SERVICE MANUAL

1/3” SONY DSP COLOR CCD CAMERA

O.S.D. (ON SCREEN DISPLAY) SERIES

V.22_S_R

The serial number of this product may be found

on the bottom of the unit.

You should note the serial number of this unit in

the space provided and retain this instruction as a

permanent record of your purchase to aid

identification in the event of theft.

Model No.

SerialNo.

▲Before attempting to connect this product, please read and keep this

manual for future use.

Safety Warning

1. Do not open the cover, it may cause electric shock.

Ask a qualified service person for maintenance when you encounter

any problems.

2. Installed the camera away from TV, radio transmitter, magnet, electric

motor, transformer, audio speakers because the magnetic fields

generate from above devices will distort the video image.

3. Place this camera on a solid base. Installed the camera away from

stoves, or other heat generating devices as the high temperature could

cause deformation, discoloration or other damages of the camera.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK), NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is interned to alert the user to the

presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

Install the camera at where the temperature range will stay between 0℃

to 50℃(32℉to 122℉)

4. Do not expose and operate the camera in the rain and humid areas.

5. Only use soft dry cloth to clean the camera. Also use lens tissue or

cotton tipped applicator and ethanol to clean CCD sensor and camera

lens.

6. When the camera is not in use, put the cover cap on the lens mount.

Please do not touch the surface of CCD by bare hand.

Introduction

This Full Function series CCD cameras introduce a new level of high

picture quality through the digital signal processing LSI’s technology for

advanced video surveillance. It provides most reliable and accurate color

picture in security industries.

Main Features

z540TV Lines Ultra High Resolution.

zHigh Sensitivity: SONY 1/3” Super HAD CCD image sensor.

zO.S.D. (On Screen Display): Controlled by selecting menu displayed

on the monitor screen.

zD.N.R. (Digital Noise Reduction).

zDay & Night Mode: Automatically switch.

zPowerful Functions: DC/Video drive lens, B.L.C., Flickerless, White

Balance control, Mirror, Motion Detection, Sens-Up, Sharpness,

Privacy, Camera ID.

zBuilt-in anti-aliasing and IR-cut optical filter.

Installation Instructions

(1) Remove the cap from the lens mount.

(2) Select the C mount lens (with mount ring) or CS mount lens.

(3) Screw and fasten the lens into the lens mount.

(4) Connect the video output wire between monitor and camera through

75ohm type coaxial cable.

(5) Connect the power cord input.

(6) When monitor shows the picture, please adjust the focus and iris of the

Lens to obtain the best image according to the following procedures:

zChoose the objects at a distance about 5 ~ 10 meter away.

zLoosen the mount lens fixing screw (use L wrench), if necessary.

zTurn the lens and the mount together until image is clear.

zScrew the mount to camera.

(7) Fix camera to the bracket, if necessary.

Rear Panel Switches (DC12V, optional AC type)

AC90

260V

24V

DC12V/AC24V

SET UP MENU

LENS * Manual * DC/VIDEO

SHUTTER & SPEED * ESC * MANUAL * FLK

WHITE BALANCE * ATW * AWC * MANUAL

* OFF * LOW * MIDDLE

B.L.C. (BACK LIGHT

COMPENSATION) * HIGH

* OFF * LOW * MIDDLE

AGC (AUTO GAIN

CONTROL) * HIGH

* OFF * LOW * MIDDLE

D.N.R. (DIGITAL

NOISE REDUCTION) * HIGH

SENS-UP (LOW LUX) * OFF * AUTO

* CAMERA ID * COLOR

* SYNC * MOTION DETECTION

* PRIVACY * MIRROR

* SHARPNESS * RESET

SPECIAL

* RETURN

EXIT

MENU On Screen

IRIS Level Control

DC Drive Video Drive

Pin 1 Drive - Volt +

Pin 2 Drive + N.C

Pin 3 Damp + IRIS

Pin 4 Damp - GND

SPECIFICATIONS

MODEL XC229S (ULTRA H.R.)

PICK-UP DEVICE Sony 1/3" IT Super HAD High Resolution CCD Image Sensor

SIGNAL PROCESSOR Digital Signal Processor (D.S.P.)

SYNC. SYSTEM Internal / Line Lock (L.L.)

RESOLUTION 540 TV Lines

MIN. ILLUMINATION 0.1Lux / F1.2, 0.001Lux (Sens-Up)

S/N RATIO More Than 50 dB

POWER SUPPLY DC12V; AC24V; AC90~260V;

DC12V/AC24V Dual Power

GAMMA CORRECTION 0.45

CONTROL OSD

WHITE BALANCE ATW (1,800° K~10,500° K)

LENS MOUNT C / CS Mount

AUTO IRIS CONTROL Video Drive lens & DC Drive lens both supported

BASIC FUNCTION

Lens Selection (DC / VIDEO / Manual)

Shutter Selection (ESC / Manual / FLK)

ATW / AWC / Manual Selection

BLC (Off / Low / Middle / High) Selection

AGC (Off / Low / Middle / High) Selection

DNR (Off / Low / Middle / High) Selection

Sens-Up (Off /AUTO: 2X ~ 128X) Selection

ADDED FUNCTION

Camera ID ON / OFF

Motion Detection ON / OFF (4 Zone, Position / Size / Sensitivity)

Privacy Zone ON / OFF (4 Zone, Position / Size / Tone)

Mirror ON / OFF

Sharpness ON / OFF

Reset Function

DAY & NIGHT (Electronic Conversion)

Watch Dog

VIDEO OUTPUT 1 Vp-p Composite Video / 75 ohm Load

POWER

CONSUMPTION 3.5W (MAX.)

OPERATING TEMP. -10°C to 50°C (14°F to 122°F)
