CPU UPGRADE BOARD

BKDS-7200K1

INSTALLATION MANUAL

1st Edition

Serial No. 10001 and Higher

!WARNING

This manual is intended for qualified service personnel only.

To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so. Refer all servicing to

qualified service personnel.

!WARNUNG

DieAnleitung ist nur für qualifiziertes Fachpersonal bestimmt.

Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die

Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei

Wartungsarbeiten strikt dieAngaben in der Anleitung zu befolgen. Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung

dazu besitzen.

!AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin

de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les

réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.

Pour toute réparation faire appel à une personne compétente uniquement.

1 (E)

BKDS-7200K1 IM

Table of Contents

1. Overview

1-1. BKDS-7200K1 Structure .......................................................................1-1(E)

1-2. Manual Structure....................................................................................1-1(E)

2. Modification

2-1. Modification Procedure..........................................................................2-1(E)

2-2. Modification Method .............................................................................2-1(E)

1-1 (E)

BKDS-7200K1 IM

Section 1

Overview

1-2. Manual Structure

Besides this Installation Manual, the following manuals are

available for the BKDS-7200K1.

.DVS-7200A Operation Manual

(Supplied with BKDS-7200K1)

This manual explains the overview of DVS-7200A and

options, and the system configuration examples.

.DVS-7200 System, DVS-7250 System User’s Guide

(Supplied with the optional software BZS-7040A or

BZS-7060A)

This guide explains how to use the switcher system

using DVS-7200A to operate the processor.

.DVS-7200A Installation Manual

(Supplied with BKDS-7200K1)

This manual describes the information necessary to

install the DVS-7200A and options.

.DVS-7200A Maintenance Manual Part 1

(Supplied with BKDS-7200K1)

This manual describes the information on primary

service of DVS-7200A and options.

.DVS-7200A Maintenance Manual Part 2

(Not supplied with BKDS-7200K1)

This manual describes the information (adjustments,

boards layouts, schematic diagrams, parts list, etc.) that

premise the service based on parts.

If this manual is required, please contact to Sony’s

service organization.

1-1. BKDS-7200K1 Structure

The BKDS-7200K1 is the CPU upgrade board for the

Digital Video Switcher DVS-7200.

By replacing this board with the corresponding board of

the DVS-7200, you can adapt the DVS-7200 to the

machine that perform as well as the DVS-7200A.

The BKDS-7200K1 consists of the following component :

.CPU-264B board : Replaces the CPU-192A board.

2-1 (E)

BKDS-7200K1 IM

Section 2

Modification

2-1. Modification Procedure

To avoid shock hazards and/or damage to the board, be

sure to turn off the power switch of DVS-7200 before

performing the modification.

Perform the modification as the following procedures.

1. Install the CPU-264B board.

2. Perform the confirmation after modification.

2-2. Modification Method

1. Install the CPU-264B board

(1) Loosen the four screws on the front panel, and remove

the front panel.

(2) Remove the twelve screws, the two board retainer and

the one board holder.

(3) Replace the CPU-192A board with the CPU-264B

board.

For details, refer to “4-3-2. Inserting/Pulling Out of Plug-in

Boards” in the DVS-7200A Installation Manual.

2. Perform the confirmation after modification

(1) Conferm the secondary power supply voltage.

(2) Install the two board retainer and the one board holder

with the twelve screws.

(3) Attach the front panel in the reverse order of the steps

(1) and (2) of “1. Install the CPU-264B board”.

For details, refer to “5-2. Confirmation of Secondary

Power Supply Voltage” the DVS-7200A Installation

Manual.

The material contained in this manual consists of

information that is the property of Sony Corporation and

is intended solely for use by the purchasers of the

equipment described in this manual.

Sony Corporation expressly prohibits the duplication of

any portion of this manual or the use thereof for any

purpose other than the operation or maintenance of the

equipment described in this manual without the express

written permission of Sony Corporation.

Le matériel contenu dans ce manuel consiste en

informations qui sont la propriété de Sony Corporation et

sont destinées exclusivement à l’usage des acquéreurs

de l’équipement décrit dans ce manuel.

Sony Corporation interdit formellement la copie de

quelque partie que ce soit de ce manuel ou son emploi

pour tout autre but que des opérations ou entretiens de

l’équipement à moins d’une permission écrite de Sony

Corporation.

Das in dieser Anleitung enthaltene Material besteht aus

Informationen, die Eigentum der Sony Corporation sind,

und ausschließlich zum Gebrauch durch den Käufer der

in dieser Anleitung beschriebenen Ausrüstung bestimmt

sind.

Die Sony Corporation untersagt ausdrücklich die

Vervielfältigung jeglicher Teile dieser Anleitung oder den

Gebrauch derselben für irgendeinen anderen Zweck als

die Bedienung oder Wartung der in dieser Anleitung

beschriebenen Ausrüstung ohne ausdrückliche

schriftliche Erlaubnis der Sony Corporation.

Printed in Japan

Sony Corporation 1999. 2 08

BKDS-7200K1 (SY) J, E

3-201-861-01
