points Keystone

Electronics 5001

37 1 TR3 SM15T10AY Automotive 1500

W TVS in SMC ST SM15T10AY

38 1 U1 IPS160HF Single high-side

switch ST IPS160HF

39 1 U2 SM15T39CA 1500 W, TVS in

SMC ST SM15T39CA

40 1 U3 ESDA15P60-1U1

M (N.M.)

High-power

transient voltage

suppressor (TVS)

ST ESDA15P60-1U1M

UM2715

Bill of materials

UM2715 - Rev 1 page 10/15

Tabla de contenidos

Otros manuales de Hardware de computadora de ST

ST X-NUCLEO-IDB04A1 Manual de usuario

ST X-NUCLEO-OUT02A1 Manual de usuario

ST STEVAL-IPFC02V1 Manual de usuario

ST X-NUCLEO-53L8A1 Manual de usuario

ST STM8SVLDISCOVERY Instrucciones de instalación y funcionamiento

ST STM32F411 Manual de usuario

ST STM32F4 Series Manual de usuario

ST X-NUCLEO-IDB04A1 Manual de usuario

ST STEVAL-IFP042V1 Manual de usuario

ST STDES-PFCBIDIR Manual de usuario

ST STM32H573I-DK Manual de usuario

ST STLINK-V3PWR Manual de usuario

ST STM32F078CB Manual de usuario

ST AEK-COM-ISOSPI1 Manual de usuario

ST STEVAL-ISF001V2 Manual de usuario

ST X-NUCLEO-IHM07M1 Manual de usuario

ST STM32F10 Series Instrucciones de instalación y funcionamiento

ST I-CUBE-LRWAN Manual de usuario

ST STM32F3 Series Manual del propietario

ST Nomadik NHK-15 Manual de usuario

ST STEVAL-IFP043V1 Manual de usuario

ST EVALSPEAr320HMI Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

ST X-NUCLEO-OUT06A1 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

Advantech

Advantech ASMB-935 Series Manual de usuario
