DIGITAL VIDEOCASSETTE RECORDER

DNW-A25/A25P

OPERATION MANUAL

1st Edition (Revised 4) [English]

WARNING

To prevent fire or shock

hazard, do not expose the

unit to rain or moisture.

To avoid electrical shock, do

not open the cabinet. Refer

servicing to qualified

personnel only.

For the customers in the USA

This equipment has been tested and

found to comply with the limits for a

Class B digital device, pursuant to Part

15 of th e FCC Rules. These limits are

designed to provide reasonable

protection against harmful interference

in a residential installation. This

equipment generates, uses, and can

radiate radio frequency energy and, if

not installed and used in accordance

with the instructions, may cause

harmful interference to radio

communications. However, there is no

guarantee that interference will not

occur in a particular installation. If this

equipment does cause harmful

interference to radio or television

reception, which can be determined by

turning the equipment off and on, the

user is encouraged to try to correct the

interference by one or more of the

following measures:

— Reorient or relocate the receiving

antenna.

— Increase the separation between

the equipment and receiver.

— Connect the equipment into an

outlet on a circuit different from that

to which the receiver is connected.

— Consult the dealer or an

experienced radio/TV technician for

help.

You are cautioned that any changes or

modifications not expressly approved

in this manual could void your authority

to operate this equipment.

The shielded interface cable

recommended in this manual must be

used with this equipment in order to

comply with the limits for a digital

device pursuant to Subpart B of Part

15 of FCC Rules.

For the customers in Europe

This product with the CE marking

complies with the EMC Directive (89/

336/EEC) issued by the Commission

of the European Community.

Compliance with this directive implies

conformity to the following European

standards:

• EN55103-1: Electromagnetic

Interference (Emission)

• EN55103-2: Electromagnetic

Susceptibility (Immunity)

This product is intended for use in the

following Electromagnetic

Environment(s):

E1 (residential), E2 (commercial and

light industrial), E3 (urban outdoors)

and E4 (controlled EMC environment,

ex. TV studio).

Table of Contents i

Chapter 1

Overview

1-1 Features ............................................................... 1-1

1-2 System Configuration......................................... 1-3

1-3 Locations and Functions of Parts...................... 1-4

1-3-1 Display Panel ...................................... 1-5

1-3-2 Control Panel.......................................1-7

1-3-3 Front Control Section........................1-18

1-3-4 Connector Panel ................................1-20

1-3-5 Top Panel .......................................... 1-24

Chapter 2

Preparations

2-1 Power Preparations ............................................ 2-1

2-1-1 Usable Batteries .................................. 2-1

2-1-2 Using the BP-L60(A)/L90(A) Battery

Pack.....................................................2-1

2-1-3 Using the BP-90(A) Battery Pack.......2-2

2-1-4 Using AC Power ................................. 2-3

2-2 Connection........................................................... 2-5

2-3 Handling Cassettes ............................................. 2-6

2-3-1 Loading/Ejecting Cassettes .................2-6

2-3-2 Preventing Accidental Erasures .......... 2-9

2-4 Setting Reference Video Signals...................... 2-10

2-5 Setting Timecode .............................................. 2-12

2-5-1 Setting an Initial Value and Recording

Timecode........................................... 2-13

2-5-2 Synchronizing the Internal Timecode

Generator with an External Signal .... 2-15

2-5-3 Synchronizing the Internal Timecode

Generator with Playback Timecode

– Timecode Recording during Auto

Editing ............................................... 2-16

2-5-4 Recording External Timecode without

Regeneration .....................................2-17

2-5-5 First Edit Function ............................ 2-17

2-6 Sub LCD Menu ................................................. 2-18

2-6-1 Displays on the Home Page of

the Sub LCD Menu ........................... 2-18

2-6-2 Sub LCD Menu Basic Operations..... 2-20

Table of Contents

(Continued)

ii Table of Contents

Table of Contents

Chapter 2

Preparations

(continued)

2-7 Input and Output Settings for Video and Audio

Signals (Sub LCD Menu) ................................. 2-23

2-7-1 Making Settings in the Audio Settings

Pages .................................................2-23

2-7-2 Making Settings in the Audio Settings

Subpages ...........................................2-25

2-7-3 Making Settings in the Video Settings

Pages .................................................2-28

2-8 General Settings Page of the Sub LCD

menu................................................................... 2-31

Chapter 3

Editing

3-1 Selecting an Edit Mode ...................................... 3-1

3-1-1 Assemble Editing ................................ 3-1

3-1-2 Insert Editing....................................... 3-2

3-2 Finding Edit Points — Search ........................... 3-3

3-3 Setting Edit Points .............................................. 3-5

3-3-1 Setting Edit Points............................... 3-5

3-3-2 Checking Edit Points........................... 3-6

3-3-3 Cueing Up Edit Points.........................3-6

3-3-4 Previewing Edit Results ......................3-7

3-3-5 Modifying Edit Points......................... 3-8

3-3-6 Setting Edit Points Using the Recorder

Unit Only.............................................3-9

3-4 Executing an Edit ............................................. 3-10

3-4-1 Outline of Editing Operations ...........3-10

3-4-2 Starting an Edit..................................3-11

3-4-3 Redoing an Edit................................. 3-12

3-4-4 Displaying the Results of Editing ..... 3-12

3-5 DMC Editing ..................................................... 3-14

3-5-1 Overview of DMC Editing................ 3-14

3-5-2 Setting Edit Points and Playback

Speeds ...............................................3-15

3-5-3 Executing DMC editing ....................3-16

3-6 Preread Editing................................................. 3-17

3-7 Special Editing .................................................. 3-19

3-7-1 Quick Editing.....................................3-19

3-7-2 Continuous Editing ............................3-20

3-7-3 Manual Editing .................................. 3-21

Table of Contents iii

Chapter 4

Recording

and

Playback

4-1 Recording ............................................................ 4-1

4-1-1 Preparations for Recording ................. 4-1

4-1-2 Recording Operation ...........................4-1

4-2 Sequential Recording ......................................... 4-2

4-3 Playback .............................................................. 4-4

4-3-1 Preparations for Playback ................... 4-4

4-3-2 Playback Operation ............................. 4-5

4-3-3 Capstan Override Playback.................4-6

Chapter 5

Shot Mark/

Shot Data

5-1 Overview of Shot Mark/Shot Data Function ... 5-1

5-1-1 Shot Mark Function Features............. 5-1

5-1-2 Shot Mark Operation Menu ............... 5-2

5-1-3 Reading Shot Data ............................. 5-3

5-2 Shot Mark Operations ....................................... 5-4

5-2-1 Reading Shot Marks........................... 5-4

5-2-2 Writing Shot Marks............................ 5-4

5-2-3 Creating a Virtual Shot Mark............. 5-5

5-2-4 Displaying Shot Mark List................. 5-5

5-2-5 Deleting Shot Marks .......................... 5-8

5-2-6 Sorting Shot Marks ............................ 5-8

5-2-7 Cueing up a Mark............................... 5-9

Chapter 6

Setup

6-1 Menu System Configuration.............................. 6-1

6-2 Basic Menu .......................................................... 6-1

6-2-1 Items in the Basic Menu......................6-1

6-2-2 Basic Menu Operations.......................6-6

6-3 Extended Menu ................................................. 6-11

6-3-1 Items in the Extended Menu .............6-11

6-3-2 Extended Menu Operations............... 6-35

iv Table of Contents

Table of Contents

Appendixes Removing a Cassette When Tape Slack Occurs ..... A-1

Head Cleaning............................................................ A-1

Moisture Condensation ............................................. A-2

Digital Hours Meter .................................................. A-3

Specifications.............................................................. A-5

Information Displayed on the LCD Monitor ........ A-11

Combining Two VTRs ............................................ A-16

Using the Shoulder Belt........................................... A-17

Using the Carrying Case ......................................... A-18

Using the Soft Carrying Case ................................. A-19

Glossary .................................................................... A-20

Index .............................................................................I-1

Overview 1-1

Chapter 1 Overview

1-1 Features

Chapter 1 Overview

The DNW-A25/A25P is a digital

portable editing recorder for the

Betacam SX format. It is equipped

with a color LCD monitor and speaker

to enable editing of news material in

the field.

The features of this unit include the

following.

Betacam SX format

This unit supports the Betacam SX

format, developed by Sony as the

digital version of the Betacam SP

format. No format conversion is

needed for use with nonlinear editing

systems and server systems.

Playback compatibility with

Betacam SP

It can play tapes recorded in the

Betacam and Betacam SP formats,

allowing you to make effective use of

Betacam and Betacam SP cassettes

recorded in the past. You can

assemble news gathering systems that

combine this unit with conventional

Betacam SP camcorders.

Digital signal processing

This unit processes 4:2:2 component

digital signals in the D-1 format.

Inter-frame data compression

Inter-frame data compression by

MPEG2 4:2:2 Profile @ Main Level

(1 GOP = 2 frames) reduces the

volume of data to about 1/10.

Rich variety of input and

output signals

The following input and output signals

are supported.

• SDI (serial digital interface) video

and audio

• Analog composite video

• Analog audio

• Timecode

Powerful editing functions

Combining two DNW-A25/A25P

units allows you to perform assemble

editing, insert editing, and audio split

editing. DMC (dynamic motion

control) is possible when both the

source and recording sides use the

Betacam SX format.

This unit can also be connected to a

BVE series or other editor for remote

editing.

Sequential recording

Combining two DNW-A25/A25P

units allows you to perform sequential

recording from one unit to another.

When you perform overwrite

recording using only two cassettes, the

last two hours recording can be

obtained at any time. When you

renew the cassette about every 1 hour,

endless recording is possible.

Features

1-2 Overview

Chapter 1 Overview

525 or 625 versatility

When using the Betacam SX format,

525 or 625 mode recording and

playback can be selected from a menu.

When using the Betacam and Betacam

SP formats, only simple viewing is

possible for tapes recorded in different

mode.

Combination of two units

Using the BKNW-225 to combine two

DNW-A25/A25P units gives you a

portable editor.

Economical

• Betacam SP cassettes and

inexpensive UVW cassettes can be

used in addition to Betacam SX

cassettes.

• Special high-durability heads and

components contribute to reduced

maintenance costs.

Compact and lightweight

Even though it is a standalone editing

recorder equipped with an LCD

monitor and a speaker, thanks to its

compact design and light weight, you

can carry it easily.

Good Shot marks/Shot Data

During tape rewinds, this unit reads

the REC Start (RS) and Good Shot

(GS) marks recorded by Betacam SX

camcorders, and builds an index. The

index facilitates quick cue-ups of

desired marks (index search function),

for greater editing efficiency.

When shot marks are recorded on the

tape, you can display and sort lists of

the shot marks.

Preread editing

You can execute preread editing,

using video or audio signals recorded

on the tape as the edit source for insert

editing. Using this function, the

previously read signals ca be sent to

mixers for mixing and returned to the

original channels.

AC and DC power

This unit is equipped with V-shoe

attachment, on which BP-L60(A)/

L90(A) or BP-90(A) battery or an AC

adaptor can be mounted. The unit can

operate for about 80 minutes with BP-

L90 battery mounted. For AC

operation, you can connect an AC-

550/550CE or AC-DN2(A) adaptor.

Overview 1-3

Chapter 1 Overview

1-2 System Configuration

The figure below shows an example of

an editing system configured around

the DNW-A25/A25P.

Betacam SX camcorder

Digital

cassette

Betacam SP

camcorder

Analog

cassette

DNW-A25/A25P

Microphone

AC-550/

550CE

Video monitor

Audio monitor

Digital

modulator

Microwave

transmission system

Digital

demodulator

Protocol

converter Protocol

converter

DNW-A100 series

BVE series

editor

BVR-3

PLAYER

REMOTE

REMOTE/DC OUT

VIDEO

OUT

MONITOR OUT/

AUDIO OUT

BATTERY/

DC IN

DC-L90 BP-90(A)

DC-210

BP-L90(A)

BP-L60(A)

AC-DN2(A)

SDI(P) SDI(R)

DSM-M1 DSM-D1

SDI

SDI(R)

SDI(P) Network

Digital

cassette

Locations and Functions of Parts

1-4 Overview

Chapter 1 Overview

1-3 Locations and Functions of

Parts

This unit is comprised of the parts

shown in the figure below.

How to open the

display panel

Slide the lock release switch

and pick up the display panel.

Display panel

(see page 1-5)

Control panel

(see page 1-7)

Front control Section

(see page 1-18)

Connector panel

(see page 1-20)

Top panel (see page 1-24)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de DVR de Sony

Sony

Sony SVR-3000 - Digital Network Recorder Manual de uso y mantenimiento

Sony

Sony Giga Pocket Manual de usuario

Sony

Sony Handycam HDR-CX330 Manual de usuario

Sony

Sony DHG-HDD250 - 30-Hour High-Definition Digital Video... Manual de usuario

Sony

Sony DSR-DR1000 Manual de usuario

Sony

Sony HVO-500MD Manual de usuario

Sony

Sony Digital Betacam DVW-2000 Manual de usuario

Sony

Sony GV-300R - Video Walkman Manual de usuario

Sony

Sony IPELA 3-869-888-16 (1) Manual de usuario

Sony

Sony DHG-HDD250 - 30-Hour High-Definition Digital Video... Manual de usuario

Sony

Sony DNW-A100 Manual de usuario

Sony

Sony SVR-3000 - Digital Network Recorder Instrucciones y recetas

Sony

Sony Handycam HDR-CX11E Manual de usuario

Sony

Sony Video Walkman GV-S50 Manual de usuario

Sony

Sony Ipela NSR-S10 Manual de usuario

Sony

Sony PDW-F1600 Manual de usuario

Sony

Sony DHG-HDD250 - 30-Hour High-Definition Digital Video... Manual de usuario

Sony

Sony GV-200 - Video Walkman Manual de usuario

Sony

Sony SVR-HD700 Manual de usuario

Sony

Sony GV-300 Primary Manual de usuario

Sony

Sony Handycam HDR-CX240 Manual de usuario

Sony

Sony PWS-4400 Manual de usuario

Sony

Sony XDCAM EX PMW-EX30 Manual de usuario

Sony

Sony DNW-A100 Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
