Quick Start Guide

Follow the procedures in steps 1 through 6 to make a print.

For details, see the Operating Instructions.

1 Check the contents of the package.

Printer (1) Paper tray (1) Video connecting cable

(1)

CD-ROM(1)

• Sony DPP-EX50 Printer Driver Software for

Windows® 98SE/Me/2000 Professional/XP Home

Edition/XP Professional

• PictureGear Studio V.2.0

Cleaning cartridge (1) Clamp ﬁlter (1)

• Operating Instructions (1)

• Quick Start Guide (this leaﬂet, 1)

• Warranty (1)

• Owner registration card (1)

• Sony End User Software License Agreement (1)

2 Prepare the printing pack (not supplied).

For post card size printing:

SVM-25LS

• Post card (4 x 6 inch)

size print paper (25

sheets)

• Print cartridge (1)

For 3.5 x 5 inch size

printing:

SVM-30MS

• 3.5 x 5 inch size print

paper (30 sheets)

• Print cartridge (1)

For Small size printing:

SVM-30SS

• Small (3.5 x 4 inch)

size print paper (30

sheets)

• Print cartridge (1)

For the details, see page 12 of Operating Instructions.

3Load the print cartridge.

1Slide open the cartridge

compartment cover.

2Insert the print

cartridge.

3Close the cover.

"Sony" logo

4 Insert the print paper.

1Open the paper tray cover, and then

adjust the spacer to ﬁt the paper

size.

Spacer

2Insert the print paper.

Insert the print paper with the arrow of the

Protective sheet facing backwards (the

feeding direction).

3Remove the protective sheet, and

then close the paper tray cover.

You can use the protective sheet as

cleaning sheet. Keep it together with the

cleaning cartridge.

4Push and open the printer's paper

tray compartment cover and insert

the paper tray into the printer.

Insert it ﬁrmly until it clicks into place.

5 Connect to the AC outlet.

Connect the AC power cord to the AC

outlet.

Go to step 6.,

AC power cord

DPP-EX50

Printing

6 Print an image.

Depending on the memory card or device you

use, the printing procedures differ:

Printing an image

stored on a

"Memory Stick" or a

CompactFlash card

Printing an image from

a PictBridge-compliant

digital camera

See page 81 of

the Operating

Instructions.

Printing using a

connected TV monitor

1Connect the printer to a

TV monitor and turn on

the TV monitor.

Set the TV monitor in the

video mode.

2 Insert a "Memory Stick"

or a CompactFlash card.

"Memory Stick"

CompactFlash card

3Press ON/STANDBY to

turn on the printer.

4Display the images on

the TV monitor.

Press MONITOR OUT to

turn on the indictor.

5 Press INPUT SELECT to

display "Memory Stick"

or "CompactFlash" on

the TV monitor.

6Select an image for

printing.

Press (B/b/V/v) to move

the yellow frame (cursor)

to the image you want to

print.

7Press PRINT.

To print multiple copies

See page 24 on the

operating instructions.

zzz

zzzz

"Memory Stick"

CompactFlash card

Printing an image

from a PC

See page 85 of

the Operating

Instructions.

4Press INPUT SELECT to

display "Memory Stick"

or "CompactFlash" on

the LCD display.

2Press ON/STANDBY to

turn on the printer.

3 Press MONITOR OUT to

turn off the indicator.

5Press AUTO PRINT to

display "INDEX."

7Select an image for

printing.

Press the arrow (B/b)

button to display the

desired image number.

To print multiple copies

Press ENTER repeatedly to

display the desired number.

6Press PRINT.

The index of the images

in the memory card is

printed, allowing you to

check the image numbers.

8Press PRINT.

Preparations Displaying images Selecting an image Printing

Printing using the

printer's LCD display

Preparations Displaying images Selecting an image

1 Insert a "Memory Stick"

or a CompactFlash card.

"Memory Stick"

CompactFlash card
