PTZDOME CAMERA

OPERATIONMANUAL

Pleaseread

this rnanualthoroughlyprior to installationandoperation

Precautions

l. Please read this manual thoroughly prior to installation and operation. Store this manual

properly for future reference. Consult your speed dome camera dealer if you have

uncertainties or questions.

2. Make sure to use correct power supply indicated in the specifications. Wrong power supply

may cause improper performance, damage of the product, or fire. It is recommended that you

usethe power supply that your speeddome dealer may provide.

3. The High-SpeedDome Cameracontainsprecisionoptical andelectrical instruments.To avoid

possible damage caused by striking or shocking, please handle the unit carefully during

delivery, storage and installation.

4. In the caseof any unusual performance, unplug the unit and contact your dealer immediately

for help. Do not disassembleor remove any internal parts of the unit without professional help.

5. To enswe optimal performance, make sure there is enough distance between video cable and

RM85 wires from theunit andany local high-voltage equipmentor cables.

6. Please do not install and use the unit in an environment with temperature or humidity that

o<ceedstheresfictive limits listed in the specifications.

7. To avoid damageto camera's CCD, do not aim the camera at the sunor very bright object and

do not aim at bright object for a long time evenwhen power is off.

8. Do not use any strong chemical liquids when cleaning. If necessary,useneutral detergent and

water to clean the housing and lower bubble, and gently dry them offwith soft cotton fabric.

9. Always install the unit in a place with enough holding force to avoid dropping the unit. The

required minimum holding force is five times of the total weight of the unit and the support.

10. Always usespecialoptical lenspaperor fabric to cleanlens.

I I' Wear cotton gloves when handling dome bubble during installation or disassernbleto avoid

bubble surface being scratched.

1.Product

Introduction

ThePTZ dome

camera

systemis CCTV front-end

equipmentwith high pricevalue.The

product

hasthefollowing mainfeatures.

. Supporb multiple

protocols.

. Supporb 26x

opticalzoom,l0x digihl zoom,

day/nightwithremovablelR

cut-filter, motion{etecting Sony CCDcamera

. Auto focus and auto iris lens

. OSDmenu

. 0 - 355"

panrotation, 0- 90"tilt range

. 12"/sec

pan

speed,12"/sec

tilt speed.

. Powersource: AC24V

. Gommunicationuses RS485dataport

. lDaddress upto 54

. lP66standardfor all weather proof environmental protection

. 9'ABS outdoor

housing

with heater/blower.

1.1 Specifications

of DomeDrive andHousing

Model ASL309 ASL609

Product

Name OutdoorPTZ

DomeCamera lndoorPTZDomecamera

Built-in

Menu OSDin English

Manual

Languages English

Damera

Supports CNB

Pan

movement 0o

- 355ocontinuous

nft movement 0"

--90"

Pan

speed 12"/sEc

Iilt speed 12"/SEC

lommunication RS485interface

Daddrcss 1- 64addresses

trotocols PelcoD

3audrate 2400

towersupply AC24V/500mA

(no Heater)

{eaterlblower

tower AC24Vt3A

P RATING lP66 Not rated

)perating Temp €0"C (-22"F

)to +60"

C(140"F) 0"C

(32"F)

to +40"C

(104"F)

)imensions D:222mm(9")

H:350mm

(14") D:222mm(9"1;

H:280mm(ll")

,Veight 3.1ks

(6.8lb) 2.ekg

(6.alb)

|-2 CameraSpecifications

SPECIFICATIONS

OFCAiIERAMODULES*

Sub-ilodel c26toDN

lmage

Sensor 7r" Sony Super HAI) GGD

TotalPirels 81{(H}x508(v)

HorizontalRes. llorc than 480TVL

ilin. lllum. (color) 1.0lux

ilin lllum {b/w) 0.0lur (lRON)

Lens F=i.6

-3.78

(ts3.Smmto

91mm

26r Optical.10xdiqital)

Resolution .l80TVL

S/N Ratio >48

Electroshutter auto/manual

1/51F1/10,000s

FocusGontrol auto/manual

lris Control auto/manual

osD English

Day/Night Yes,wilfr removablelR

cut filter

Motion detection Yes(need

to set up in camera

menu)

Scanllode 2:1interlacedscan

Sync. lntemal/extemal (line lock):

auto detect

Power

consumption Mar.4.2W

Dimensions

{mml 50.5161.fu92.3mm

Weiqht Approx 340q

* Detail

dataareavailableupon request

2. Installation

2.I Accessories

Checking

Prior to installation. please make sure all accessories are available. Contact your producl

dealer immediately if any accessoriesare missing or damaged.

Item 309 609

IScrew for cameramountinq I (if camera is not included; suitable for most

commonly used zoom cameras)

2Cotton Gloves I pair

JUser'smanualfor camera I (if cameraisprovided)

4User's manualfor pan/tilt

For theconvenience

of RMA service.

please

storeall original packing materials

properly.

2.2

Dipswitch

Setup

Before installation, correctly setup dome address.

protocol, andbaud rate. Dome address,

protocol and baud rate can be set up through adjusting dipswitches on the dome drive.

2.2.1-

Dome

Address

Setup

Dipswitches I to 6 are for dome address setting. Dome addresscan be set to any number

from 0 to 64. Refer to the following chart in Appendix I for corresponding addressand dipswitch

positions.

Default is l.

2-2.2.

ProtocolandBaudRateSetup

Dipswitches 7 to l0 are for protocol setting; I I and 12are for baud rate. Refer to the

following two tables

for thepositioning of dipswitchesandthe corresponding

protocolsandbaud

rate. Default protocol andbaudratearePelcoD. 2400.Becausethe camera

provided supports

Pelco D (2400) protocol only, pleasekeep the default setting for the protocol and baud rate.

Dipswitch

Positions Baudrate Dipswitch

Positions Baudrate

H1200 H4800

E2400 E9600

NO. Communication

Protocol Communication

Protocol

RecommendedBaud

Rate

78910

IPELCO-D 2400

2.3Wire Connections

Connectowo24VAC power wires (labeledbrown) to your power supply andRS485+ (Red)

andRM85{Black) wires to your control device.Connectcoaxial cableto video oulput. If usinga

bracket, wire connection can be carried out after mounting the unit to the bracket.

Notc: Make sure that the power supply is 24VAC. Pay special attention to correct

connection of power supply wires. Incorrect connection will rcsult in permanent damege of

the unit and may ceusefirc, Any damage causedby imprcper wirc connection is not under

the manufacturrr's warranQr coverage.

2.4InstallationProcedures

2.4.1 CameraMount

Prior to mount a zoom camera to the uniq pleasebe surethat the camera has to support

l.24VAC power input.

2. RS485 control with PelcoD protocol.

Mount the camera to PTZ's camera bracket and make sure that the camera towards the

arrow direction shown on the sticker on the bracket. The camera shall be mounted roughly in the

middle of the bracket. Use the screw provided to tight the camera-Then connect the RS485+ (red)

and RS485- (black), 24VAC power supply wires (two brown wires) and video cable to

corresponding terminals on the back of camera-

2.4

.2 Camera

Configuration

After mount the camer4 camera parameters may need to be configwed correct$ for

proper system performance. To configure the camer4 refer to the camera manual provided for

precise description of the procedures. The following stepsarerecommended.

l. Make surethat the power supply,aswell asall video and control wires, are connected

correctly.Lens cover must beremoved.

2. Connect the unit's RS485 to the control device (keyboard or a DVR). and connect the

video to amonitor.

3. Turn power on.Video imageshallnow appearon thescreenof themonitor.

Note: If no image shows, turn ofr thc unit immediately and check wire connections.

4. Pushthe menu button at the back of the camerato enter camera OSD menu.

5. Follow camera's

manualto changecamera

parameters.

The following pararneters

must

be configured correctly in order to control the camerawith your control device.

. CameralD (default l)

. Protocol (defaultP/D. i.e.,PelcoD)

. Auto focus mode (defaultAUTO)

Depending on the contnol device and the application, other camera parameters (e.g.,

motion detection mode) may also need to be configured. Refer to the manual of yow control

device aswell asthe manual for your camera for details.

6. Try to control the camera through the control device. Repeat step4 if necessary.

2.4.3Mount/Dismount

LowerDome

Beforemounting

thelowerdome,makesurethat

' CameraID, protocol,

andbaudrate

arecorrectly

setupwith dipswitches.

. Camera

lens

coverisremoved.

. Cameraisconfigured

properly.

To keepfingerprintsandscratchesfrom distortingthe lower dome,wearthe provided

gloves

whenhandling

thelowerdome.Tomountthelowerdome,carefullylinethescrew

holeson

theback

boxupwith thescrewsonthelowerdomering andtightenthescrews

(referto thefigure

below).

Do notremove

theplastic

wraponthelowerdome

until all stepsaredone.

Dothereverse

for dismounting.

2.4.4

Mount

toaSupport

Send

wiresthrough

thesupport

andtightenthemountingscrewson thesupport,or follow

the manualof the support.If using a supportprovidedby us, refer to the following chart for

supportmounting.

2.4.5 Install ttre Entire Unit

Notc: Since thc horizontel rotation range of the YIZ umit is not 360", please identify and

avoid the blind angle position before insbll tfre unit. For outdoor model, the blind

angle is at the support (bracket) position. For indoor model, the blind angle position is

shown on the stickeron the upper dome housing.

Always install the unit in a place with enough holding force to support the weight of the

unit The required minimum holding force is five times the total weight of the unit and the support.

Due to the fact that installation of an entire unit is subject to local administrative regulations, we

*:lnrlit

can not provide more detailed instructions. Make sure to follow all relevant larrs and goverffnent

regulations when installing the unit. Refer to the following chars for installation dimensions (units

arein millimeters).

br:lr:tr:t ar.*r::aj*g {:rte

CeilingInstall

BracketInstall

r-fer tu right

CeilingRecessInstall

3.Operation

The PTZ camera system can be controlled via keyboard, matrix, or DVR (digital video

recorder). In order to operale thePTZ unit, control device and PTZ must have sameprotocol and

baud rate. For most of control devices. PTZcutbe controlled asfollowing.

l. To move PTZ vertically or horizontally, use

joystick, arrow keys, or mouse to click arrow

buttons.

Notc: Since the horizontal rotation range of the WZ unit is not 360", do not keep

trying to move in the same direction when horizontal limit is reached.

2. To zoom in/out, tum joystick clockwise/counterclockwise or click the zoom*/zoom-

button.

" 3- Manual focus, iris control and other operations are also available, depending on camera

pararneter configuration. Check cameramanual for details.

Pleasealso refer to the manual ofcontrol device for any control issue.

Tabla de contenidos

Otros manuales de Cámara de seguridad de Sony

Sony

Sony XCD-SX910CR/X710CR Manual de usuario

Sony

Sony CD-7226 Manual de usuario

Sony

Sony Ipela SNC-DH210T Manual de usuario

Sony

Sony SNC-CX600W Manual de usuario

Sony

Sony EXWAVEPRO SNC-CM120 Manual de usuario

Sony

Sony IPELA SNC-CH110 Manual de usuario

Sony

Sony SNCEM602R Manual de usuario

Sony

Sony SNC-VB600B Manual de usuario

Sony

Sony Ipela SNC-ZM551 Manual de usuario

Sony

Sony Ipela SNC-WR600 Manual de usuario

Sony

Sony O.S.D. WDR Series Manual de usuario

Sony

Sony Ipela SNC-DH210 Manual de usuario

Sony

Sony SNC-DH110 Manual de usuario

Sony

Sony EVI-H100S Manual de usuario

Sony

Sony SNC-RZ25N - Network Camera Manual de usuario

Sony

Sony SuperExwave SSC-E453P Manual de instalación y operación

Sony

Sony SNCEM602R Manual de usuario

Sony

Sony BRC SERIES Manual de lista de piezas

Sony

Sony SNCEM600 Manual de usuario

Sony

Sony IPELA SNC-CH210 Manual de usuario

Sony

Sony IPELA SNC-CH140 Manual de usuario

Sony

Sony Super HAD CCD SSC-DC314 Manual de usuario

Sony

Sony FCB-EX45MC Manual de usuario

Sony

Sony DFW-SX900 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
