4-247-461-11(1)

Micro Hi-Fi

Component

System

Operating Instructions

CMT-GP7

2GB

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

To prevent fire, do not cover the ventilation of the

apparatus with news papers, table-cloths, curtains, etc.

And don’t place lighted candles on the apparatus.

To prevent fire or shock hazard, do not place objects

filled with liquids, such as vases, on the apparatus.

This appliance is

classified as a CLASS 1

LASER product. This

label is located on the

rear exterior.

Don’t throw away the battery with

general house waste, dispose of it

correctly as chemical waste.

WARNING

Do not install the appliance in a confined space,

such as a bookcase or built-in cabinet.

3GB

How to use this manual...........................4

Playable discs..........................................4

Getting Started

Hooking up the system............................6

Setting the clock......................................7

CD/MP3 – Play

Loading a disc.........................................8

Playing a disc..........................................8

— Normal Play/Shuffle Play

Playing repeatedly.................................10

— Repeat Play

Creating your own program..................10

— Program Play

Tuner

Presetting radio stations........................12

Listening to the radio............................13

— Preset Tuning

— Manual Tuning

Using the Radio Data System (RDS)....14

Tape – Play

Loading a tape.......................................15

Playing a tape........................................15

Tape – Recording

Recording your favorite CD tracks on a

tape..................................................16

— CD-TAPE Synchro Recording

Recording on a tape manually...............17

— Manual Recording

Sound Adjustment

Adjusting the sound ..............................17

Timer

Falling asleep to music..........................18

— Sleep Timer

Waking up to music ..............................18

— Daily Timer

Timer recording radio programs...........19

Display

Turning off the display......................... 20

— Power Saving Mode

Viewing information about the disc in the

display ............................................ 21

Optional Components

Hooking up optional components......... 22

Troubleshooting

Problems and remedies......................... 24

Messages............................................... 26

Additional Information

Precautions............................................ 27

Specifications........................................ 28

List of button locations and reference

pages............................................... 30

Table of Contents

4GB

• Thismanualmainlyexplainsoperationsusing

the remote, but the same operations can also

be performed using the buttons on the system

having the same or similar names.

• The following symbols are used in this

manual.

You can play back the following discs on this

system. Other discs cannot be played back.

List of playable discs

Discs that this system cannot

play

•CD-ROMs

• CD-Rs/CD-RWs otherthan those recorded in

the following formats:

– music CD format

– MP3 format that conforms to ISO9660*1

Level 1/Level 2, Joliet or Multi Session*2

• A disc that has a non-standard shape (e.g.,

card, heart).

• A disc with paper or stickers on it.

• A disc that has the adhesive, cellophane tape,

or a sticker still left on it.

*1 ISO 9660 Format

The most common international standard for the

logical format of files and folders on a CD-ROM.

There are several specification levels. In Level 1,

file names must be in the 8.3 format (no more than

eight characters in the name, no more than three

characters in the extension “.MP3”) and in capital

letters. Folder names can be no longer than eight

characters. There can be no more than eight nested

folder levels. Level 2 specifications allow file

names and folder names up to 31 characters long.

Each folder can have up to 8 trees.

For Joliet in the expansion format (file and folder

names can have up to 64 characters) make sure of

the contents of the writing software, etc.

*2 Multi Session

This is a recording method that enables adding of

data using the Track-At-Once method.

Conventional CDs begin at a CD control area called

the Lead-in and end at an area called Lead-out. A

Multi Session CD is a CD having multiple sessions,

with each segment from Lead-in to Lead-out

regarded as a single session.

CD-Extra: This format records audio (audio CD

data) on the tracks in session 1 and data on the tracks

in session 2.

Mixed CD: This format records data on the first

track and audio (audio CD data) on the second and

subsequent tracks of a session.

How to use this manual

Symbol Meaning

Functions that can be used with

audio CDs

Functions that can be used with

MP3

Playable discs

Format of

discs Disc logo Contents

Audio CDs Audio

CD-R/CD-RW

(audio data) Audio

CD-R/CD-RW

(MP3 files) Audio

5GB

Notes on CD-R and CD-RW

• This system can play CD-R/CD-RW discs

edited by the user. However, note that

playback of some discs may not be possible

depending on the recording device used for

recording or the disc condition.

• Discs recorded on CD-R/CD-RW drives may

not be played back because of scratches, dirt,

recording condition or the driver’s

characteristics.

• CD-R and CD-RW discs that have not been

finalized (processing to allow play by a

normal CD player) cannot be played.

• CD-R and CD-RW discs recorded in multi-

session that have not ended by “closing the

session” are not supported.

• The system may be unable to play MP3

format files that do not have the extender

“.MP3”.

• Attempting to play non-MP3 format files that

have the extender “.MP3” may result in noise

or malfunction.

• With formats other than ISO 9660 level 1 and

2, folder names or file names may not be

displayed correctly.

• The following discs take a longer time to start

playback.

– a disc recorded with complicated tree

structure.

– a disc recorded in Multi Session.

– a disc to which data can be added (non-

finalized disc).

Music discs encoded with

technologies

This product is designed to playback discs that

conform to the Compact Disc (CD) standard.

Recently, various music discs encoded with

by some record companies. Please be aware that

among those discs, there are some that do not

conform to the CD standard and may not be

playable by this product.

Cautions when playing a disc

that is recorded in Multi

Session

• If the disc begins with a CD-DA session, it is

recognized as a CD-DA (audio) disc, and

MP3 sessions are played back without sound.

• If the disc begins with an MP3 session, it is

recognized as an MP3 disc, and CD-DA

sessions are played back without sound.

• The playback range of an MP3 disc is

determined by the tree structure of files

produced by analyzing of the disc.

• A disc with a mixed CD format will be

recognized as a CD-DA (audio) disc.

6GB

Perform the following procedures 1to 3to hook up your system using the supplied cords and

accessories.

1Connect the speakers.

Connect the right and left speaker cords to

the SPEAKER terminals as shown below.

2Connect the FM and AM antennas.

Set up the AM loop antenna, then connect

it.

Getting Started

Hooking up the system

AM loop antenna

Right speaker Left speaker

FM lead antenna

Black (#)

Gray (3)

Insert this portion

FM75Ω

Extend the FM lead antenna horizontally

AM loop antenna

Getting Started

7GB

Note

To prevent noise pickup, keep the antennas away from

the system and other components.

3Connect the power cord to a wall

outlet.

If the plug does not fit the wall socket,

detach the supplied plug adaptor (only for

models equipped with an adaptor).

To turn on the system, press ?/1.

Inserting two R6 (size AA)

batteries into the remote

Note

If you do not use the remote for a long period of time,

remove the batteries to avoid possible damage from

battery leakage and corrosion.

Tip

When the remote no longer operates the system,

replace both batteries with new ones.

Use buttons on the remote for the operation.

1Press ?/1 to turn on the system.

2Press CLOCK/TIMER SET.

3Press ./> repeatedly to set the

hour.

4Press ENTER.

5Press ./> repeatedly to set the

minute.

6Press ENTER.

The clock starts working.

To adjust the clock

1Press CLOCK/TIMER SET.

2Press ./> until “CLOCK” appears,

then press ENTER.

3Do the same procedures as step 3 to 6

above.

Note

The clock is not displayed in Power Saving Mode.

Setting the clock

8GB

Use buttons on the unit for the operation.

1Press Z.

2Place a disc with the label side up on

the disc tray.

3Press Zagain to close the disc tray.

Notes

• Do not use a disc with tape, seals or paste on it as this

may cause malfunction.

• Do not forcibly press the disc tray closed with your

finger, as this may cause malfunction.

You can play audio CDs and discs with MP3

audio tracks.

1Press FUNCTION on the remote

repeatedly to switch the function to CD.

2Press PLAY MODE/TUNING MODE on

the unit in stop mode repeatedly until

the mode you want appears.

3Press Non the remote (or CD NX on

the unit).

CD/MP3 – Play

Loading a disc

When you

play an 8 cm

disc, place it

on the inner

circle of the

tray.

Playing a disc

— Normal Play/Shuffle Play

Select To play

No display

(Normal Play) The tracks on the disc in

original order.

ALBM

(Normal Play) All MP3 audio tracks in the

album on the disc in original

order.

When playing a non-MP3

disc, Album Play performs

the same operation as

Normal Play.

SHUF

(Shuffle Play) All tracks on the disc in

random order.

ALBM SHUF

(Shuffle Play) All MP3 audio tracks in the

album on the disc in random

order.

When playing a non-MP3

disc, Album Shuffle Play

performs the same operation

as Shuffle Play.

PGM

(Program Play) The tracks on the disc in the

order you want them to be

played (see “Creating your

own program” on page 10).

Track number Playing time

CD/MP3 – Play

9GB

Other operations

Playing a track by entering the

track number

You can also select the track you want using the

remote during Normal Play. Press the numeric

button(s), then press ENTER. Playback

automatically starts.

Notes

• You cannot change the play mode during playback.

• Some time may be needed to start playback of discs

recorded in complex configurations such as many

layers.

• When the disc is inserted, the player reads all the

audio tracks on that disc. If there are many albums

or non-MP3 audio tracks on the disc, it may take a

long time for play to begin or for the next MP3 audio

track to start play.

• Do not save unnecessary albums or audio tracks

other than MP3 ones in the disc to be used for MP3

listening. We recommend that you do not save other

types of audio tracks or unnecessary albums on a disc

that has MP3 audio tracks.

• An album that does not include an MP3 audio track

is skipped.

• Maximum album number: 150 (including root album

and empty albums)

• The maximum number of MP3 audio tracks and

albums that can be contained on a single disc is 300.

• Playback is possible up to 8 levels.

• MP3 audio tracks are played back in the order that

they are recorded on the disc.

• Depending on the encoding/writing software,

recording device, or the recording media used at the

time an MP3 audio track is recorded, you may

encounter such problems as disabled playback,

sound interruptions and noise.

• When playing back an MP3 audio track, the playback

elapsed time indication may differ from the actual

time in the following cases.

– When you play back a VBR (variable bit rate)

MP3 audio track

– When you perform Fast Forward or Rewind

(Manual Search)

Tip

When disc access takes a long time, set “CD POWER”

and “ON” by the CD power manage function

(page 12).

To Do this

Stop play Press x.

Pause Press Xon the remote (or CD

NX on the unit). Press again to

resume play.

Select a track Press ./> repeatedly.

Select an album

of MP3 Press ALBUM +/– on the remote

repeatedly after step 2.

Find a point in a

track Keep pressing m/M during

playback and release it at the

desired point.

Remove a disc Press Zon the unit.

10GB

You can play all the tracks or a single track on a

disc repeatedly.

Press REPEAT/FM MODE on the unit

repeatedly during playback until

“REPEAT” or “REPEAT 1” appears.

REPEAT: For all the tracks on the disc up to five

times (or endlessly for MP3 tracks when

“SHUF” is displayed).

REPEAT 1: For a single track only.

To cancel Repeat Play

Press REPEAT/FM MODE on the unit

repeatedly until both “REPEAT” and “REPEAT

1” disappear.

You can make a program of up to 25 steps.

You can synchro record the programed tracks

onto a cassette tape (page 16).

Use buttons on the remote for the operation.

1Press FUNCTION repeatedly to switch

the function to CD.

2Press PLAY MODE/TUNING MODE on

the unit in stop mode repeatedly until

“PGM” appears.

3Press ./> repeatedly until the

desired track number appears.

When programing an MP3, press ALBUM

+/– repeatedly to select the album, then

press ./> repeatedly until the

desired track number appears.

4Press ENTER (or PLAY MODE/TUNING

MODE on the unit).

The track is programed.

The program step number appears,

followed by the last programed track

number.

5To program additional tracks, repeat

steps 3 and 4.

6Press N(or CD NX on the unit).

Program Play starts.

Playing repeatedly

— Repeat Play

Creating your own

program

— Program Play

Selected track number Total playing time

Tabla de contenidos

Otros manuales de Sistema estéreo de Sony

Sony

Sony SRS-XB2 Manual de usuario

Sony

Sony HCD-MG510AV Manual de usuario

Sony

Sony MHC-GRX990 Manual de usuario

Sony

Sony SRS-BTS50 Manual de usuario

Sony

Sony LBT-LCD77Di - Compact Hi-fi Stereo System Manual de usuario

Sony

Sony CX-LDB10 Manual de usuario

Sony

Sony MHC-EC50 Marketing Manual de usuario

Sony

Sony CMTBX1 - CMT BX1 Micro System Manual de usuario

Sony

Sony DHC-MD313 - System Rack Manual de usuario

Sony

Sony HCD-DX50 Manual de usuario

Sony

Sony SRS-BTS50 Manual de lista de piezas

Sony

Sony MHC-LX10000 - High Power Mini Hi-fi System Manual de usuario

Sony

Sony HCD-EC68 Manual de usuario

Sony

Sony CMT-NEZ30 Manual de usuario

Sony

Sony MHC-M60D Manual de usuario

Sony

Sony MHC-GN100D Manual de usuario

Sony

Sony HCD-GNX80 Manual de usuario

Sony

Sony HCD-HP7 - Hi Fi Components Manual de usuario

Sony

Sony FST-ZUX9 - Mini Hi-fi Component System Manual de usuario

Sony

Sony HCD-GX45 - System Components Manual de usuario

Sony

Sony PMC-107L Manual de usuario

Sony

Sony MHC-WX7AV Manual de usuario

Sony

Sony HCD-M500AV Manual de usuario

Sony

Sony SRS-X77 Manual de usuario

Manuales populares de Sistema estéreo de otras marcas

LG CM3330B Manual de usuario

Cetacea Sound

Cetacea Sound CVS-II Manual de usuario

Aiwa

Aiwa XR-H66MD Manual de usuario

Denon

Denon UCD-250 Manual de usuario

Sanyo

Sanyo DC-MX41i Manual de usuario

Sharp

Sharp CD-ES600V Manual de usuario

Exibel

Exibel BDX600-UK Manual de usuario

Sanyo

Sanyo DC-F320 Manual de usuario

Philips

Philips FWM583X Manual de usuario

Sharp

Sharp CD-C462 Manual de usuario

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manual de usuario

Aiwa

Aiwa XR-EM70 Manual de usuario

Cyrus

Cyrus Lyric Manual de usuario

Philips

Philips MCM159/98 Manual de usuario

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manual de usuario

RCA

RCA RS3965SB Manual de usuario

Sharp

Sharp XL-UH240 Manual de usuario

Philips

Philips FW 690 Manual de usuario
