Wireless Module

WPEQ-268AXI(BT)

WPEQ-268AX(BT)

Manual

SPEC

Standards IEEE 802.11ax/ac/a/b/g/n (2T2R)

Bluetooth V5.2, V5.1, V5.0, V4.2, V4.1, V4.0LE, V3.0, V2.1+EDR

Chipset Qualcomm Atheros WCN6856

Data Rate

802.11b: 11Mbps

802.11a/g: 54Mbps

802.11n: MCS0~15

802.11ac: MCS0~9

802.11ax: HE0~11

Bluetooth: 1 Mbps, 2Mbps and Up to 3Mbps

Operating Frequency

IEEE 802.11ax/ac/a/b/g/n

ISM Band, 2.412GHz~2.484GHz, 5.150GHz~5.850GHz ,5.925~7.125GHz

*Subject to local regulations

Interface

WLAN: PCIe

Bluetooth: USB

Form Factor Half Mini PCI-e

Antenna

2 x IPEX MHF1 connectors

(Ant 1 for WLAN/BT, Ant 2 for WLAN)

Modulation

Wi-Fi:

802.11b: DSSS (DBPSK, DQPSK, CCK)

802.11g: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)

802.11n: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)

802.11a: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)

802.11ac: OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM)

802.11ax: OFDMA (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM)

BT:

Header: GFSK

Wireless Module

Payload 2M: π/4-DQPSK

Payload 3M: 8-DPSK

Operating Voltage DC 3.3V

Operating Temperature Range

WPEQ-268AXI(BT) :-40°~+75°C (Operating)

WPEQ-268AX(BT) :-10°~+65°C (Operating)

Storage Temperature Range -45°C~90°C

Humidity

(Non-Condensing)

5%~90% (Operating)

5%~90% (Storing)

Dimension L x W x H (in mm) 29.85mmx 26.65mmx 2.5mm

Weight (g) 3.2g

Security 64/128-bits WEP, WPA, WPA2, WPA3, 802.1x

Wireless Module

Block Diagram

Wireless Module

Installation

Connect the Module to the PCIe slot of the computer.

Install Wi-Fi driver driver.

After the Wi-Fi Driver is installed , click the Network icon on the Windows, then search the network ,

and connect the Wireless Network you want.

Federal Communication Commission Interference Statement:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications not expressly approved by the party responsible for compliance could void

your authority to operate the equipment.

RF exposure statements

This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with a minimum distance of 20 centimeters between the

radiator and your body or nearby persons.

CFR 47 FCC PART 15 SUBPART C (15.247) and SUBPART E (15.407) has been investigated. It is applicable to

the modular transmitter.

The devices must be installed and used in strict accordance with the manufacturer's instructions as

described in the user documentation that comes with the product.

Wireless Module

This radio transmitter RYK-WPEQ268AXBT has been approved by Federal Communications Commission to

operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types

not included in this list that have a gain greater than the maximum gain indicated for any type listed are

strictly prohibited for use with this device.

Unique antenna connector must be used on the Part 15 authorized transmitters used in the host product.

Antenna

Type

Brand

Antenna

Model

Maximum Gain (dBi)

Remark

2.4 GHz 5GHz 6GHz

Dipole SparkLAN AD-506AX 2.65 dBi 4.81 dBi 4.98 dBi

Length of Antenna cable:550mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-501AX 3.7 dBi 5 dBi 5 dBi

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX to RP-SMA

Dipole SparkLAN AD-312N 2.65 dBi 4.86 dBi N/A

Length of Antenna cable:550mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-509AX 3.7 dBi 5 dBi 5 dBi

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-103AG 2.02 dBi 2.03 dBi N/A

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX to RP-SMA

Dipole SparkLAN AD-302N 3.14 dBi 2.87 dBi N/A

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX to RP-SMA

Dipole SparkLAN AD-303N 3.14 dBi 3.45dBi N/A

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX to RP-SMA

Dipole SparkLAN AD-315N 3 dBi 5 dBi N/A

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-507AX 2.67 dBi 4.87 dBi 4.94 dBi

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-508AX 2.67 dBi 4.87 dBi 4.94 dBi

Length of Antenna cable:250mm

Connector type of Antenna cable: I-PEX

If the FCC identification number is not visible when the module is installed inside another device, then the

outside of the device into which the module is installed must also display a label referring to the enclosed

module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID:

RYK-WPEQ268AXBT” Or “Contains FCC ID:RYK-WPEQ268AXBT”

The modular transmitter is only FCC authorized for the specific rule parts (i.e., FCC transmitter rules) listed

on the grant, and the host product manufacturer is responsible for compliance to any other FCC rules that

Wireless Module

apply to the host not covered by the modular transmitter grant of certification. The final host product still

requires Part 15 Subpart B compliance testing with the modular transmitter installed.

Manufacturers of U-NII devices are responsible for ensuring frequency stability such that an emission is

maintained within the band of operation under all conditions of normal operation as specified in the users

manual.

The module is for indoor applications only.

The module may not be used for the purposes of remote control of drones

The antenna must be installed into the host device so that the end user does not have access to the

antenna or its connector.

Minimum antenna gain, including any cable losses, for the 6GHz bands must exceed 0dBi.

When installed in the host there cannot be a direct connection to the internet

Industry Canada statement:

This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two

conditions:

1) This device may not cause interference, and

2) This device must accept any interference, including interference that may cause undesired operation of

the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de

licence. L’exploitation est autorisée aux deux conditions suivantes :

1) l’appareil ne doit pas produire de brouillage;

2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, meme si le brouillage est

susceptible d’en compromettre le fonctionnement.

Caution:

1) The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for

harmful interference to co-channel mobile satellite systems;

2) For devices with detachable antenna(s), the maximum antenna gain permitted for devices in the bands

5250-5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit;

Wireless Module

3) For devices with detachable antenna(s), the maximum antenna gain permitted for devices in the band

5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-

point and non-point-to-point operation as appropriate; and

Avertissement:

1) Le dispositif fonctionnant dans la bande 5150-5250 MHz est réservé uniquement pour une utilisation à

l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant

les mêmes canaux;

2) Le gain maximal d’antenne permis pour les dispositifs avec antenne(s) amovible(s) utilisant les bandes

5250-5350 MHz et 5470-5725 MHz doit se conformer à la imitation P.I.R.E.;

3) Le gain maximal d’antenne permis pour les dispositifs avec antenne(s) amovible(s) utilisant la bande

5725-5850 MHz doit se conformer à la limitation P.I.R.E spécifiée pour l’exploitation point à point et non

point à point, selon le cas.

Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with minimum distance 20cm between the radiator & your

body.

Déclaration d’exposition aux radiations:

Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un

environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de

distance entre la source de rayonnement et votre corps.

This radio transmitter (IC:6158A-WPEQ268AXBT has been approved by Industry Canada to operate with

the antenna types listed below with the maximum permissible gain indicated. Antenna types not included

in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for

use with this device.

Le présent émetteur radio (IC:6158A-WPEQ268AXBT a été approuvé par Industrie Canada pour fonctionner

avec les types d'antenne énumérés cidessous et ayant un gain admissible maximal. Les types d'antenne

non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits

pour l'exploitation de l'émetteur.

Wireless Module

Antenna

Type

Brand

Antenna

Model

Maximum Gain (dBi)

Remark

2.4 GHz 5GHz 6GHz

Dipole SparkLAN AD-506AX 2.65 dBi 4.81 dBi 4.98 dBi

Length of Antenna cable:550mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-501AX 3.7 dBi 5 dBi 5 dBi

Length of Antenna cable:550mm

Connector type of Antenna cable: I-PEX to RP-SMA

Dipole SparkLAN AD-312N 2.65 dBi 4.86 dBi N/A

Length of Antenna cable:550mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-509AX 3.7 dBi 5 dBi 5 dBi

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-103AG 2.02 dBi 2.03 dBi N/A

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX to RP-SMA

Dipole SparkLAN AD-302N 3.14 dBi 2.87 dBi N/A

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX to RP-SMA

Dipole SparkLAN AD-303N 3.14 dBi 3.45dBi N/A

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX to RP-SMA

Dipole SparkLAN AD-315N 3 dBi 5 dBi N/A

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-507AX 2.67 dBi 4.87 dBi 4.94 dBi

Length of Antenna cable:150mm

Connector type of Antenna cable: I-PEX

Dipole SparkLAN AD-508AX 2.67 dBi 4.87 dBi 4.94 dBi

Length of Antenna cable:250mm

Connector type of Antenna cable: I-PEX

If the ISED certification number is not visible when the module is installed inside another device, then the

outside of the device into which the module is installed must also display a label referring to the enclosed

module. This exterior label can use wording such as the following: “Contains IC: 6158A-WPEQ268AXBT”.

Si le numéro de certification ISDE n'est pas visible lorsque le module est installé à l'intérieur d'un autre

appareil, alors l'extérieur de l'appareil dans lequel le module est installé doit également afficher une

étiquette faisant référence au module inclus. Cette étiquette extérieure peut utiliser un libellé comme

celui-ci: “ Contient IC:6158A-WPEQ268AXBT“.

Plaque signalétique du produit final:

Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des

IC:6158A-WPEQ268AXBT ".

Wireless Module

Manual Information To the End User:

The OEM integrator has to be aware not to provide information to the end user regarding how to install or

remove this RF module in the user’s manual of the end product which integrates this module.

The end user manual shall include all required regulatory information/warning as show in this manual.

Manuel d'information à l'utilisateur final

L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la

façon d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre

ce module. Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et

avertissements comme indiqué dans ce manue

Must use the device only in host devices that meet the FCC/ISED RF exposure category of mobile, which

means the device is installed and used at distances of at least 20cm from persons.

The end user manual shall include FCC Part 15 /ISED RSS GEN compliance statements related to the

transmitter as show in this manual.

Host manufacturer is responsible for compliance of the host system with module installed with all other

applicable requirements for the system such as Part 15 B, ICES 003.

Host manufacturer is strongly recommended to confirm compliance with FCC/ISED requirements for the

transmitter when the module is installed in the host.

Must have on the host device a label showing Contains FCC ID:RYK-WPEQ268AXBT, Contains IC:6158A-

WPEQ268AXBT

The use condition limitations extend to professional users, then instructions must state that this

information also extends to the host manufacturer’s instruction manual.

If the end product will involve the Multiple simultaneously transmitting condition or different operational

conditions for a stand-alone modular transmitter in a host, host manufacturer have to consult with module

manufacturer for the installation method in end system.

l'hôte doit utiliser l'instrument uniquement dans des dispositifs qui répondent à la fcc / (catégorie

d'exposition rf mobile, ce qui signifie le dispositif est installé et utilisé à une distance d'au moins 20 cm de

personnes.

le manuel de l'utilisateur final doit inclure la partie 15 / (fac rss gen déclarations de conformité relatives à

l'émetteur que de montrer dans ce manuel.

le fabricant est responsable de la conformité de l'hôte, le système d'accueil avec le module installé avec

toutes les autres exigences applicables du système comme la partie 15 b, ices - 003. accueillir le fabricant

Wireless Module

est fortement recommandé de confirmer la conformité avec les exigences de la fcc / (émetteur lorsque le

module est installé dans l'hôte.

le dispositif d'accueil doivent avoir une étiquette indiquant contient FCC ID: RYK-WPEQ268AXBT, contient

IC :6158A-WPEQ268AXBT

Operation shall be limited to indoor use only.

Operation on oil platforms, cars, trains, boats and aircraft shall be prohibited except for on large aircraft

flying above 10,000 ft.

Le fonctionnement doit être limité à une utilisation en intérieur uniquement.

L'exploitation sur les plates-formes pétrolières, les voitures, les trains, les bateaux et les aéronefs est

interdite, sauf pour les gros aéronefs volant au-dessus de 10 000 pieds.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Módulo inalámbrico de Sparklan

Sparklan

Sparklan WPEQ-405AX Manual de usuario

Sparklan

Sparklan WPEB-265AXI B33 Manual de usuario

Sparklan

Sparklan WUBT-239ACN(BT) Manual de usuario

Sparklan

Sparklan WNFB-266AXI Manual de usuario

Manuales populares de Módulo inalámbrico de otras marcas

Laird

Laird RM024 Manual de usuario

Laird

Laird BT830-SA Guía de configuración rápida

Ebyte

Ebyte E49-400T20S Manual de usuario

Fibocom

Fibocom FM101-NA-20 Instrucciones de instalación

Waldmann

Waldmann EnOcean TALK MODUL G2 Manual de usuario

Smartech

Smartech LBT-1.DO4 Manual de usuario

Cooper Wiring Devices

Cooper Wiring Devices ESPIRE RF RFAPM Manual de usuario

Yuga

Yuga CLM920 Manual de usuario

Waldmann

Waldmann TALK Bluetooth Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions UC864-G Manual de instalación

Ebyte

Ebyte E07-900M10S Manual de usuario

Quectel

Quectel SC690A Series Suplemento

Panasonic

Panasonic INDUSTRY PAN9028 Guía de configuración rápida

Ebyte

Ebyte E70-433NW30S Manual de usuario

LongSung Technology

LongSung Technology U9507E Manual de usuario

Wistron NeWeb

Wistron NeWeb DNUR-S2 Manual de usuario

Ebyte

Ebyte E49-400M20S4 Manual de usuario

RF-Star

RF-Star SimpleLink RF-BM-2652P1 CC2652P Manual de usuario
