Speco D8HS Manual de instrucciones

OSD Main Menu

Option Description

SEARCH Select this option to enter the Search menu

SETUP Select this option enter the Setup menu

DISPLAY Select between dierent multi-view display formats.

Capture pictures and store as BMP lesSNAPSHOT

SUPER EZ COPY

AUDIO MUTE Select this option to mute audio on all channels.

CAMERA PTZ Select this option to access the PTZ interface

ENABLE MAIN

MONITOR SEQUENCE

Select this option to enable/disable video sequence function.

DISABLE ALARM OUT Select this option to enable/disable Alarm outputs.

MANUAL

DIGITAL DETERRENT

Displays a window where the user can manually

trigger the Digital Deterrent audio message.

SITE INFORMATION Press the button to view the record setting of a selected channel.

SYSTEM INFORMATION Displays a window with the system information.

EXPORT HELP Displays quick instructions for exporting video.

SYSTEM LOCK Locks the DVR from unauthorized user access..

SYSTEM SHUTDOWN Click this button to shutdown system.

Select this option to enable/disable manual recording. Also known

as Panic Record. Default is set to continuous recording.

ENABLE MANUAL

RECORD

ADVANCED MENU

Select this option to start EZ Setup WizardEZ SETUP

Select this option to start EZ Copy Wizard

• To enter the main menu, press the setup button on the remote control or right click on the mouse

and select setup from the submenu

• Enter username and password.

The default username is admin

and password is 1111.

INSTANT PLAYBACK Go back to the specic time and play the recoding data

Playback

EZSearch

• Select EZSEARCH and click NEXT.

and click NEXT.

click NEXT. Thumbnail view of each

hour will be shown.

• Double click on the hour of interest.

Thumbnail view of each 2.5 minutes

within the hour will be shown.

• Double click on the thumbnail to

begin playback.

• Select SEARCH from the sub-menu

Each thumbnail represents an hour of

video. Select a thumbnail to narrow event.

Each thumbnail now represents

2.5 minutes of video.

Time Line

• Select TIME LINE and click NEXT.

Event

• Select EVENT and click NEXT.

• Click on PLAY to begin playback.

• Go into playback mode as described in the previous section

Export

• Click on EXPORT near the bottom of the playback screen.

Export

EZCopy

• Click on EZCOPY START near the bottom of the playback screen. This will begin the start

time of the recorded data to be exported.

• Select the ARCHIVE MEDIA TYPE and click NEXT.

◦ STILL IMATE : Snapshots

◦ NSF : Proprietary *.nsf video format

◦ AVI : *.avi video format, integrated subtitles, Separated Subtitle(MAC compatible)

• Select the MEDIA TYPE (USB DRIVE) and click NEXT.

• Select the specific CHANNEL and DURATION and click START to begin export.

• The DVR will continue to play the recorded video.

• Move time cursor to go to the time to end backup

• Click on EZCOPY STOP and this will set the end time of the recorded data to be exported

• Select the FILE FORMAT and click NEXT.

• Select the specific CHANNEL and click START to begin export.

Event Export

Export via Web-Browser Viewer

• Start Internet Explorer and enter the IP address and port of the DVR.

◦ For example http://[ip address] : [port]→http://192.168.78.11:80

• The ActiveX controls and plug-ins dialog will be prompted for installation

• Install the plug-ins

• Click on CONNECT and enter the IP, port number, username and password of the DVR.

◦ The default usernames and passwords are admin / 1111 and user 1 / 1111.

• Click on SEARCH to go into PLAYBACK

• To export an event, go into Live mode and go to SEARCH from the sub-menu.

• Select EVENT and click NEXT.

• Select the specific MONTH, DATE and click NEXT. The list of events will be shown.

• Select the specific EVENT and click BACKUP

• Select the MEDIA TYPE (USB DRIVE) and click BACKUP to begin export of event

iPhone®

• Click on EZCOPY START near the bottom of the playback screen. This will indicate the start

time of the recorded data to be exported.

• The DVR will continue to play the recorded video.

• Move time bar cursor to go to the time to end backup.

• Click on EZCOPY END and this will indicate the end time of the data export

• Select AVI ACKUP button.

• Select the CHANNEL, FILE FORMAT, FILE PATH and click OK to begin export.

The DVR provides mobile surveillance software for both the iPhone and the Android™.

Mobile View Software

• Search for ‘Speco Player’ in the Apple App Store and install the app.

• Select the ADD menu and enter site information. Click ADD to save the site information.

• Select the saved site from “Devices”.

• Select a channel(s) to view.

• Select Playback/Live then click CONNECT.

D16HS

D16HS D16HS D16HS D16HS

D16HS

Android™

SpecoTech Multi-Client Viewer

The SpecoTech Multi-Client Viewer Software and manual are included on the CD.

• Select the ADD menu and enter site information. Click ADD to save the site information

• Select the saved site from “Devices” and select LIVE VIEW or PLAYBACK

• Select 4 channels to view and click “Start” button

• Search for ‘Speco Player’ in the Android Play Store and install the App.

SpecoTech Multi-Client Viewer Software is a multiple site

monitoring client software that allows streaming of video and

audio, and transmission of alarm signals from the DVR’s over

the network.

The SpecoTech Multi-Client can display up to 16 DVR’s and

supports dual monitors. PTZ Camera control is also supported

by this software

By attaching a microphone and speaker system to devices on

site, the user may make bi-directional audio communication

over the network

Refer to the complete manual for more information

D16HS
