Sonifex Redbox Series Manual de referencia
www.sonifex.co.ukwww.sonifex.co.uk
The Redbox Range of Products
Features
•All are equipped with IEC mains lead and instruction manual.
•In-house design and manufacture ensures high quality control standards.
•All units are 115V 60Hz or 230V 50Hz switchable, or universal and all have a
front panel LED power indicator.
•Manufactured within ISO9000 standards and guaranteed CE compliant.
•Housed in eye catching red anodised aluminium cases.
Redbox are a range of audio and video interfaces designed for use in critical
broadcast applications where the product needs to be powered 24 hours a day, 365
days a year. Manufactured to the highest standards in our UK offices, utilisation of
the finest components and critical quality control techniques ensure that your
Redboxes work every time, for years to come. They are “fit and forget” products - you
can set them up, fit them in your installation and then forget about them.
www.sonifex.co.uk 1
Redbox Introduction
www.sonifex.co.ukwww.sonifex.co.uk
RB-ADDA Combined A/D and D/A Converter
Uses:
•To connect an analogue line level
audio signal into a digital mixer.
•To connect a digital recorder to an
analogue mixer in both directions.
•To convert an analogue amplifier
signal to an S/PDIF or AES/EBU input
on a mixer.
The RB-ADDA A/D and D/A converter is a 1U rack-mount which produces an
AES/EBU or S/PDIF level digital audio output from a balanced XLR or unbalanced
phono stereo audio input. It also produces a stereo balanced XLR or unbalanced
phono output from an incoming AES/EBU or S/PDIF digital input signal.
www.sonifex.co.uk 2
Digital Audio Converters
www.sonifex.co.ukwww.sonifex.co.uk
Features:
•Front panel control.
•Operation up to 192kHz.
•AES/EBU & wordclock synchronising
inputs, so that the A/D and D/A
sections can operate independently.
The RB-ADDA2 A/D and D/A converter is a 1U rack-mount which produces an
AES/EBU, S/PDIF or TOSlink optical level digital audio output from a balanced XLR
or unbalanced phono stereo audio input. It also produces a stereo balanced XLR or
unbalanced phono output from an incoming AES/EBU, S/PDIF or TOSlink optical
digital input signal.
www.sonifex.co.uk 3
Digital Audio Converters
RB-ADDA2 Combined A/D & D/A Converter
www.sonifex.co.ukwww.sonifex.co.uk
RB-SC1 Sample Rate Converter
Features:
•Superb conversion quality.
•AES/EBU and S/PDIF inputs and
outputs.
•AES/EBU,S/PDIF and TTL wordclock
synchronizing inputs.
•Sample rates up to 24bit 96kHz.
Ideal for the transfer of digital audio between different digital equipment, the
RB-SC1 sample rate converter standardises the sample rate of a digital audio
signal to one of 32kHz, 44.1kHz, 48kHz or 96kHz, or to a synchronising input. Both
audio inputs and outputs have push-button switches to select either AES/EBU or
S/PDIF. The synchronising input can be selected from one of AES/EBU, S/PDIF or
TTL word clock.
www.sonifex.co.uk 4
Digital Audio Converters
www.sonifex.co.ukwww.sonifex.co.uk
RB-SC2 Dual Sample Rate Converter
Features:
•Supports sample frequencies up to
176.4kHz & 192kHz.
•Output sample rate set by internal
clock or external sync.
•Has 2 independent sample rate
converter circuits & can function as a
full bi-directional sample rate
converter.
The RB-SC2 sample rate converter is a 1U rack-mount which produces AES/EBU,
S/PDIF and TOSlink optical level digital audio outputs from a balanced AES/EBU,
S/PDIF and TOSlink optical level digital audio inputs. The sample rate of the outputs
can be set by an internal clock or from various external synchroniser sources.
www.sonifex.co.uk 5
Digital Audio Converters
www.sonifex.co.ukwww.sonifex.co.uk
RB-DAC1 Digital to Analogue Converter
Features:
•Superb quality and pristine audio
clarity with 24 bit, 96kHz operation.
•AES/EBU and S/PDIF digital inputs.
•Both balanced XLR and unbalanced
phono outputs.
•Front panel headphone output with
volume control.
Using 24 bit, 96kHz capable devices, the RB-DAC1 D/A Converter is a 1U rack-
mount which produces a stereo balanced XLR or unbalanced phono output from an
incoming AES/EBU or S/PDIF digital input signal. There is also a headphone output
with volume control for monitoring purposes.
www.sonifex.co.uk 6
Digital Audio Converters
www.sonifex.co.ukwww.sonifex.co.uk
RB-SP1 Digital Splitter and Combiner
Features:
•Can be used for interfacing stereo
and mono signals to digital mixing
desks, e.g. can split a digital stereo
signal into 2 digital mono signals.
•Can handle sample rates up to
96kHz and sample sizes of 16, 20
and 24 bit.
The RB-SP1 digital splitter & combiner is used to interface stereo and
mono AES/EBU & S/PDIF signals to digital mixing desks by splitting the left
and right signals of a stereo XLR to two separate XLR’s, and vice versa by
combining them.
www.sonifex.co.uk 7
Digital Audio Converters
www.sonifex.co.ukwww.sonifex.co.uk
RB-SYA Analogue Video Sync Board
for RB-SC2
Uses:
•Used to synchronise the outputs of
the RB-SC2 to a 48kHz sample rate.
•Used to synchronise the outputs of
the RB-TGHD(B & X).
The Analogue video sync board will accept a composite signal of NTSC (525), PAL
(625) & SECAM (625) signals covered by SMPTE-170-M (NTSC) and ITU-R BT.470-6
(PAL & SECAM.
www.sonifex.co.uk 8
Synchronisation Add-On Boards
www.sonifex.co.ukwww.sonifex.co.uk
RB-SYD Digital Video Sync Board
for RB-SC2
•Used to synchronise the outputs of
the RB-SC2 to a 48kHz sample rate.
•Used to synchronise the outputs of
the RB-TGHD(B & X).
The Digital video sync board will accept 270Mbps SD-SDI and HD-SDI signals
covered by SMPTE-259-M-C (SD) and SMPTE-292M (HD).
www.sonifex.co.uk 9
Synchronisation Add-On Boards
www.sonifex.co.ukwww.sonifex.co.uk
RB-SYE Sync Board
Uses:
•Used to synchronise the outputs of
the RB-TGHD(B & X).
The AES/EBU sync board will accept a digital audio input signal with a sample
frequency between 32kHz and 192 kHz. When using the RB-SYE sync board, the
Channel Status information that is encoded in the input data signal is copied to all
digital output channels.
www.sonifex.co.uk 10
Synchronisation Add-On Boards
