Sony StorStation AITi90 Manual de usuario

AIT Drive

4-679-249-17(1)

2003 Sony Corporation

AIT-4 TAPE DRIVE

AITi520

AIT-3 Ex TAPE DRIVE

AITi390

AIT-3 TAPE DRIVE

AITi260

AIT-2 TAPE DRIVE

AITi130

AIT-1 TAPE DRIVE

AITi90

User’s Guide

This document contains proprietary

information which is protected by

document may be photocopied,

reproduced or translated to another

language without prior written consent

of Sony.

The information contained in this

document is subject to change without

notice.

SONY MAKES NO WARRANTY

OF ANY KIND WITH REGARD TO

THIS DOCUMENT.

Sony shall not be liable for errors

contained herein, indirect, special,

incidental or consequential damages in

connection with the furnishing,

performance or use of this document.

Your AITi90, AITi130 is assigned a

Model No. ATDNA2 for regulatory

compliance certifications.

Your AITi260 is assigned a Model No.

ATDNA3 for regulatory compliance

certifications.

Your AITi390, AITi520 is assigned a

Model No. ATDNA4 for regulatory

compliance certifications.

The number is indicated on the model

number label on your drive along with

the rated voltage and current.

VORSICHT

Für Kunden in Deutschland

Diese Ausrüstung erfüllt die

Europäischen EMC-Bestimmungen für

die Verwendung in folgender /

folgenden Umgebung(en):

•Wohngegenden

• Gewerbegebiete

•Leichtindustriegebiete

(Diese Ausrüstung erfüllt die

Bestimmungen der Norm EN55022,

Klasse B.)

IMPORTANT SAFEGUARDS

For your protection, please read these

safety instructions completely before

operating the appliance, and keep this

manual for future reference.

Carefully observe all warnings,

precautions and instructions on the

appliance, or the one described in the

operating instructions and adhere to

them.

USE

Power Sources – This unit should be

operated only from the type of power

source indicated on the marking label.

If you are not sure of the type of

electrical power, consult your dealer or

local power company.

For the unit with a three-wire

grounding type ac plug:

If you are unable to insert the plug into

the outlet, contact your electrician to

have a suitable plug installed. Do not

defeat the safety purpose of the

grounding plug.

AC Power cord: (for AC mains

operating unit only)

The AC power cord should have

appropriate safety approvals or

marking for the country in which the

equipment will be used. Consult your

dealer or local power company.

Cleaning – Unplug the unit from the

wall outlet before cleaning or

polishing it. Do not use liquid

cleaners or aerosol cleaners.

Use a cloth lightly dampened with

water for cleaning the exterior of the

unit.

Object and Liquid Entry – Never

push objects of any kind into the unit

through openings as they may touch

dangerous voltage points or short out

parts that could result in a fire or

electric shock. Never spill liquid of

any kind on the unit.

INSTALLATION

Water and Moisture – Do not use

power-line operated units near water -

for example, near a bathtub,

washbowl, kitchen sink, or laundry

tub, in a wet basement, or near a

swimming pool, etc.

Power-Cord Protection – Route the

power cord so that it is not likely to be

walked on or pinched by items placed

upon or against them, paying

particular attention to the plugs,

receptacles, and the point where the

cord exits from the appliance.

Accessories – Do not place the unit on

an unstable cart, stand, tripod, bracket,

or table. The unit may fall, causing

serious injury to a child or an adult,

and serious damage to the unit. Use

only a cart stand tripod, bracket, or

table recommended by the

manufacturer.

Ventilation – The slots and openings

in the cabinet are provided for

necessary ventilation. To ensure

reliable operation of the unit, and to

protect it from overheating, these slots

and openings must never be blocked or

covered.

•Never cover the slots and openings

with a cloth or other materials.

•Never block the slots and openings

by placing the unit on a bed, sofa,

rug or other similar surface.

•Never place the unit in a confined

space, such as a bookcase, or built-

in cabinet, unless proper ventilation

is provided.

SERVICE

Damage Requiring Service – Unplug

the unit from the wall outlet and refer

servicing to qualified service

personnel under the following

conditions:

•When the power cord or plug is

damaged or frayed.

•If liquid has been spilled or objects

have fallen into the unit.

•If the unit has been exposed to rain

or water.

•If the unit has been subject to

excessive shock by being dropped,

or the cabinet has been damaged.

•If the unit does not operate normally

when following the operating

instructions. Adjust only those

controls that are specified in the

operating instructions. Improper

adjustment of other controls may

result in damage and will often

require extensive work by a

qualified technician to restore the

unit to normal operation.

•When the unit exhibits a distinct

change in performance - this

indicates a need for service.

Servicing – Do not attempt to service

the unit yourself as opening or

removing covers may expose you to

dangerous voltage or other hazards.

Refer to all servicing to qualified

service personnel.

Contents

Overview .................................................................................................................. 6

Introduction ..............................................................................................................7

About AIT Drives ............................................................................................ 7

Precautions .....................................................................................................10

Installation ..............................................................................................................12

SCSI Connection/Setting the SCSI ID ...........................................................12

Option Switches (DIP Switch) .......................................................................13

Mounting Holes..............................................................................................17

Reconfiguring from 5.25" Model to 3.5" Model............................................19

Orientation......................................................................................................20

Attaching and Removing the Dust Cover ...............................................................21

Attaching the Dust Cover ............................................................................... 21

Removing the Dust Cover .............................................................................. 23

Operation ................................................................................................................24

Location of 3 LEDs ........................................................................................ 24

Drive Operation..............................................................................................25

Emergency Tape Removal Procedure ............................................................ 28

WORM Function .................................................................................................... 30

Interface Implementation........................................................................................ 32

Supported SCSI Messages .............................................................................32

Supported SCSI Commands........................................................................... 32

Specifications .........................................................................................................33

Product Specifications....................................................................................33

Sony Contacts .........................................................................................................35

• Sony cannot accept liability for data written to cartridges lost as a result of using this product.

• Sony bears no responsibility for any financial damages, lost profits, or claims made by third

parties arising from the use of this product.

Overview

The Sony AITi520, AITi390, AITi260, AITi130 and AITi90 drives are

high capacity data storage devices using Advanced Intelligent Tape (AIT)

technology. The AITi260, AITi130 and AITi90 drives achieve high data

reliability through third-level Error Correction Code (second-level Error

Correction Code for the AITi520 and AITi390).

The Sony AITi520, AITi390, AITi260, AITi130 and AITi90 drives store

data on tape using standard formats called AIT (Advanced Intelligent Tape)

and ALDC formats.

Introduction

About AIT Drives

The AITi520 is an internal AIT drive unit that uses data cartridges

conforming to the AIT-4 format. The AITi390 is an internal AIT drive unit

that uses data cartridges conforming to the AIT-3 Ex format. The AITi260

is an internal AIT drive unit that uses data cartridges conforming to the

AIT-3 format. The AITi130 is an internal AIT drive unit that uses data

cartridges conforming to the AIT-2 format. The AITi90 is an internal AIT

drive unit that uses data cartridges conforming to the AIT-1 format. The

AITi520 supports AIT-4 format. The AITi390 supports AIT-1 (Read only),

AIT-2 (Read only), AIT-3 and AIT-3 Ex formats. The AITi260 supports

AIT-1, AIT-2 and AIT-3 formats. The AITi130 supports AIT-1 and AIT-2

formats. The AITi90 supports only AIT-1 format.

Features

The AIT Drive Unit AITi520 has the following features:

•Supports reading and writing to data cartridges conforming to the AIT-4

format.

•The second-level error correction code guarantees high data reliability

writing to data cartridges conforming to the AIT-4 format.

•Data compression provides 520 gigabytes of storage on SDX4-200C.*1

The native capacity is 200 gigabytes of storage on SDX4-200C.

•Stored data are automatically checked for compression.

• Ultra 160 SCSI LVD/SE interface is fully supported for host computer

access.

*1 This is assuming 2.6 : 1 compression ratio.

The degree of data compression attained while recording data varies according to

system environment and data type.

The AIT Drive Unit AITi390 has the following features:

•Supports reading and writing to data cartridges conforming to the AIT-3

and AIT-3 Ex formats.

•Supports reading from data cartridges conforming to the AIT-1 and

AIT-2 formats.

•The second-level error correction code guarantees high data reliability

writing to data cartridges conforming to the AIT-3 Ex format.

•The third-level error correction code guarantees high data reliability

writing to data cartridges conforming to the AIT-1, AIT-2 and AIT-3

formats.

•Data compression provides 390 gigabytes of storage on SDX3X-150C.*1

The native capacity is 150 gigabytes of storage on SDX3X-150C.

•Stored data are automatically checked for compression.

• Ultra 160 SCSI LVD/SE interface is fully supported for host computer

access.

The AIT Drive Unit AITi260 has the following features:

•Supports reading and writing to data cartridges conforming to the AIT-1,

AIT-2 and AIT-3 formats.

•The third-level error correction code guarantees high data reliability.

•Data compression provides 260 gigabytes of storage on SDX3-100C.*1

The native capacity is 100 gigabytes of storage on SDX3-100C.

•Stored data are automatically checked for compression.

• Ultra 160 SCSI LVD/SE interface is fully supported for host computer

access.

The AIT Drive Unit AITi130 has the following features:

•Supports reading and writing to data cartridges conforming to the AIT-1

and AIT-2 formats.

•The third-level error correction code guarantees high data reliability.

•Data compression provides 130 gigabytes of storage on SDX2-50C.*1

The native capacity is 50 gigabytes of storage on SDX2-50C.

•Stored data are automatically checked for compression.

•Wide Ultra SCSI LVD/SE interface is fully supported for host computer

access.

*1 This is assuming 2.6 : 1 compression ratio.

The degree of data compression attained while recording data varies according to

system environment and data type.

The AIT Drive Unit AITi90 has the following features:

•Supports reading and writing to data cartridges conforming to the AIT-1

format.

•The third-level error correction code guarantees high data reliability.

•Data compression provides 91 gigabytes of storage on SDX1-35C.*1

The native capacity is 35 gigabytes of storage on SDX1-35C.

•Stored data are automatically checked for compression.

•Wide Ultra SCSI LVD/SE interface is fully supported for host computer

access.

*1 This is assuming 2.6 : 1 compression ratio.

The degree of data compression attained while recording data varies according to

system environment and data type.

Precautions

Installation

Avoid placing the drive in a location subject to:

–high humidity

–high temperature

– mechanical shock and vibration

–direct sunlight

*For details, see “Specifications” on page 33.

Operation

• Do not move the drives while they are operating. It may cause

malfunctions.

• Avoid exposing the drives to sudden changes from low to high

temperatures. This may cause condensation to collect inside the drives. If

the ambient temperature should suddenly rise while the drives are turned

on, turn them off and wait at least one hour before turning them back on.

If you attempt to operate the drives immediately after a sudden increase

in temperature, malfunctions may occur.

•Turning off the power to the drives while they are writing to tape may

cause the tape to become unreadable. All previously negotiated

parameters will be lost, whenever power to the drives is cycled.

Transportation

•Keep the original packing materials to facilitate safe transportation of the

drive.

•Always remove the tape/media cartridge before moving the drive. After

removing the drive from the computer, repack the drive into its original

packing.

Backup Application

Make sure to use a backup application that is confirmed to operate with an

ISV.

Otros manuales para StorStation AITi90

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Almacenamiento de Sony

Sony

Sony AIT-SDX800 Instrucciones de instalación

Sony

Sony SDX-550V Manual de usuario

Sony

Sony USM128ED Manual de usuario

Sony

Sony VGN-AW Series Guía

Sony

Sony SDZ-100 Manual de usuario

Sony

Sony PHD-A55 Manual de usuario

Sony

Sony USM4GL Manual de instrucciones de instalación

Sony

Sony StorStation AITi260 Manual de usuario

Sony

Sony SRR1000 Manual de usuario

Sony

Sony HD-B1 Manual de usuario

Sony

Sony SDT-7000 Series Manual de usuario

Sony

Sony HD-PG5 Manual de usuario

Sony

Sony MicroVault USM4GL Manual de usuario

Sony

Sony MS-A16GU2 Manual de usuario

Sony

Sony MSAC-US40 - MemoryStick Flash Memory Card USB 2.0... Manual de usuario

Sony

Sony SF Series Manual de usuario

Sony

Sony VGC-RB10M - Vaio Desktop Computer Manual de usuario

Sony

Sony SDX-D500C Manual

Sony

Sony Memory Card DKA-MC10F Manual de usuario

Sony

Sony MS-HX16G Manual de usuario

Sony

Sony PCV-LX810 - Vaio Slimtop Computer Manual de usuario

Sony

Sony HD-EG5U Manual de usuario

Sony

Sony VAIO PCGA-CDRWX1 Manual de usuario

Sony

Sony Personal Content Station Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
