MEMORY STORAGE UNIT

SR-R1000

INSTALLATION MANUAL

1st Edition

Serial No. 10001 and Higher: SR-R1000 (SY)

Serial No. 50001 and Higher: SR-R1000 (CN)

SR-R1000

!警告

このマニュアルは，サービス専用です。

お客様が，このマニュアルに記載された設置や保守，点検，修理などを行うと感電や火災，

人身事故につながることがあります。

危険をさけるため，サービストレーニングを受けた技術者のみご使用ください。

!WARNING

This manual is intended for qualiﬁed service personnel only.

To reduce the risk of electric shock, ﬁre or injury, do not perform any servicing other than that

contained in the operating instructions unless you are qualiﬁed to do so. Refer all servicing to

qualiﬁed service personnel.

!WARNUNG

Die Anleitung ist nur für qualiﬁziertes Fachpersonal bestimmt.

Alle Wartungsarbeiten dürfen nur von qualiﬁziertem Fachpersonal ausgeführt werden. Um die

Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei

Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung

dazu besitzen.

!AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Aﬁn

de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les

réparations indiquées dans le mode d’emploi à moins d’être qualiﬁé pour en effectuer d’autres.

Pour toute réparation faire appel à une personne compétente uniquement.

For safety, do not connect the connector for peripheral

device wiring that might have excessive voltage to the

following port(s).

: MAINTENANCE connector

: NETWORK 1 connector

: NETWORK 2 connector

Follow the instructions for the above port(s).

For kundene i Norge

Dette utstyret kan kobles til et IT-strømfordelingssystem.

SR-R1000 1 (P)

Attention-when the product is installed in Rack:

1. Prevention against overloading of branch circuit

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

make sure that the rack does not overload the supply

circuit.

2. Providing protective earth

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

conﬁrm that the outlet is provided with a suitable

protective earth connection.

3. Internal air ambient temperature of the rack

When this product is installed in a rack, please make

sure that the internal air ambient temperature of the

rack is within the speciﬁed limit of this product.

4. Prevention against achieving hazardous

condition due to uneven mechanical loading

When this product is installed in a rack, please

make sure that the rack does not achieve hazardous

condition due to uneven mechanical loading.

5. Install the equipment while taking the operating

temperature of the equipment into consideration

For the operating temperature of the equipment, refer

to the speciﬁcations of the Operation Manual.

6. When performing the installation, keep the

following space away from walls in order to

obtain proper exhaust and radiation of heat.

Right, Left: 4 cm (1.6 inches) or more

Rear: 15 cm (6 inches) or more

設置時には，通気やサービス性を考慮して設置スペース

を確保してください。

. ファンの排気部( リアパネル面，右側面後ろ側 )や通

気孔（フロントパネル面，前面下部，前面両端部）を

ふさがない。

. 通気のために，セット周辺に空間をあける。

. 作業エリアを確保するため，セットの左側面および右

側面は 4cm 以上，セット後方は 40cm 以上の空間を

あける。

机上などの平面に設置する場合は，左側面および右側面

は 4cm 以上の空間をそれぞれ確保してください。ただ

し，セット上部はサービス性を考慮し 40cm 以上の空

間を確保することを推奨します。

When installing, the installation space must be secured

in consideration of the ventilation and service operation.

.Do not block the fan exhaust areas (rear panel and

rear part of the right side panel) and vents (front panel,

front lower part, and front right and left ends) with

objects.

.Leave a space around the unit for ventilation.

.Secure working spaces (at least 4 centimeters from

the left panel and right panel and at least 40 centime-

ters from the rear panel of the unit).

When the unit is installed on the desk or the like, leave at

least 4 centimeters of space in the left and right sides.

Leaving 40 centimeters or more of space above the unit

is recommended for service operation.

1 (E)

SR-R1000

Table of Contents

Manual Structure

Purpose of this manual............................................................ 3 (E)

Related manuals...................................................................... 3 (E)

Trademarks.............................................................................. 3 (E)

1. Installation

1-1. Installation Procedure................................................ 1-1 (E)

1-2. Accessories................................................................1-1 (E)

1-3. Operating Environment............................................. 1-2 (E)

1-4. Power Supply ............................................................1-2 (E)

1-4-1. Power Supply Speciﬁcations ...........................1-2 (E)

1-4-2. Recommended Power Cord .............................1-2 (E)

1-5. Installation Space ......................................................1-4 (E)

1-6. Rack Mounting.......................................................... 1-5 (E)

1-7. Connectors and Cables............................................ 1-10 (E)

1-8. Connector Input/Output Signals.............................. 1-11 (E)

1-9. Setting Switch on the Connector Panel................... 1-14 (E)

1-10. Opening/Closing the Control Panel.........................1-14 (E)

1-11. System Setting Method ...........................................1-15 (E)

1-11-1. Setting System Frequency .............................1-15 (E)

1-11-2. Setting Port ....................................................1-16 (E)

1-11-3. Setting Metadata ............................................1-17 (E)

1-11-4. Storing and Reading System Settings in/

from the User Bank........................................1-18 (E)

1-12. Reference System....................................................1-20 (E)

1-13. Settings when Connecting the Unit to an Editing

Device......................................................................1-20 (E)

1-13-1. Setting Timecode ...........................................1-20 (E)

1-13-2. Setting Constant Values for VTR of Editing

Device ............................................................1-20 (E)

1-14. Removing/Installing Plug-in Boards.......................1-21 (E)

1-14-1. Combination of Option Boards......................1-21 (E)

1-14-2. Option Board Installing/Removing

Procedures...................................................... 1-23 (E)

1-14-3. Checking Recognition of SRK-R201/

SRK-R202 by the Unit...................................1-24 (E)

1-14-4. Settings after Installing SRK-R201/

SRK-R202......................................................1-25 (E)

1-15. Ejecting SRMemory (Memory Card) Manually .....1-27 (E)

Appendix A Setting Check Sheet

3 (E)

SR-R1000

Manual Structure

Purpose of this manual

This manual is the installation manual of Memory Storage Unit SR-R1000.

This manual is intended for use by trained system and service engineers,

and provides the information that is required to install (operating environment,

installation space, connection information, initial setting, etc.) and the setting check

sheet.

Related manuals

Besides this Installation Manual, the following manuals are prepared for SR-R1000.

.Operation Manual (PDF) (Supplied with this unit. (CD-ROM))

This manual describes the application and operation of this unit.

.Maintenance Manual (Available on request)

Volume 1: Service Instruction

Volume 2: Parts List, Block Diagrams, and Board Layouts

Volume 3: Schematic Diagrams

These manuals describe the maintenance and service information (service over-

view, error message, detailed parts list, block diagrams, board layouts, schematic

diagrams, etc.) for this unit.

.Protocol Manual of Remote (9-pin) Connector (Available on request)

This manual explains the protocol for controlling this unit via the RS-422A (9-pin

serial remote).

Trademarks

Trademarks and registered trademarks used in this manual are follows.

.Ethernet is a registered trademark of Xerox Corporation.

1-1 (E)

SR-R1000

1-1. Installation Procedure

The following ﬂowchart shows the installation procedure

of the unit.

For details of each step, refer to the relevant section.

Items marked with an asterisk (*) also need the Operation

Manual.

Start

Determination of

installation place

1-3. Operating Environment

1-4. Power Supply

1-5. Installation Space

1-7. Connectors and Cables

1-8. Connector Input/Output Signals

1-9. Setting Switch on the Connector Panel

1-10. Opening/Closing the Control Panel

1-11. System Setting Method

1-12. Reference System

1-13. Settings when Connecting the Unit to an Editing Device

1-6. Rack Mounting

When the unit is transported, it is required to pack the unit into the specified new packing materials.

Do not reuse the packing materials.

If an error message appears on the time data display area, refer to the operation manual.

(For more details, refer to the maintenance manual volume 1.)

* Connection

* Initial setup

* Operation check

End

Unpacking

Rack mounting

Section 1

Installation

1-2. Accessories

.Operation Manual CD-ROM (PDF) (x1)

.Installation Manual (x1)

.Operation Guide (x1)

.SR VIEWER CD-ROM (x1)

1-2 (E) SR-R1000

1-3. Operating Environment

Do not block any air vents in the cabinet and exhaust vents

for fans to reduce temperature rise in the unit.

Furthermore, implement appropriate measures for cooling

air to adequately ﬂow in the unit.

Operating temperature: 5 to 40 degrees-C

Operating humidity: 25 to 90 % (no condensation)

Storage temperature: _20 to 60 degrees-C

Prohibited installation places:

.Places exposed to direct sunlight or intense light

.Places near a heat source

.Dusty places or places subject to constant vibration

.Places in strong magnetic ﬁeld

.Places subject to much electrical noise

.Places where electrostatic noise is likely to be generated

.Places where speciﬁed installation space cannot be

provided (Refer to Section 1-5 “Installation Space.”)

.Sealed places

Horizontal installation condition:

Allowable gradient of 30 degrees or less

Do not tilt the front or rear of the unit more than 30

degrees.

If the unit is used at a slant, secure it to prevent it from

slipping down.

1-4. Power Supply

1-4-1. Power Supply Speciﬁcations

A switching regulator is used in the power supply unit of

the unit.

Be sure to use the unit within the following power voltage

range.

Power voltage: 100 VAC ±10 %

Power frequency: 50 or 60 Hz

Power consumption: 480 W max. (including options)

Inrush current: 25 A at 100 VAC

The AC power supply requires capacity including inrush

current.

If the AC power capacity is insufﬁcient, the circuit breaker

of the AC power supply on the supply side may be turned

on, which may cause malfunction of the unit.

1-4-2. Recommended Power Cord

This unit does not come with a power cord.

To get a power cord, please contact your local Sony Sales

Ofﬁce/Service Center.

.Use the approved Power Cord (3-core mains lead)/Appli-

ance Connector/Plug with earthing-contacts that con-

forms to the safety regulations of each country if appli-

cable.

.Use the Power Cord (3-core mains lead)/Appliance

Connector/Plug conforming to the proper ratings (Volt-

age, Ampere).

If you have questions on the use of the above Power Cord/

Appliance Connector/Plug, please contact your local Sony

Sales Ofﬁce/Service Center.

.Never use an injured power cord.

For customers in the U.S.A. and Canada:

1Power cord 125 V 10 A (2.4 m): !1-551-812-31

2Plug holder: 3-613-640-01

AC inlet

For customers in the United Kingdom

1Power cord 250 V 10 A (2.4 m): !1-777-823-12

2Plug holder: 3-613-640-01

AC inlet

Otros manuales para SRR1000

Tabla de contenidos

Otros manuales de Almacenamiento de Sony

Sony

Sony SDX-900V Series Manual de usuario

Sony

Sony SDT-9000 Series Manual de usuario

Sony

Sony csm-20s Manual de usuario

Sony

Sony MicroVault USM1GJ Manual de usuario

Sony

Sony CSMA-EX200S Manual de usuario

Sony

Sony AITi200STS Manual de usuario

Sony

Sony MSG-M64A Manual de usuario

Sony

Sony VGN-BX660P Guía

Sony

Sony Personal Content Station LLS-201 Manual de usuario

Sony

Sony CDL1100 Manual de usuario

Sony

Sony PHD-A55 Manual de usuario

Sony

Sony HD-E Series Manual de usuario

Sony

Sony SR16A4 Manual de usuario

Sony

Sony SRR1000 Manual de usuario

Sony

Sony HDPS-M10 - Data Storage Wallet Manual de usuario

Sony

Sony SF Series Manual de usuario

Sony

Sony MicroVault USM1GJ Manual de usuario

Sony

Sony SDX-420C Manual de usuario

Sony

Sony AIBO Explorer Manual de usuario

Sony

Sony TSL-S11000 Manual de usuario

Sony

Sony MSX-M4GS Manual de usuario

Sony

Sony MS-A16GU2 Manual de usuario

Sony

Sony SRMASTER SR-R4 Manual de usuario

Sony

Sony StorStation LIB-D81 Manual del operador

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
