OperationInstruction (2009EditionA)
Soloon Electronics (Beijing) Co., Ltd &
Soloon Electronics (Singapore) Co., Ltd
S6051-L2 Series LCD Thermostat
1、General
S6051-L1 Series thermostat, with multi
purpose updated and computerized
controller function, and by using
thermostat’s NTC temperature sensor and
motorized fan together, detecting the
room’s temperature condition, at the same time comparing to user desire
temperature degree, able to select the appropriate flow rate of warm air
capacity automatically, so therefore produce a comfy room’s
temperature. The manufacturer also has passed ISO 9001:2000,
approved for quality and performance control.
2、Technical Data
zPower Consumption: <1.5W
zSet-point Range: 10-30℃
zLoad Current:< 1A
zTiming Error: <1%
zAccuracy: ±1℃
zOutput Power:<200W
zDimension：86mm×86mm×13mm(length × Width × Thickness）
zPower Supply：220VAC±10%，50/60HZ
3、Symbols
“ ”Power, Turn-on/off ；
“ ”Mode, Heating/Cooling Changeover (Optional) ；
“ ”Function, order: Electric heating function→Time Adjustment →
Timing Turn-on →Timing Turn-off →Return to Original Mode ；
“ ”Fan Speed: Auto, High, Medium and Low;
“∧”Temperature up/down or setting ；
“∨”Temperature down or setting;
4、Menu & Setting
zTemperature setting
Programmable ：When it is running, temperature and Power on/off
can not be adjusted ，if it needs to be adjusted ,it must be
reprogrammed .
Manual Mode ：Can set it directly（LCD screen shows “ ”on the top
right corner）。
zHeating/Cooling Setting
Press“ ”choosing Heating/cooling Mode，press “∧” for confirm、
press “∨” for cancel
zSleeping Function Setting
Touch“ ” Function key to switch to Sleeping and when the
is flickering, please press“∧” for confirm and “∨”for cancel.
zManual setting
Manual / Programmable switchover, Touch Function “ ” key switch
to programmable (manual) ,When the “ ”is flickering, please
touch“∧” for turn up and “∨”for turn down.
zClock
Touch“ ” Function key to switch to Clock and when the
is flickering, please press “∧”Set time up；“∨”Set time down
Confirm after 5 sec.
zTiming on/of Setting
