Sony RDP-XA700iP Manual

RDP-XA900iP / RDP-XA700iP

AirPlay via Wi-Fi

Network Setup

Guide de configuration

d’AirPlay via le réseau Wi-Fi

Configuración de AirPlay

e través de la red Wi-Fi

4-417-839-11(1)

Personal Audio Docking System

AirPlay

via Wi-Fi Network

Setup

2GB

NO / UNKNOWN

YES

Refer to the operating instructions supplied with the

router/access point for details.

QAre you using a wireless LAN router/access

point compatible with Wi-Fi Protected Setup

(WPS)?

What is AirPlay?

AirPlay allows you to play audio from iPhone, iPod touch, iPad or iTunes, and control it

from anywhere in your home.

You will need to set your iPhone/iPod touch/iPad to a Wi-Fi Network, and connect this unit

to that network.

* A dedicated dock app for iPhone, iPod touch, iPad available at Apple App Store. Search for“D-Sappli” and download

the free app to find out more about the functions. ** RDP-XA700iP is used for illustration purposes.

Check How to Connect Your Network

Set up the network after checking your network environment. Use the chart below

to determine the correct connections.

GB3

Set up using

WPS Push-Button Configuration Method (page 4).



Set up using

D-Sappli* with iPhone/iPod touch/iPad (page 6).



Check How to Connect Your Network

Set up the network after checking your network environment. Use the chart below

to determine the correct connections.

For Access Point Scan using your Mac

or PC

Refer to“Connecting Your Network” of

“Operating Instructions”supplied with

this unit.

4GB

Before Starting

1 Place this unit close to the wireless LAN

router/access point.

2 Turn this unit on.

The LINK indicator (page 5) starts to flash

green.

3 Wait for about 70 seconds until the LINK

indicator turns off.

Note

While it is connected to a Wi-Fi Network, do not turn

this unit off.

Setup device: WPScompatible Wireless LAN router/access point

Method: WPS Push-ButtonConfiguration Method

Starting Network Settings

1 Press and hold the WPS button on this

unit until the beep sound is output from

this unit.

Rear of this unit

2 Press and hold the WPS button on the

router/access point within 90 seconds

after step1.

* The position and shape of the WPS button differ

depending on the model of the router/access point.

Tip

For details on the WPS button, refer to the operating

instructions of the router/access point.

3 Check the status of the LINK indicator

(page 5).

When the LINK indicator lights up green,

the connection is established.

GB5

Listening via AirPlay

1 Check that the iPhone/iPod touch/iPad

you are using as the“AirPlay” device is

connecting to the Wi-Fi Network.

2 Tap the “AirPlay” icon on the music

player screen of your iPhone/iPod

touch/iPad.

3 Tap this unit’s name.

unit name

4 Tap to start playback.

For details on “AirPlay” operation of

iTunes, refer to“Operating Instructions”

supplied with this unit.

About the LINK indicator

Lights up green.

The Wi-Fi Network connection is

established.

(Green)

Flashes green.

This unit is in the process of

connecting to the Wi-Fi Network.

Please wait.

(Green)

Lights up red.

An error has occurred.

Try again from the beginning, or adjust

your network settings.

(Red)

The indicator turns off.

No connection is established.

(Nothing)

6GB

Before Starting

1 Check that the iPhone/iPod touch/iPad

you are using as the“AirPlay” device is

connecting to the Wi-Fi Network.

2 Write down the Security Key (WEP or

WPA key) of your wireless LAN router/

access point.

For details, refer to the operating

instructions of the router/access point.

3 Press to open the Docking Tray, and

connect your iPhone/iPod touch/iPad to

the connector.

4 Turn this unit on (page 4).

The LINK indicator (page 7) starts to flash

green.

5 Wait for about 70 seconds until the LINK

indicator turns off.

Tip

If the message to download D-Sappli appears, follow

the on-screen instructions and download it.

Notes

While it is connected to a Wi-Fi Network, do not

turn this unit off, press the Home button, or

disconnect your iPhone/iPod touch/iPad.

When a problem occurs during Wi-Fi settings,

disconnect your iPhone/iPod touch/iPad and

connect it again.

Setup device: iPhone/ iPod touch/ iPad

Method: D-Sapplisetup

Starting Network Settings

1 Tap the D-Sappli icon to access it while

keeping your iPhone/iPod touch/iPad on

this unit.

2 Perform the network settings, following

the on-screen instructions.

3 When the message [Connection

complete.] appears, tap [OK] to finish the

network settings.

4 Check the status of the LINK indicator

(page 7).

When the LINK indicator lights up green,

the connection is established.

GB7

Listening via AirPlay

1 Disconnect your iPhone/iPod touch/iPad

from the connector.

2 Tap the “AirPlay” icon on the music

player screen of your iPhone/iPod

touch/iPad.

3 Tap this unit’s name.

unit name

4 Tap to start playback.

For details on “AirPlay” operation of

iTunes, refer to“Operating Instructions”

supplied with this unit.

About the LINK indicator

Lights up green.

The Wi-Fi Network connection is

established.

(Green)

Flashes green.

This unit is in the process of

connecting to the Wi-Fi Network.

Please wait.

(Green)

Lights up red.

An error has occurred.

Try again from the beginning, or adjust

your network settings.

(Red)

The indicator turns off.

No connection is established.

(Nothing)

To adjust the network settings at a later

time

1 Perform the procedure of “Before Starting”

to connect your iPhone/iPod touch/iPad to

the connector.

2 Access D-Sappli.

3 Tap the [i] icon, then tap [Network] to

perform the network settings.

[i] icon

8GB

This unit cannot connect to the Wi-Fi Network.

☐Check that your wireless LAN router/access point is turned on.

☐Check that the router/access point is close to this unit.

☐Devices that use a 2.4GHz frequency band such as microwave, Bluetooth or digital cordless

device, may interrupt the communication. Move this unit away from such devices, or turn off

the devices.

WPS configuration method failed.

☐Check that the router/access point Wi-Fi Network setting is WEP. If so, adjust the network

settings using Access Point Scan. For details, refer to“Operating Instructions”supplied with this

unit.

If you encounter a problem, please check

GB9

If you encounter a problem, please check

The “AirPlay” icon or unit name does not appear on your iPhone/iPod

touch/iPad or iTunes.

☐Check that this unit, your iPhone/iPod touch/iPad, Mac or

PC are connected to the same network.

You can check the connected access point under [Network]

setting using D-Sappli (page 7).

☐Check that your iPhone/iPod touch/iPad or iTunes has the latest software version.

☐If the problem persists, reboot your iPhone/iPod touch/iPad or iTunes.

No sound is output, even when you select this unit’s name.

☐Adjust this unit’s volume by pressing VOL+/-.

☐Check that no other iPhone/iPod touch/iPad is set on this unit. If so, remove it from the

network.

☐If the problem persists, reboot your iPhone/iPod touch/iPad or iTunes.

It takes time for the “AirPlay” function to start.

☐Use this unit in the network standby mode. This mode shortens the startup time when using

the “AirPlay” function, but increases standby power consumption. For details, refer to

“Operating Instructions”supplied with this unit.

2FR

NON / INCONNU

OUI

Pour plus d’informations, reportez-vous au mode

d’emploi qui accompagne le routeur/point d’accès.

QUtilisez-vous un point d’accès/routeur LAN

sans fil compatible WPS (Wi-Fi Protected

Setup) ?

Qu’est-ce que la fonction AirPlay ?

AirPlay permet d’écouter le son d’un iPhone, d’un iPod touch, d’un iPad ou d’iTunes, et de

le commander à partir de n’importe quel endroit de votre maison.

Vous devez configurer votre iPhone/iPod touch/iPad sur un réseau Wi-Fi et y connecter cet

appareil.

* Application de connexion réservée à l’iPhone, iPod touch et iPad, disponible sur Apple App Store. Recherchez

« D-Sappli » et téléchargez l’application gratuite pour en savoir davantage sur les fonctions. ** Le modèle illustré est

le RDP-XA700iP.

Déterminez le mode de connexion à votre réseau

Vérifiez votre environnement réseau, puis configurez le réseau. Utilisez le schéma

ci-dessous pour déterminer les connexions correctes.
