Macroscope 45

PRODUCT MANUAL

Item # 2852

MACROSCOPE

portable microscopes

Thank you for purchasing a MACROSCOPE 45.

MACROSCOPE portable microscopes are designed to fill the

need for superior image quality in simple, cost effective configu-

rations for application in research, production, quality control or

wherever superior image quality is essential. MACROSCOPE

portable microscopes represent a significant departure from cur-

rent day trends towards more sophistication and more elaborate

features. Instead, they offer a simple, basic design and an ease

of use not found in today’s laboratory microscopes but without

compromising optical or mechanical quality. MACROSCOPE

25X an the MACROSCOPE 45X Power Unit. Both unites pro-

duce images superior to most laboratory instruments in resolu-

tion, contrast, brightness and field of view but at only a fraction

of the cost.

The MACROSCROPE 45x is a fixed magnification unit that is

equivalent in performance to instruments costing thousands of

dollars but is much quicker and easier to use. The 45x Macro-

scope is ideal for disease diagnosis on turfgrass plants.

A by-product of the simpler mechanical design is portability.

This unit can be used not only in the field but also for in-place

observation of specific portions of large or immovable objects

such as, a bridge girder, an aircraft wing or cement structure,

etc., without the need for destructive sampling for laboratory

analysis.

Applications for this unit are diversified and numerous. Archeol-

ogy, botany, entomology, forensics, geology, horticulture, numis-

matics and philately, quality control, and textiles are just a few of

the disciplines that can benefit from the use of this MACRO-

SCOPE portable microscope.

The assembled MACROSCOPE 45 has two knurled focus

adjustment knobs—one located at the top (eyepiece) and the

other located on the close-up attachment. The focusing

procedure is as follows:

1. Adjust the eyepiece focus know (Top of Macroscope) until

the reticle is as sharp as possible disregarding the image of

the object.

2. After the reticle is sharp adjust the close-up focus knob

(Bottom of Macroscope) until the image of the object is

sharp.

Estimating Distances

To estimate the distance of an object it is necessary to know its

approximate size. The procedure is simple using either of the

following formula: Metric:

English units:

For instance—a person is the distance approximately 6 feet tall

(2 meters) provides a scale reading of 2.5 sixteenths (4 mm).

The calculations are as follows:

Metric:

Answer = 40 meters English:

Answer = 192 feet

Focusing Instructions

Distance

(meters) = Size of object (M) / scale

reading (mm) X 80

Distance (feet)

= Size of object (ft) / scale

reading (sixteenth) X 80

0(Meters) 2(Meters) / 4(mm) X 80

0(feet) 6 (ft) / 2.5 (sixteenth) X 80

Warr a nty

This product is warranted to be free from defects in material or work-

manship for one year from the date of purchase. During the warranty

period Spectrum will, at its option, either repair or replace products that

prove to be defective. This warranty does not cover damage due to

improper installation or use, lightning, negligence, accident, or unau-

thorized modifications, or to incidental or consequential damages be-

yond the Spectrum product. Before returning a failed unit, you must

obtain a Returned Materials Authorization (RMA) from Spec-

trum. Spectrum is not responsible for any package that is returned

without a valid RMA number or for the loss of the package by any ship-

ping company.

12360 S. Industrial Dr. E

Plainfield IL 60585

(800) 248-8873 or (815) 436-4440

Fax (815) 436-4460

E-Mail: [email protected]

www.specmeters.com

Rev. 08/28/2012

For customer support, or to place an order, call Spectrum

Technologies at (800)248-8873 or (815)436-4440 between 7:30

a.m. and 5:30 p.m. CST, FAX at (815)436-4460, or E-mail at

[email protected].
