Complete Home Alerng Soluon

HA360MK

Quick Reference and Installaon Guide

Seng Up Your HomeAware™

1. Remove all contents of the box.

– HomeAware™ - Main Unit

– Doorbell Transmier

– Doorbell Chime Box Connector Cord

– Vibrator / Bed Shaker

– Telephone Line Cord

2. Plug the power supply into back of

the Main unit, 7.5V 2A DC IN.

3. Plug Main unit power supply into a

120V outlet.

4. Plug Vibrator/Bed Shaker into the

vibrator outlet on the back of the

Main unit. (Oponal)

Seng Time of Day

1. Press the Time Set buon. Blinking red

dots will show on the display.

2. Press the Hour and Minutes buons up

or down to set desired me. When

seng the me make sure the PM

indicator light reﬂects the correct me.

3. Press the Enter buon to complete.

Seng Alarm 1

1. Press and hold AL.1 Set buon. Blinking

red dots will show on the display.

2. Press the Hour and Minute buons up

or down to set desired alarm me.

3. Press the Enter buon when done to

complete. A red LED Alarm indicator

light will appear on the display’s le side

indicang alarm 1 is now set.

4. Repeat for AL.2.

PM Indicator

SNOOZE

AL.2 Set Hour Minute Back

Enter

Tone

Volume

AL.1 Set

Time Set Alarm Off Set Up

Main

Alarm Indicator

SNOOZE

AL.2 Set Hour Minute Back

Enter

Tone

Volume

AL.1 Set

Time Set Alarm Off Set Up

Main

7.5V 2A

DC IN

120V Outlet

7.5V 2A

DC IN

LAMP

SW.

EXT.

BATT.

USB CHARGE 5V

TEL.

LINE CELL PHONE

DETECTOR

VIBRATOR

VIBRATOR/

BED SHAKER

LATCH TO OPEN

COMPARTMENT

DOOR

Seng Up Your Doorbell Transmier

1. Install provided baeries into the boom of

the unit.

2. Once installed push the link buon and the red

LED light will light. If the light does not show,

you may have the baeries in backwards.

Linking Doorbell Transmier to Main Unit

Do the LINK procedure in the same room as the

Main Unit.

1. Press Set Up and LINK will be shown, press Enter

the word LINK will begin blinking.

2. Press link buon on the boom of the doorbell

transmier. The red LED light on front of the

doorbell transmier will blink two mes and

DOOR will be shown, press Enter.

BATTERIES

LINK BUTTON

BATTERY/LINK

COMPARTMENT

DOOR

Complete Home Alerng Soluon

HA360MK

Quick Reference and Installaon Guide

Installing a Telephone Line to the Main Unit

1. Place the Main unit close to a standard RJ11

telephone wall jack.

2. Plug the phone line cord into the wall jack.

3. Plug the opposite end of the phone line

cord into the back of the Main unit,

TEL LINE.

4. To hookup a standard telephone plug the

phone jack into the back of the Main unit,

TEL.

5. To charge your smartphone, plug into the

USB CHARGE 5V.

7.5V 2A

DC IN

LAMP

SW.

EXT.

BATT.

USB CHARGE 5V

TEL.

LINE CELL PHONE

DETECTOR

VIBRATOR

Installaon and Set Up of Doorbell Transmier

There are two methods to install and set up.

1. Stand-alone no exisng chime box. See page 26 of

User Guide.

2. To exisng chime box. See page 29 of User Guide.

EXISTING CHIME BOX

METHOD

LINK BUTTON

RJ11

WALL

JACK

SMARTPHONE

USB

CHARGER
