Spirometrics FLOWMATE V PLUS Manual de usuario

Doc. #: 20003 Rev. 3

FLOWMATE V PLUS USER’S MANUAL

P O Box 680, 22 Shaker Road

Gray, ME 04039 USA

http://www.spirometrics.com

REV 03

February 2004

Spirometrics FLOWMATE V PLUS User Manual

Page 2

Doc. #: 20004 Rev. 03

FLOWMATE V PLUS USER’S MANUAL

Table of Contents

CHAPTER 1 1

Introduction 1

Warranty Card 3

CHAPTER 2 5

Intended Use 5

Warnings and Precautions 5

Setting Up 6

Loading Paper 6

Factory Settings 8

Customization Routine 10

Setting Time/Date 11

CHAPTER 3 12

Calibrating the Spirometer 12

CHAPTER 4 14

Operating the Flowmate V Plus 14

Summary of Operations 16

CHAPTER 5 17

Testing 17

Patient Preparation 17

Entering Patient Data 18

Forced Vital Capacity (FVC) Testing 20

Summary of FVC Test Results 22

Maximum Voluntary Ventilation (MVV) Testing 23

Vital Capacity (VC) Testing 25

Methacholine Challenge 27

Post-Bronchodilator Testing 30

Retrieving Test Results 31

Erasing a Test 32

Erase Procedure 32

Saving Patients to Diskette 33

Summary Reports 33

CHAPTER 6 35

Maintenance 35

Diagram Handle Assembly 36

Cleaning and Sanitizing 37

Troubleshooting 38

Calibration 40

Patient Storage 41

Spirometrics FLOWMATE V PLUS User Manual

Page 3

Doc. #: 20004 Rev. 03

CHAPTER 7 42

Specifications 42

Spirometrics FLOWMATE V PLUS User Manual

Page 4

Doc. #: 20004 Rev. 03

CHAPTER 1

INTRODUCTION

CONGRATULATIONS...on your purchase of a Spirometrics FLOWMATE V PLUS

spirometer. Built by the Spirometrics Medical Equipment Company of Maine, the

FLOWMATE V PLUS represents the newest technology in the medical equipment field.

Its ease of operation and durability will provide years of service.

Spirometrics is committed to designing products that meet the highest standards of

quality instrumentation for pulmonary function testing. We have designed the

FLOWMATE V PLUS to take advantage of new developments in computers and

software for years to come.

Please read this manual carefully before setting up and operating your new FLOWMATE

V PLUS.

STOP!

BEFORE SETTING UP, PLEASE COMPLETE THE ATTACHED WARRANTY

CARD ON PAGE THREE (3) TO ENSURE THAT YOUR WARRANTY RIGHTS

ARE COVERED.

Spirometrics FLOWMATE V PLUS User Manual

Page 5

Doc. #: 20004 Rev. 03

For the device warranty to be in effect, the attached warranty card must be returned to

Spirometrics Medical Equipment Co. for warranty registration. Please take this time to

fill out the enclosed postage paid warranty card. You may also register your warranty by

calling 800-767-0004 or faxing the information to 207-657-4123.

All Spirometrics spirometers are warranted to be free from defects in workmanship and

material for a period of TWELVE MONTHS from the date of purchase as validated by

the return of the warranty card. If the warranty card is not returned or otherwise

registered by phone, the TWELVE MONTH warranty begins from the date of

manufacture.

During the warranty period, any and all original parts and or workmanship proven to be

defective will be replaced or repaired at an authorized service center provided the

equipment has been operated and maintained in accordance with the instructions

contained in the Operator’s Manual. This warranty applies to the original user only, is

not transferable, and does not extend to any product or component which has been

repaired or altered by anyone other than personnel authorized by Spirometrics. This

warranty is in lieu of and excludes any warranty as to merchantability and all other

warranties expressed or implied and does not cover consequential damages due to

improper use or application of the product.

Spirometrics FLOWMATE V PLUS User Manual

Page 6

Doc. #: 20004 Rev. 03

This page set aside for the WARRANTY CARD insert.

Spirometrics FLOWMATE V PLUS User Manual

Page 7

Doc. #: 20004 Rev. 03

This page set aside for the WARRANTY CARD insert.

Spirometrics FLOWMATE V PLUS User Manual

Page 8

Doc. #: 20004 Rev. 03

CHAPTER 2

INTENDED USE

The FLOWMATE V PLUS spirometer is intended for use with adult and pediatric

patients for the diagnosis and monitoring of pulmonary disorders. The company

disclaims responsibility for all other uses, and the user agrees to assume liability for

damages resulting from non-intended use or operator error by the user or user’s

employees.

WARNINGS AND PRECAUTIONS

The following warnings and precautions must be heeded at all times:

Use a genuine Spirometrics filter/mouthpiece (Spiro-Filter) to ensure proper

accuracy, reduce the risk of patient cross-contamination and to protect the

internal sensor element. Replace the Spiro-Filter after each patient.

When the unit is not used for extended periods of time, set the printer lever in

the down position. If the printer is left for a long time with the printer head

engaged, the printer head may become deformed and print quality cannot be

guaranteed. See the LOADING PAPER section later in this chapter.

Clean the EASY CLEAN cartridge regularly to insure the long-term stability

and accuracy of the instrument. Please refer to Chapter 6 MAINTENANCE

AND TROUBLESHOOTING for proper cleaning procedures. Do not attempt

to clean the unit with abrasives or solvents. Do not autoclave any portion of the

unit.

Never immerse any component of the system in water or other liquids with the

exception of the EASY CLEAN cartridge.

The FLOWMATE V PLUS has built-in calibration capability. The 1994 ATS

standard on spirometry recommends daily calibration of this instrument or

more frequently as appropriate.

Accurate and effective use of the FLOWMATE V PLUS depends on correct

application of well established spirometry practices.

Do not operate the unit in a flammable or explosive atmosphere.

Insure that the EASY CLEAN cartridge is properly installed as described in

Chapter 6 MAINTENANCE AND TROUBLESHOOTING.

Do not drop the sensor handle. The FLOWMATE V PLUS handle is a sensitive

measurement device. Improper handling could affect the accuracy of its

reported results.

Spirometrics FLOWMATE V PLUS User Manual

Page 9

Doc. #: 20004 Rev. 03

SETTING UP

1. Remove FLOWMATE V PLUS from box and unwrap packing materials.

Check the list to make sure all items listed are in the box.

1 - FLOWMATE V PLUS

1 - Thermal paper roll

1 - Power cord

1 - Power supply

1 - Operator’s manual

2. Place FLOWMATE V PLUS on flat surface.

3. Take the five (5) pin DIN connector end of power supply cord and plug into

the power input of FLOWMATE V PLUS.

•Take the IEC320 connector end of power cord and plug into the power

supply.

•Plug AC cord into an outlet.

4. Insert disposable filter onto EASY CLEAN Cartridge.

LOADING PAPER

The FLOWMATE V PLUS is equipped with an internal thermal printer, and an external

parallel printer connection. Before using, the thermal paper will have to be loaded.

1. Cut the printer paper with a diagonal cut as shown at the end of this section.

Position the printer lever in the down position. This releases the printer platen

to ease the threading of paper into the printer.

2. Place paper roll into holder by pulling either of the spring-loaded clips.

3. Insert paper into the printer slot going in from the top. When the paper meets

with resistance against the paper roller, press the PAPER key on the keypad.

Pressing once and releasing will advance the paper one line at a time.

Pressing the PAPER key down and holding it for 4 seconds will initiate the

printer continuous feed mode until the PAPER key is released.

Note: The printer has an internal paper sensor located on the right hand

side. If when inserting the paper to thread the printer, paper does not cover

Spirometrics FLOWMATE V PLUS User Manual

Page 10

Doc. #: 20004 Rev. 03

the sensor, the printer will not advance when pressing the paper key. It will

beep to indicate that the paper is not detected. Please remove and try again.

4. Once the paper has begun to feed through the printer, create enough lead to

check the paper alignment through the printer by lining up the edges of the

paper through the printer with that to be fed into it from the back. Shift as

necessary to align.

5. Set paper release toggle to up position to engage printer platen onto the paper.

CAUTION: When the unit is not used for extended periods of time, set the

printer lever in the down position. If the printer is left for a long time with

the printer head engaged, the printer head may become deformed and print

quality cannot be guaranteed.

6. Press paper advance.

We suggest cutting the thermal paper roll on a diagonal and leave about an inch on the

right hand side to ease the paper detection and threading of paper into the printer:

Now your FLOWMATE V PLUS is ready to operate.

BEFORE SETTING UP, PLEASE COMPLETE THE ATTACHED WARRANTY

CARD ON PAGE THREE (3) TO ENSURE THAT YOUR WARRANTY RIGHTS

ARE COVERED.
