4-Port DSL/Cable Router

Model SS2604

Part No. 007-0113-001

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION.............................................................................................. 1

Features of the DSL/Cable Router................................................................................... 1

Package Contents .............................................................................................................. 3

Physical Details .................................................................................................................. 3

CHAPTER 2 INSTALLATION ............................................................................................... 6

Requirements ..................................................................................................................... 6

Procedure ........................................................................................................................... 6

CHAPTER 3 SETUP.................................................................................................................8

Overview ............................................................................................................................ 8

Configuration Program..................................................................................................... 9

Setup Wizard ................................................................................................................... 11

LAN Screen ......................................................................................................................14

Password Screen .............................................................................................................. 16

CHAPTER 4 PC CONFIGURATION................................................................................... 17

Overview .......................................................................................................................... 17

Windows Clients .............................................................................................................. 17

Printer Setup for Windows®........................................................................................... 29

Macintosh®Clients .......................................................................................................... 35

Linux Clients.................................................................................................................... 35

Other Unix Systems ......................................................................................................... 36

CHAPTER 5 OPERATION AND STATUS ......................................................................... 37

Operation ......................................................................................................................... 37

Status Screen.................................................................................................................... 38

Connection Status - PPPoE............................................................................................. 40

Connection Status - PPTP............................................................................................... 42

Connection Details - Fixed/Dynamic IP Address .......................................................... 44

CHAPTER 6 ADVANCED FEATURES............................................................................... 46

Overview .......................................................................................................................... 46

Advanced Internet Screen............................................................................................... 46

URL Filter........................................................................................................................ 50

Virtual Servers.................................................................................................................52

Dynamic DNS................................................................................................................... 55

Remote Management....................................................................................................... 57

Access Control ................................................................................................................. 58

Firmware Upgrade .......................................................................................................... 63

CHAPTER 7 ADVANCED CONFIGURATION ................................................................. 64

Overview .......................................................................................................................... 64

Network Clients Screen................................................................................................... 65

Options ............................................................................................................................. 67

Printer Port...................................................................................................................... 69

MAC Address .................................................................................................................. 70

Routing ............................................................................................................................. 71

Security............................................................................................................................. 75

APPENDIX A TROUBLESHOOTING ................................................................................ 77

Overview .......................................................................................................................... 77

General Problems ............................................................................................................ 77

Internet Access.................................................................................................................77

Printing............................................................................................................................. 78

APPENDIX B SPECIFICATIONS........................................................................................ 81

SpeedStream 4-Port DSL/Cable Router ........................................................................ 81

APPENDIX C TECHNICAL SUPPORT.............................................................................. 82

its logos and SpeedStream are registered and unregistered trademarks of Efficient Networks,

Inc. Siemens and the Siemens logo are trademarks of Siemens AG, Germany. All other trade-

marks are held by their respective companies. Efficient Networks reserves the right to make

changes to product specifications at any time without notice.

All trademarks and trade names are the properties of their respective owners.

Chapter 1

Introduction

This Chapter provides an overview of the SpeedStream 4-Port DSL/Cable

Router's features and capabilities.

Congratulations on the purchase of your new SpeedStream DSL/Cable Router, commonly

referred to as a Broadband Router. The SpeedStream 4-Port DSL/Cable Router is a multi-

function device providing the following services:

•Shared Broadband Internet Access for all LAN users.

•4-Port Switching Hub for 10BaseT or 100BaseT connections.

•Network Printer - LAN users can share the printer attached to the SpeedStream Router.

Figure 1: SpeedStream Router

Features of the DSL/Cable Router

The SpeedStream 4-Port DSL/Cable Router incorporates many advanced features, carefully

designed to provide sophisticated functions while being easy to use.

Internet Access Features

•Shared Internet Access. All users on the LAN can access the Internet through the

DSL/Cable Router, using only a single external IP Address. The local (invalid) IP Ad-

dresses are hidden from external sources. This process is called NAT (Network Address

Translation).

•DSL & Cable Modem Support. The DSL/Cable Router has a 10BaseT Ethernet port

for connecting a DSL or Cable Modem. All popular DSL and Cable Modems are sup-

ported.

•PPPoE and PPTP Support. The Internet (WAN port) connection supports PPPoE

(PPP over Ethernet) and PPTP (Peer-to-Peer Tunneling Protocol), as well as "Direct Con-

nection" type services.

DSL/Cable Router User Guide

•Fixed or Dynamic IP Address. On the Internet (WAN port) connection, the

DSL/Cable Router supports both Dynamic IP Address (IP Address is allocated on connec-

tion) and Fixed IP Address.

Advanced Internet Functions

•Conferencing & Telephony Applications. Internet Telephony and Conferencing

applications, which are often difficult to use when behind a Firewall, are supported.

•Special Internet Applications. Applications which use non-standard connections or

port numbers are normally blocked by the Firewall. The ability to define and allow such

applications is provided, to enable such applications to be used normally.

•Virtual Servers. This feature allows Internet users to access Internet servers on your

LAN. The required setup is quick and easy.

•DMZ. One (1) PC on your local LAN can be configured to allow unrestricted 2-way

communication with Servers or individual users on the Internet. This provides the ability to

run programs that are incompatible with Firewalls.

•URL Filter. Use the URL Filter to block access to undesirable Web sites by LAN users.

•Internet Access Log. See which Internet connections have been made.

•VPN Support. VPN (Virtual Private Networking) connections using PPTP and IPSec are

transparently supported - no configuration is required.

LAN Features

•4-Port Switching Hub. The DSL/Cable Router incorporates a 4-port 10/100BaseT

switching hub, making it easy to create or extend your LAN.

•DHCP Server Support. Dynamic Host Configuration Protocol provides a dynamic IP

address to PCs and other devices upon request. The DSL/Cable Router can act as a DHCP

Server for devices on your local LAN and WLAN.

•Multi Segment LAN Support. LANs containing one or more segments are supported,

via the Router's RIP (Routing Information Protocol) support and built-in static routing ta-

ble.

•Network Printer. The printer attached to the DSL/Cable Router becomes a "Network

Printer", available to all Windows and Linux (Unix) clients on your LAN.

Configuration & Management

•Easy Setup. Use your WEB browser from anywhere on the LAN for configuration.

•Remote Management. The DSL/Cable Router can be managed from any PC on your

LAN. And, if the Internet connection exists, it can also (optionally) be configured via the

Internet.

•UPnP Support. UPnP (Universal Plug and Play) allows automatic discovery and con-

figuration of the DSL/Cable Router. UPnP is by supported by Windows ME, XP, or later.

Introduction

Security Features

•Password - protected Configuration. Optional password protection is provided to

prevent unauthorized users from modifying the configuration data and settings.

•NAT Protection. An intrinsic side effect of NAT (Network Address Translation) tech-

nology is that by allowing all LAN users to share a single IP address, the location and even

the existence of each PC is hidden. From the external viewpoint, there is no network, only

a single device - the DSL/Cable Router.

•Stateful Inspection Firewall. All incoming data packets are monitored and all incom-

ing server requests are filtered, thus protecting your network from malicious attacks from

external sources.

•Protection against DoS attacks. DoS (Denial of Service) attacks can flood your

Internet connection with invalid packets and connection requests, using so much bandwidth

and so many resources that Internet access becomes unavailable. The DSL/Cable Router

incorporates protection against DoS attacks.

Package Contents

The following items should be included:

•SpeedStream 4-Port DSL/Cable Router (SS2604)

•Power Adapter

•Quick Start Guide

•CD-ROM containing the on-line manual and Print Port Driver for Windows®

•Extended Warranty/Product Registration Card

If any of the above items are damaged or missing, please contact SpeedStream Technical

Support for assistance.

Physical Details

LEDs

The front panel contains the following LEDs.

Power On - Normal operation.

Off - No power

Status On - Error condition.

Off - Normal operation.

Blinking - This LED blinks during start up, or when the Firmware is being

upgraded.

DSL/Cable Router User Guide

LAN Ports

(1, 2, 3, 4)

For each LAN port, there are 2 LEDs

•Link/Act

•On - Corresponding LAN (hub) port is active.

•Off - No active connection on the corresponding LAN (hub) port.

•Flashing - Data is being transmitted or received via the corre-

sponding LAN (hub) port.

•100

•On - Corresponding LAN (hub) port is using 100BaseT.

•Off - Corresponding LAN (hub) port connection is using

10BaseT, or no active connection.

WAN Port Flashing - data is being transmitted or received via the WAN port.

Off - no data is being transferred.

Print Act On - Connection to printer established.

Off - No connection to printer; printer is Off or Off-line.

Flashing - Data is being transmitted to the printer.

Print Err On - Printer error detected.

Off - No printer error detected.

Rear Panel

Figure 2: Rear Panel

Printer Port Standard parallel printer port. If you wish to share a printer, connect

it here.

Reset Button This button has three (3) functions:

•Reboot. When pressed and released, the DSL/Cable Router

will reboot (restart).

•Diagnostic print-out. If held down for 3 seconds, a diagnostic

print-out will be sent to the attached printer.

•Ensure the printer is ready.

•Both Print LEDs will flash simultaneously during the di-

agnostic printing.

•Restore Factory Defaults. This button can also be used to

clear ALL data and restore ALL settings to the factory default

values.

To Clear All Data and restore the factory default values:

1. Power Off the router.

Introduction

2. Hold the Reset Button down while you Power On the router.

3. Continue holding the Reset Button until the Status (Red) LED

blinks TWICE.

4. Release the Reset Button.

The factory default configuration has now been restored, and

the Router is ready for use.

WAN port

(10BaseT)

Connect the DSL or Cable Modem here. If your modem came with

a cable, use the supplied cable. Otherwise, use a standard LAN

cable.

10/100BaseT

LAN connectors

Use standard LAN cables (RJ45 connectors) to connect this port to

your PCs. Both 10BaseT and 100BaseT connections can be used

simultaneously.

LAN1 can act either as a normal port, or an "Uplink" port for

connection to another Hub. See the "Normal/Uplink" button

below.

Normal/Uplink

Button- Optional

If this button is present, it allows LAN port 1 to be used as an

Uplink port for connecting directly to another hub.

When depressed (in), then the "LAN 1" port becomes an "Uplink"

port, and must be connected to a normal port on another Hub.

If this button is extended (out), then the "LAN 1" port acts as a

normal LAN port.

Power port Connect the supplied power adapter here.

Chapter 2

Installation

This Chapter covers the physical installation of the SpeedStream DSL/Cable

Router.

Requirements

•DSL or Cable modem, and an Internet Access account with an ISP, for shared Internet

access.

•Network cables. Use standard 10/100BaseT CAT5 network (UTP) cables with RJ45

connectors

•TCP/IP network protocol must be installed on all PCs.

•For shared access to the attached printer, the following clients are supported:

•Windows 95/98/ME

•Windows NT 4.0, 2000 or XP

•Unix (LPD printing)

Procedure

Figure 3: Installation Diagram

1. Choose an Installation Site

Select a suitable place on the network to install the DSL/Cable Router.

Ensure that both the DSL/Cable Router and the DSL or Cable modem are powered OFF.

2. Connect LAN Cables

•Use standard 10/100 CAT5 network cables to connect PCs to the Switching Hub ports on

the DSL/Cable Router.

•Both 10BaseT and 100BaseT connections can be used simultaneously.

Installation

3. Connect WAN Cable

Connect the DSL or Cable modem to the WAN port on the DSL/Cable Router. Use the ca-

ble supplied with your DSL/Cable modem. .

4. Connect Printer Cable

Use a standard parallel printer cable to connect your printer to the Printer port on the

DSL/Cable Router.

5. Power Up

•Power on the Cable or DSL modem.

•Power on the Printer.

•Connect the supplied power adapter to the DSL/Cable Router and power up the router.

Use only the power adapter provided. Using a different one may cause hardware damage

6. Check the LEDs

•The Status LED should flash, then turn On. If it stays On, or flashing, there is a hardware

error.

•For each active LAN (PC) connection, the LAN Link/Act LED should be ON

•The WAN LED should be ON.

•The Print Act LED should be ON.

For more information, refer to LEDs in Chapter 1.

Tabla de contenidos

Otros manuales de Enrutador de red de SpeedStream

SpeedStream

SpeedStream 4200 Manual de usuario

SpeedStream

SpeedStream 2614 Manual de usuario

SpeedStream

SpeedStream 2602 Manual de usuario

SpeedStream

SpeedStream 5851 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
