SOMFY EOLIS Inteo Wind Control Manual de usuario

EOLIS

InteoWindControl

InstallationandOperatingInstructions

DESCRIPTION

INSTALLATIONPROCEDURES

TheEolisshouldbemountedasclosetothemotoraspossible.If

mountedoutside,ensurethattheconnectionsarefacingdowntoavoid

rainseepage.Avoidmountingthecontrolagainstanymetallicsurface,

asthismayaffecttheradioreception.

Connecthighandlowvoltagewiresaccordingtothewiringdiagram

onthenextpage.

Makesuretouseincluded

watertightstrainrelieffittingstomaintaintheweatherproofingofthe

enclosure.

Thewindsensorshouldbeplacedclosetotheawningorshading

systemtomakesurethewindspeedismeasuredattheproduct.

Guardagainstinstallingthewindsensortooclosetoanobstruction

suchasachimney,gutterorthewindowtreatmentitself,whichcould

blockthewindandcauseerroneoussensorreadings.Thesensor

shouldnotbemorethan100feetfromthecontrol.

Thelowvoltageswitchshouldbelocatednomorethan100feetfrom

theEolisControl.

Itisrecommendedthatthelowvoltagewiringis

donefirst,foreasieraccesstotheterminals.

Removetheback

coverofthesensorandconnectthetwo-wirecable(included)fromthe

terminalsonthesensortotheterminalsonthecontrol.Refertothe

diagramonthenextpage.

ThenewSomfyEolisisasinglemotorcontroldesignedforresidential

use.Itincludesawindsensorandalowvoltageswitch.Windspeedis

continuouslymonitored,triggeringthecontroltoretractawningsor

lowershuttersautomaticallyasneeded.

Thisnewcontrolispackagedina

weatherproofenclosureandincludeswatertightstrain-relieffittingsfor

wiresenteringthebox.

Twouser-definedintermediate

positionscanbeprogrammed.

CatalogNo:6301021

CAT.NO:2500021

SOMFYSYSTEMS,INC.

47CommerceDrive

Cranbury,NJ08512

SOMFYCANADA

6315ShawsonDrive,Unit#1

Mississauga,OntarioL5T1J2

SOMFYMEXICOS.A.DeC.V.

Calle3No.47,Loc.E-5

FraccInd.AlceBlanco

Nau.,Edo.deMexC.P.53370,Mex

SOMFYSYSTEMS,INC.1/01

SOMFYSYSTEMS,INC.reservestherighttochange,

updateorimprovethisdocumentwithoutpriornotice.

DOWN

COM

DOWN

COM

OPERATINGINSTRUCTIONS

SystemSetUpOperatingProcedures

Withpoweroff,wirethecontrolasindicatedabove.Turnall

circuitbreakerson(motorsshouldnotmove).

Whenthemonitoredwindspeedisgreaterthanthesetting,the

directionwillactivateafter2seconds.Aslongasthewind

speed

remainshigh,allothercommandswillbeignored.

Whenthewindspeeddropsbelowthesetvalue,theEolis

willreturntonormaloperationfollowingaverybriefdelay.

OperateeachmotorintheDOWNdirectionbypressingthedown

arrowonthelowvoltageswitch.

hemotorizedtreatmentshouldmovedownorout.Ifthisis

incorrect,turnoffthecircuitbreakersandreversetheredand

blackwiresofthemotor.

Tochangethewindsensitivity,simplyrotatethewindadjustment

knobtothedesiredsetting.

SettingTheWindLevel

WindAdjustmentDetail

LOWVOLTAGESWITCH

WINDFUNCTION

PressingtheDOWNbuttonwillmovethewindowtreatmentdown

orout.

PressingtheUPbuttonwillmovethetreatmentuporin.

Tostopthemotorizedawningorshutteratanytime,simplypress

theSTOPbuttononthelowvoltageswitch.

31MPH

WIRINGDIAGRAM

MOTOR

WIND

SENSOR

HOT

NEUTRAL

GROUND

BLACK

RED

GREEN

WHITE

COLORCODE

WindAdjustment

NOTE:

Mountcontrolwith

fittingsfacingdownward!

WIND

DIR1

DIR2

COM

DOWN

MTRCOM

NEUT

HOT

LowVoltage

Switch
