Enable Left Detection: Alarms will be triggered if there are
items left in the pre-defined area.
Enable Item Missing Detection: Alarms will be triggered if
there are items missing in the pre-defined area.
Shortest Holding Time: it is the alarm delay time of the
object left in the region or removed from the region
(ranges from 10~3600s). For example, if “Left detection” is
selected and the shortest holding time is set as 10, alarms
will be triggered after the object is left and stay in the
region for 10s, but when someone takes away the object
within 10s, alarms will not be triggered.
Set the alarm holding time and alarm trigger options. The
setup steps are the same as motion detection. Please refer
to motion detection section for details.
Click “Save” button to save the settings. Set the alarm area
of the object removal detection.
Click the “Area” tab to go to the interface as shown below.
Set motion detection area and sensitivity. Click the “Area and Sensitivity” tab to go to the interface as
shown below.
2) Move the “Sensitivity” scroll bar to set the sensitivity. Higher sensitivity value means that
motion will be triggered more easily. Select “Add” and click “Draw”. Drag the mouse to draw the
motion detection area; Select “Erase” and drag the mouse to clear motion detection area. After
that, click the “Save” to save the settings. “Clear All” can be used to clear out the entire motion
zone. Set the schedule for motion detection. The schedule setup steps of the motion detection
are the same as the schedule recording setup.
People & Vehicle Detection (*This will not be enabled by default*)
1) Enable object removal detection and then select the detection type.
