SS Telecoms SS-68BB Manual de usuario

SS-68BB

USB MINI BUFFER

User Manual

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 2of 16

Revision History

Revision 01 Original document 2004

Revision 02 Cosmetic changes 06 December 2007

Revision 03 Add Appendix A 10 December 2008

Revision 04 Added Installation of USB drivers 08 July 2011

CONTENTS

1. INTRODUCTION ...............................................................................................................3

2. FEATURES .......................................................................................................................3

3. CONNECTIONS ................................................................................................................3

4. INSTALLATION OF USB WINDOWS 7 DRIVERS.............................................................4

5. CONNECTING TO SS-68 USING HYPERTERMINAL.......................................................9

6. PROGRAMMING INSTRUCTIONS .................................................................................12

7. TECHNICAL SPECIFICATIONS......................................................................................13

6. CONTACT DETAILS........................................................................................................14

APPENDIX A: USING SS—68BB USB AS A SECURITY DONGLE ..........................................15

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 3of 16

1. INTRODUCTION

The SS-68 USB Buffer is a call logging buffer that is supplied fitted standard with 128

Kbytes of RAM. Battery backup will allow logging in the event of power failure.

2. FEATURES

Line Powered

PABX connection OPTO-COUPLED

Battery backed operation

PABX power used when PC turned off

Full functionality during battery operation

Beeper warning when buffer full

Compact

Easy installation

LED buffer status indications

3. CONNECTIONS

PC Connection

USB PC Connection for programming and

collecting of data,

PABX Connection

Number

Pin Description

PABX Connection is by means of a

male 9 way ‘D’ type connector 2 Receive from PABX

4 & 7 Handshake to PABX

5 Common ‘Ground’ signal

6 & 8 Handshake from PABX

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 4of 16

4. INSTALLATION OF USB WINDOWS 7 DRIVERS

SS-68BB Driver Installation

Step 1

Connect a USB cable between the PC

and the SS

68 BB

USB

Device.

Step 2

Once the USB cable is connected, windows will try to install the driver.

When a window pops p that asks yo if yo wo ld like to install the drivers go

to STEP 6, if not follow the next STEP.

If USB cable is connected on a different port reinstall driver for that port. Go to

STEP 6.

Step 3

On the

comp ter connected to the SS

Click on Start then right click on

“Comp ter (My Comp ter Win Xp)” and select “Manage”.

Step 4

Select “Device Manager” nder Comp ter Management.

Step 5

Locate the SS

68 USB Datab ffer

nder “Other devices” and right click and select

“Update Driver Software”

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 5of 16

Step 6

The following window

appears

. Select “Browse my c

omp ter for drives”.

Step 7

Use the Browse b tton to locate drivers.

Note: The drivers can be downloaded from SS Telecoms web site or given on a

CD at special req est.

Step 8

Select Next and the following window appears indi

cating that the installation is

in progress.

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 6of 16

Step 9

When the Windows Sec rity message pops p, choose “Install this driver

software anyway”.

Step 10

Once the USB driver is installed the following window appears.

Step 11

Yo will notice the SS Telecoms Data B ffer USB device nder USB controllers.

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 7of 16

Step 12

Once the USB device is installed, windows will try to install the USB serial driver.

When a window pops p that asks yo if yo wo ld like to inst

all the drivers go

to STEP 15 if not follow the next STEP.

Step 13

To get serial comm nication to the device

yo need to i

nstall the Serial to USB

driver. Locate the “USB Serial” nder “Other devices”

Step 14

ight click and s

elect “Update Driver Software”

Step 15

The following window appears. Select “Browse my comp ter for drives”.

Step 15

Use the Browse b tton to locate drivers.

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 8of 16

Step 16

Select Next and the following window appears indicating that the installation is

in progress.

Step 17

When the Windows Sec rity message pops p, choose “Install this driver

software anyway”.

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 9of 16

Step 18

Once the USB driver is installed the following window appears.

Please make a not note of the COM port n mber at the top of the page.

5. CONNECTING TO SS-68 USING HYPERTERMINAL

Step 1

Open Hyperterminal

and select the Com Port of t

he SS

68 USB B ffer

and click

OK. Refer to Section 4 “Installation if USB Drivers “ Step 18

SS-68BB USB USER MANUAL

DOC. NO: SS-68BB USB-14 (REV 04) Page 10 of 16

Step 2

Select “Restore Defaults” then click OK

STEP 3

When connected Hyperterminal will show “Connected” at the left bottom corner.
