SOLTEK SL-65MIE Manual de usuario
R
SL-65MIE
USER MANUAL V1.2
NOTICE
Product Model : SL-65MIE
Manual Revision : V1.2
Release Date : June 2 1
• Intel, Celeron, Pentium II, Pentium III are trademarks of Intel Corporation.
• Intel 82815 Graphic Memory Controller ub(GMC ), 82801 I/O Controller ub(IC ) are trade-
marks of Intel Corporation.
• VIA Cyrix III is trademark of VIA Corporation.
his Users’ Guide & Technical Reference is to help system
manufacturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for print-
ing or clerical errors. Information in this document is subject to
change without notice and does not represent a commitment on the
part of Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek Computer inc. Provides this manual “As is “ without war-
ranty of any kind, either express or implied, including but not limited
to the implied warranties or conditions of merchantability or fitness
for a particular purpose. In no event shall Soltek Computer inc. be
liable for any loss or profits, loss of business, loss of use or data,
interruption of business, or for indirect, special, incidental, or con-
sequential damages of any kind, even if Soltek Computer inc. has
been advised of the possibility of such damages arising from any
defect or error in this manual or product.
Copyright © 2001 Solt k Comput r Inc. All Rights R s rv d.
T
SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, si-Chih, Taipei-
sien, Taiwan, R.O.C.
Telephone : 886-2-2642-9060
Fax : 886-2-2642-9065
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOUL TECHNOLOGY EUROPE B.V.
Address : ongkongstraat 55 3047 BR, Rotterdam, The
Netherlands
Telephone : 31-10-2457492
Fax : 31-10-2457493
E-mail : [email protected]
Web site : http://www.soultech-europe.com
65MIE
4
C O N T E N T
CHAPTER 1 INTRODUCTION .................................... 8
1- 1 MAINBOARD SPECIFICATION ................................................... 9
1-1-1 PROCESSOR ..................................................................................... 9
1-1-2 C IPSET ............................................................................................. 9
1-1-3 INTEGRATED SDRAM CONTROLLER .............................................. 9
1-1-4 FULL FEATURED ACCELERATED GRAP ICS PORTS ................... 9
(AGP) CONTROLLER ........................................................................ 9
1-1-5 MULTI-I/O FUNCTION ...................................................................... 10
1-1-6 EXPANSION SLOTS ......................................................................... 10
1-1-7 AWARD BIOS V6.0, SUPPORTING ................................................. 10
1-1-8 SOUND CONTROLLER .................................................................... 10
1-1-9 POWER MANAGEMENT .................................................................. 10
1-1-10 FORM FACTOR .............................................................................. 11
1-1-11 ARDWARE MONITORING ........................................................... 11
1-2 MOT ERBOARD LAYOUT --- 65MIE ........................................ 12
1-3 C IPSET SYSTEM BLOCK DIAGRAM...................................... 13
CHAPTER 2 HARDWARE SETUP............................ 15
2- 1 CPU INSTALLATION ................................................................. 16
2- 2 MEMORY INSTALLATION ......................................................... 17
2- 3 SUPPORTED SYSTEM BUS AND SYSTEM MEMORY BUS
FREQUENCIES TABLE ............................................................. 18
2- 4 DD/FDD INSTALLATION ......................................................... 19
2- 5 JUMPER SETTING FOR DEVICES ON BOARD: ..................... 21
2-5-1 JUMPER JBAT1/2 FOR CLEARING CMOS DATA: .......................... 21
2-5-2 KEYBOARD POWER ON (JP2) ........................................................ 22
2-5-3 USB WAKE UP (JP3) ........................................................................ 22
2-5-4 BUS CLOCK SELECT (JP7/JP8) ...................................................... 23
2-5-5 BIOS BOOT BLOCK LOCK (JP16) ................................................... 23
Content
5
2-5-6 USB PORT SELECT (JP17/JP18) .................................................... 24
2-5-7 USB PORT SELECT (JP19/JP20) .................................................... 24
2-5-8 FACTORY DEFAULT (J1) ................................................................. 25
2-6 CONNECTORS CONFIGURATIONS ......................................... 26
2-6-1 ONBOARD FAN CONNECTOR (CPUFA1/AUXFA1/C AFA1) ......... 26
2-6-2 CD-ROM AUDIO CONNECTOR (CD32/CD33) ................................ 27
2-6-3 WAKE ON LAN FUNCTION (JWOL1) ............................................. 27
2-6-4 T ERMAL SENSOR CONNECTOR (RT2) ....................................... 28
2-6-5 COMPLEX EADER J2&J3 .............................................................. 29
2-6-6 C ASSIS PANEL CONNECTOR ...................................................... 30
2-6-7 SERIAL PORT CONNECTORS ........................................................ 31
2-6-8 SMART CARD READER CONNECTOR (SCR1) ............................. 32
2-6-9 ATX POWER SUPPLY CONNECTOR .............................................. 32
2-6-10 COMMUNICATION AND NETWORKING RISER SLOT (CNR) ...... 33
2-6-11 PS/2 MOUSE AND PS/2 KEYBOARD ............................................ 33
2-6-12 SECOND USB EADER (USB2) .................................................... 34
2-6-13 IRQS DESCRIPTION FOR VARIOUS DEVICES............................ 35
CHAPTER 3 SOFTWARE SETUP ............................ 37
3-1 INTEL C IPSET DRIVER INSTALLATION ................................. 38
3-2 INTELL ULTRA ATA STORAGE DRIVER INSTALLATION ......... 39
3-3 AC’97 DRIVER INSTALLATION .................................................. 41
3-4 INSTALLING ITE ARDWARE MONITOR UTILITY
(SMARTGUARDIAM) .................................................................. 42
CHAPTER 4 BIOS SETUP ........................................ 45
T E BIOS ......................................................................................... 45
4-1 W AT IS BIOS SETUP ............................................................... 46
4-2 OW TO RUN BIOS SETUP ...................................................... 46
4-3 W AT IS CMOS ......................................................................... 46
4-4 W AT IS POST .......................................................................... 46
4-5 BIOS UPGRADE......................................................................... 46
65MIE
6
4-5-1 BEFORE UPGRADING BIOS ........................................................... 47
4-5-2 UPGRADE PROCESS ...................................................................... 47
4-6 BIOS SETUP-- CMOS SETUP UTILITY ..................................... 51
4-6-1 STANDARD CMOS SETUP .............................................................. 52
4-6-2 ADVANCED BIOS FEATURES ......................................................... 55
4-6-3 ADVANCED C IPSET FEATURES .................................................. 60
4-6-4 INTEGRATED PERIP ERALS ......................................................... 64
4-6-5 POWER MANAGEMENT SETUP ..................................................... 69
4-6-6 PNP / PCI CONFIGURATION ........................................................... 73
4-6-7 PC EALT STATUS ........................................................................ 76
4-6-8 FREQUENCY/VOLTAGE CONTROL................................................ 77
4-6-9 LOAD OPTIMIZED DEFAULTS ......................................................... 78
4-6-10 SET SUPERVISOR / USER PASSWORD ...................................... 80
4-6-11 SAVE & EXIT SETUP ...................................................................... 81
4-6-12 EXIT WIT OUT SAVING ................................................................ 81
APPENDICES ................................................................. 82
APPENDIX-1 TEC NICAL TERMS INTRODUCTION .................... 83
APPENDIX-2 IDENTIFYING BIOS VERSION AND BIOS PART
NUMBER.................................................................... 84
APPENDIX-3 IDENTIFYING MAINBOARD / MODEL NUMBER ..... 86
Chapter 1 Introduction
7
Mainboard
Support CD
User’s Manual
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
Temperature Sensor Cable
ATA66/100 IDE Cable
RS232 Cable
FDD Cable
======ITEMLIST CHECKUP
65MIE
8
CHAPTER 1
INTRODUCTION
• This chapter briefly introduces the characteristics of this mainboard. It
includes the information regarding the chipset, CPU types, built-in
functions and layout. Users will have more ideas about mainboards after
reading this chapter.
1-1 MAINBOARD SPECIFICATION
1-2 MAINBOARD LAYOUT
1-3 CHIPSET DIAGRAM
THIS CHAPTER CONTAINS THE FOLLOWING TOPICS :
Chapter 1 Introduction
9
1- 1 MAINBOARD SPECIFICATION
1-1-1 PROCESSOR
• Supporting Intel® FC-PGA Pentium !!!TM up to 1G z.
• Supporting Intel® FC-PGA 370 Celeron & PPGA 370 Celeron up to 850M z.
• Supporting VIA Cyrix !!! up to 800M z.
• Supporting CPU voltage Auto-Detect circuit.
1-1-2 CHIPSET
• INTEL 82815 Graphics and Memory Controller ub (GMC ) & INTEL
82801BA I/O Controller ub (IC 2).
• ITE 8712 EC-LPC I/O chip.
1-1-3 INTEGRATED SDRAM CONTROLLER
• Provides 3pcs DIMM slots supporting double-sided DIMMs.
• Supporting 100/133M z SDRAM spec.
• Supporting total memory from 32MB to 512MB using 32Mb/64Mb/128Mb/
256Mb technology.
• Supporting up to 3 double sided DIMMs at 100M z system memory bus.
• Supporting up to 2 double sided or 3 single sided DIMMs at 133M z
system memory bus.
• Unbuffered , Non-ECC SDRAM only supported.
1-1-4 FULL FEATURED ACCELERATED GRAPHICS PORTS
(AGP) CONTROLLER
• Supporting 64-bit 66/ 100/ 133 M z System Bus Frequency.
• Provides 1x/ 2x/ 4x AGP controller.
• Integrated 2D & 3D Graphics Engines.
• Integrated /W Motion Compensation Engine.
• Integrated 24-bit 230 M z DAC.
• Supporting 133M z System Memory while running in non-CPC mode:
--AGP v2.0 compliant.
--Full 2D /W Acceleration.
--2D Graphics up to 1600 x 1200 in 8--bit Color at 85 z Refresh.
-- /W Motion Compensation Assistance for S/W MPEG2 Decode.
--Integrated Graphics Memory Controller can be disabled to support an
external AGP Card or PCI Graphics card.
--Provided an AGP 4X Slot which is compatible for AGP 1X/2X/4X mode
and AGP In-Line Memory Module (AIMM) up to 4 MB.
65MIE
1
1-1-5 MULTI-I/O FUNCTION
• Integrated IDE Controller.
• Supporting Ultra ATA33/66/100, BMIDE and PIO modes.
• Two UARTs for complete Serial Ports.
• One dedicated IR connector:
--Third serial port dedicated to IR function either through the two complete serial
ports or the third dedicated port Infrared-IrDA ( PSIR) and ASK( Amplitude Shift
Keyed) IR.
• Multi-mode parallel connector supporting:
--Standard mode, ECP and EPP.
• Floppy Disk connector supporting:
--Two FDDs with drive swap function.
• Universal Serial Bus connector supporting:
--USB v1.1 and Intel Universal CI v1.1 compatible.
--2 built-in USB connectors, in addition to one internal USB header which requires
a USB cable to support 2 more optional USB ports.
• PS/2 keyboard connector.
• PS/2 Mouse connector.
1-1-6 EXPANSION SLOTS
• Three PCI bus Master slots.
• One AGP 4x mode slot.
• One CNR slot.
• Three DIMM slots.
• One SCR (Smart Card Reader) slot.
1-1-7 AWARD BIOS V6.0, SUPPORTING
• Plug & Play V1.0.
• Flash Memory for easy upgrade.
• Year 2000 compliant.
• BIOS writing protection.
1-1-8 SOUND CONTROLLER
• AC 97 Link for Audio and Telephony CODECs.
• AC 97 2.1 compliant.
1-1-9 POWER MANAGEMENT
• ACPI 1.0 compliant. (Advanced Configuration and Power Interface)
• APM V1.2 compliant. (legacy power management)
• Supporting ACPI suspend POS mode. (Power On Suspend)
Tabla de contenidos
Otros manuales de Placa madre de SOLTEK
SOLTEK
SOLTEK 86SP3 Manual de usuario
SOLTEK
SOLTEK 85MR3-R Manual de usuario
SOLTEK
SOLTEK SL-845GVI Manual de usuario
SOLTEK
SOLTEK SL-67G60 Manual de uso y cuidado
SOLTEK
SOLTEK SL-K890-754G Manual de usuario
SOLTEK
SOLTEK SL-65EP Manual de usuario
SOLTEK
SOLTEK 75FRN Series Manual de usuario
SOLTEK
SOLTEK KT400 Manual de usuario
SOLTEK
SOLTEK SL-65MIV-C Manual de usuario
SOLTEK
SOLTEK SL-75DRV5 Manual de usuario
SOLTEK
SOLTEK NF4-754RL Manual de usuario
SOLTEK
SOLTEK SL-65KV2-T Manual de usuario
SOLTEK
SOLTEK SL-54A2 Manual de usuario
SOLTEK
SOLTEK KT400-R Manual de usuario
SOLTEK
SOLTEK SL-85DRS Manual de usuario
SOLTEK
SOLTEK SL-PM800I-R Manual de usuario
SOLTEK
SOLTEK SL-PT880E-R Manual de usuario
SOLTEK
SOLTEK SL-85MIR3 Manual de usuario
SOLTEK
SOLTEK SL-65DRV Manual de usuario
SOLTEK
SOLTEK 86SP2 Manual de usuario
Manuales populares de Placa madre de otras marcas
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manual de usuario
Gigabyte
Gigabyte GA-9IVDT Manual de usuario
Texas Instruments
Texas Instruments ADS8372EVM Manual de usuario
Commell
Commell MS-C73 Manual de usuario
IBT Technologies
IBT Technologies MB860 Manual de usuario
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manual de usuario
