ICF-C1200

SERVICE MANUAL

FM STEREO/AM PLL

SYNTHESIZED RADIO

SPECIFICATIONS

US Model

AEP Model

E Model

Tourist Model

9-873-106-11

2001C0200-1

Sony Corporation

Audio Entertainment Group

General Engineering Dept.

ICF-C1200

Specifications ........................................................................... 1

1. GENERAL ...................................................................... 2

2. DISASSEMBLY

2-1. Main Board ................................................................. 3

3. ELECTRICAL ADJUSTMENTS

3-1. Tuner Section .............................................................. 4

4. DIAGRAMS

4-1. Explanation of IC Terminals ....................................... 6

4-2. Block Diagram ............................................................ 7

4-3. Printed Wiring Boards

– Main Section (1/2) (Side A) – .................................. 8

4-4. Printed Wiring Boards

– Main Section (2/2) (Side B) – .................................. 9

4-5. Schematic Diagram ................................................... 10

5. EXPLODED VIEWS

5-1. Main Section ............................................................. 13

6. ELECTRICAL PARTS LIST................................... 14

TABLE OF CONTENTS

SECTION 1

GENERAL

Notes on chip component replacement

• Never reuse a disconnected chip component.

• Notice that the minus side of a tantalum capacitor may be

damaged by heat.

LOCATION AND FUNCTION OF CONTROLS This section is extracted from

instruction manual.

rUNLEADED SOLDER

Boards requiring use of unleaded solder are printed with the

lead-free mark (LF) indicating the solder contains no lead.

(Caution: Some printed circuit boards may not come printed

with the lead free mark due to their particular size.)

: LEAD FREE MARK

Unleaded solder has the following characteristics.

• Unleaded solder melts at a temperature about 40°C higher

than ordinary solder.

Ordinary soldering irons can be used but the iron tip has to

be applied to the solder joint for a slightly longer time.

Soldering irons using a temperature regulator should be set

to about 350°C.

Caution: The printed pattern (copper foil) may peel away if

the heated tip is applied for too long, so be careful!

• Strong viscosity

Unleaded solder is more viscous (sticky, less prone to

flow) than ordinary solder so use caution not to let solder

bridges occur such as on IC pins, etc.

• Usable with ordinary solder

It is best to use only unleaded solder but unleaded solder

may also be added to ordinary solder.

ICF-C1200

SECTION 2

DISASSEMBLY

2-1. MAIN BOARD

Screws (1.4X6 tapping)

Screws (1.4)

Claw

Remove solder

(three places)

Red

Cabinet (rear) ASSY

Claw

Cabinet (front) ASSY

Main board

Knob (HOLD)

ANT101

S301

Brown

• Caution during assembly

Align the hold switch(S301)

to the knob(HOLD).

Black

Note : Follow the disassembly procedure in the numerical order given.

ICF-C1200 SECTION 3

ELECTRICAL ADJUSTMENTS

BAND button : AM

Volume : MIN

3-1.TUNER SECTION

AM Section

FM Section

BAND button : FM

Volume : MIN

Put the lead-wir

antenna close to

the set.

AM RF signal

generator

30% amplitude modulation by 400Hz

signal.

Output level : as low as possible

telescopi

antenna

terminal

FM RF signal

generator

22.5kHz frequency deviation by

400Hz signal.

Output level : as low as possible

0.01 uF

Adjustment Location : Main board (See page 5)

• Repeat the procedures in each adjustment several times, and the

frequency coverage and tracking adjustments should be finally

done by the trimmer capacitors.

AM IF ADJUSTMENT

Adjust for a maximum reading on level meter.

T101 1485kHz <1480kHz>

AM FREQUENCY COVERAGE ADJUSTMENT

Adjust part Frequency display

L105 531kHz <530kHz>

reading on digital

voltmeter.

Adjustment value: 2.7V

Standaed value: 2.5 to 2.9V

AM TRACKING ADJUSTMENT

Adjust for a maximum reading on level meter.

L 102 585kHz <580kHz>

CT101 1,485kHz <1,480kHz>

Frequency Coverage Adjustment

Connect Location :

FM FREQUENCY COVERAGE CONFIRMATION

Adjust part Frequency display

Confirmation 87.5MHz 3.0 to 4.0V

Confirmation 108MHz 9.5 to 10.5V

reading on digital

voltmeter

FM TRACKING ADJUSTMENT

Adjust for a maximum reading on level meter.

L103 87.5MHz

CT102 108MHz

Ω

level mete

set

J201 (phones)

–

0dB=1µV

< > : US model

MAIN BOARD (SIDE A)

S308

(JOG SWITCH)

BAT401

PAS

(VT)

C405

R404

C412

R403

R314

R315

R405

C404

C301

C406 C407

R401

R402

D402

D403

BCE

Q402

302

T401

–

Digital

(VT)

100K

Ω

voltmeter

ICF-C1200

C113

C108

CF101

L104

L101

C212 C202

C118

T101

C201

C207

C205

R204

C103

C211

C214

C213

C206

C204

C410

R113 R129

R112

R202

R205

R201 R203

BCE

Q201

BCE

Q202

C210

C215

C208

C203

C209

C120

C122

D108

CT102

IC201

D109

(3V)

(76K)

33k

Ω

TP1 (76k)

TP(3V)

frequency

counter

MAIN BOARD (SIDE A)

VCO Adjustment

Procedure :

FM RF signal

generator

Carrier frequency : 98MHz

Modulation : No modulation

Output level : 1.38mV (–55dB)

set

telescopi

antenna

terminal

0.01 F

1. Connect the frequency counter to TP (76k) and TP (3V) as shown

the figure below.

2. Turn the set to 98MHz.

3. Adjust RV101 for 76kHz reading frequency counter.

Standard value:75.5kHz to 76.5kHz.

Adjustment Location:

[MAIN BOARD] (SIDE A)

CT101: AM Tracking Adjustment

L102: AM Tracking Adjustment

L105: AM Frequvency Coverage Adjustmen

RV101: VCO Adjustment

T101: AM IF Adjustment

L103: FM Tracking Adjustment

CT102: FM Tracking Adjustment

ICF-C1200

Pin No. Pin name I/O Description

1-4 COM1-4 O LCD common output.

5-26 S1-S22 O LCD segment output.

27 HOLD SW I HOLD switch input. ON:L OFF:H

28-30 KR1-3 I Key return input.

31 VDD — Power supply terminal.

32-34 KR1-3 O Key souce output.

35 POWER O Power ON control signal output. ON:L OFF:H

36 BEEP O Beep signal output.

37 MUTE O Mute signal output.

38 WAKE UP O Alarm output at volume control min. ON:L OFF:H

39 LCD I LCD check test mode setting input.

40 BAND O Band select signal output. AM:H FM:L

41 TEST — Not used (Fixed at "L").

42 HOLD — Not used (Fixed at "L").

43 INTR1 I 1.9V voltage detection terminal. Radio OFF :L

44 INTR2 I 1.1V voltage detection terminal. All OFF :L

45 — Not used (OPEN).

46 — Not used (OPEN).

47 GND — Ground terminal.

48 FM IN I FM local oscillator signal input.

49 AM IN I AM local oscillator signal input.

50 VDD — Power supply terminal.

51 D01 — Not used (OPEN).

52 D02 O Tuning voltage control output.

53 VREG — Regulator output for phase compalator.

54 — Not used (OPEN).

55 AL SW1 I ALARM switch input (OFF).

56 AL SW2 I ALARM switch input (RADIO).

57 AL SW3 I ALARM switch input (BUZZER).

58 VDET I 2.1V voltage detection input.

59 ID I Destination select input.

60 ID I Destination select input.

61 — Not used (OPEN).

62 SP BEEP O Beep signal output.

63 LIGHT O LCD back light ON/OFF output.

64 ST/MO O Stereo/Mono select output.

65-69 — Not used (OPEN).

70 RESET I Reset signal input.

71 XOUT O Oscillator output (75kHz).

72 XIN I Oscillator input (75kHz).

73 GND — Ground terminal.

74 VDB — Capacitor terminal.

75 C1 — Capacitor terminal.

76 C2 — Capacitor terminal.

77 VEE — Voltage pull-up terminal.

78 C3 — Capacitor terminal.

79 C4 — Capacitor terminal.

80 VLCD — Voltage pull-up terminal.
