SOLIS CREMA SL 70 Manual de usuario

Legend:

Removable water reservoir and cover

Storage plate for cups

Swivelling steam and hot-water nozzle

Hot-water/steam knob

Height-adjustable cup tray

Removable drip tray

Filter holder

Built-in grounds tamper

Filter set, containing: one-cup insert, two-cup insert

and portion-insert

Measuring spoon

Dear Customer,

Congratulations on acquiring this new Crema espresso machine, a

Swiss quality product. Please read these instructions carefully and

follow them. By doing so, you and your guests will truly enjoy your

SOLIS CREMA. Please keep these instructions in a safe place. If

you are not sure about anything or would like more information,

please ask us or your local dealer. We are always ready to help.

SOLIS LTD.

SOLIS CREMA SL 70 User’s manual

This espresso machine is partially registered and patented in

Europe and overseas.

1.0 Safety instructions Page 48

2.0 General comments Page 49

3.0 Starting up / Before using for first time Page 50

4.0 Making coffee with ground coffee Page 51-52

5.0 Making coffee with portions Page 52-53

6.0 Making hot water Page 53

7.0 Making steam Page 53-54

8.0 Pre-heating the cups Page 54

9.0 Care and cleaning Page 55

10.0 Decalcifying Page 56

11.0 Trouble-shooting Page 57

12.0 Useful tips for coffee Page 58

13.0 Recommended accessories Page 58

14.0 Technical data Page 59

Control panel:

Main switch On/Off

Pump switch

Steam switch

Coffee temperature indicator

Steam temperature indicator

OFF

SOLIS CREMA SL 70

User’s manual

Table of contents:

1.0 Safety instructions

Children do not understand how dan-

gerous electrical appliances can be.

For that reason, children should never

be allowed around electrical applian-

ces without supervision.

Do not use the appliance without stu-

dying the user manual or being shown

how to operate it.

Never use an appliance with a faulty

cord. Since special tools are needed

to replace a damaged cord, this work

must be carried by a manufacturer-

designated repair station.

Do not immerse the appliance in

water. Do not use the appliance with

wet hands.

Do not remove the filter holder while

the coffee is pouring. As the appliance

is under pressure, wait until the coffee

has stopped pouring.

The socket to which the appliance is

connected must be earthed. For your

safety, we recommend the use of an

FI safety adapter (available from all

good electricians).

Place the appliance on a firm, level

surface. The surface must not be

warm or hot. Choose a position which

is out of reach of children or pets.

Be careful when touching the steam

nozzle and filter holder as they beco-

me hot when the appliance is in ope-

ration (DANGER OF SCALDING!).

SOLIS CREMA SL 70 User’s manual

Be sure to remove the plug before

cleaning the appliance. Do not allow

the cord to come into contact with hot

parts of the appliance.

Do not expose the appliance to clima-

tic conditions (rain, snow, frost, etc).

When you unpack the appliance, plea-

se check that the voltage indicated on

the plate on the base of the appliance

is the same as your own main supply.

2.0 General comments

Do not operate the appliance without

water and coffee.

Any work on the appliance must be

carried out by authorised technicians.

Otherwise, all guarantee claims and

warranties are invalidated.

The appliance is intended for the pre-

paration of hot water, steam and cof-

fee and must not be used for any

other purpose. The appliance is desi-

gned for domestic use. If it is used for

commercial purposes, warranty condi-

tions will change. Please observe the

guarantee conditions.

The original packaging has been made

specially strong so that the appliance

can be sent by post. Please retain

the packaging in case it should be

necessary to return the appliance.

The appliance may be damaged by

freezing. For this reason, it must be

protected against frost and should not

be left overnight in a car during winter.

SOLIS CREMA SL 70

User’s manual

SERVICE

3.4 Vent the appliance.

To do this, place a large container

under the hot water/steam nozzle, turn

the rotary knob and activate the pump

switch until a steady stream of water

comes out of the nozzle. Let it run until

about 2 dl of water has been collected,

then close the rotary switch and turn off

the pump switch again. The applian-

ce has now been vented.

3.5 Rinse the appliance out. To do

this, fit the empty filter holder and place

a cup underneath. Turn the pump

switch on until the cup is full. Turn

the switch off again. The appliance

has now been rinsed out.

3.6 The appliance is ready to ope-

rate when the temperature light

shows green. We recommend leaving

the empty filter holder in place while the

appliance is heating up so that it is pre-

warmed.

3.0 Starting up

3.1 Fill the water container with

cold water up to a maximum of 3 lit-

res. Insert it into the rear of the appli-

ance and press home firmly so that the

base valve opens. Close the cover.

Note: Use only fresh cold water to fill

the container. Do not use mineral

water, milk or any other fluid.

3.2 Pull the required length of

cord out from the back of the

appliance. Leave the rest in the spe-

cial cable compartment. Connect the

appliance to an earthed socket.

3.3 Turn the main switch to ON.

The appliance must now be vented

and rinsed out.

Note: The best time to remove air from

the appliance is when it is cold. For

this reason, start the venting operation

as quickly as possible after switching

on.

SOLIS CREMA SL 70 User’s manual

IMPORTANT: Never operate the

appliance without water. For reasons

of hygiene, we would recommend you

to vent and rinse out the appliance

before it is used for the first time or

after any long period of non-use (e.g.

after the holidays).

4.0 Making coffee with ground

coffee

It is assumed that the appliance has

been started up in accordance with

Point 3 and is ready to operate, i.e.

the container has been filled with

water and the temperature light is

showing green.

4.1 With the appliance ready, fit

the appropriate filter (one-cup or

two-cup) into the filter holder.

Depending on the filter size, fill with

one or two level measuring spoons of

coffee and press down lightly with the

built-in tamper . Wipe the edge of the

filter holder to remove any coffee

grains.

4.2 Insert the filter holder into the

brewing unit by moving from left

to right and close tightly. Check that

the filter holder is fully tightened.

4.3 Place one or two cups on the

tray under the filter holder.

Note: The height of the tray can be

adjusted to take small espresso cups

simply by turning it.

4.4 Activate the pump switch

and coffee will be poured.

SOLIS CREMA SL 70

User’s manual

4.5 As soon as your cup is full,

turn off the pump switch .This will

stop the pouring.

4.6 Now remove the filter holder

from the brewing unit by moving it

from right to left. Holding the filter

firmly with the filter holder, knock out

the grounds.

Note: You can use a special SOLIS tray

for your grounds (see Section 13.0,

recommended accessories).

Rinse the filter under running water and

replace the filter holder in the brewing

unit. Once the filter has been refilled,

the next cup of coffee can be prepared.

5.0 Making coffee with portions

It is assumed that the appliance has

been started up in accordance with

Point 3 and is ready to operate, i.e.

the container has been filled with

water and the temperature light is

showing green.

5.1 The procedure is just the

same as for ground coffee, except

that the following points must be

observed.

Please prepare SOLIS coffee portions

(see adjacent illustration and section

13.0 «Recommended accessories»)

with the special portion-filter insert

only, and do not use the 1 or 2 cup fil-

ter. The portion filter is specially desi-

gned for the «hard» portion bags.

«Soft» SOLIS portions or other brand

name portions should be prepared in

the 1 or 2 cup filter as recommended

by the coffee producer.

SOLIS CREMA SL 70 User’s manual

Note: If the coffee comes out of the

sides of the filter holder, the portion is

either too big for the filter insert or the

filter holder has not been properly ins-

erted.

As all SOLIS CREMA espresso machi-

nes are fitted with both portion inserts

and one-cup and two-cup filters, you

will have no problem in using any ordi-

nary filter-paper portions, provided

that you take note of the points listed

above. However, please be sure to fol-

low the coffee manufacturer’s instruc-

tions.

6.0 Making hot water

For tea, broth, etc. It is assumed that

the appliance has been started up in

accordance with Point 3 and is ready

to operate, i.e. the container has been

filled with water and the temperature

light is showing green.

6.1 With the appliance ready,

place your glass or cup directly

under the hot water/steam nozzle

and turn the rotary knob and activate

the pump switch . The hot water

now runs automatically.

6.2 After pouring the water requi-

red, close the rotary switch and

turn off the pump switch

7.0 Making steam

For heating milk and for cappuccino or

other drinks.

It is assumed that the appliance has

been started up in accordance with

Point 3 and is ready to operate, i.e. the

container has been filled with water and

the temperature light is showing

green.

7.1 With the appliance ready,

activate the steam switch and

wait until the temperature light shows

green.

7.2 Turn the rotary knob slightly,

allowing the condensed water to run

out into the drip tray. Next, swing the

steam jet out and immerse it in the

liquid to be heated. Slowly open the

rotary switch and heat the liquid by

making circular movements from bot-

tom to top.

SOLIS CREMA SL 70

User’s manual

8.0 Pre-heating the cups

Apart from the type of blend and the

quality of the water, the most important

factor in making a good cup of coffee is

getting the right temperature.

8.1 Place your cups on the storage

plate to be kept warm (indirect hea-

ting by the radiation from the heating

system).

8.2 If you need to heat cups

quickly, you can rinse them out with

hot water from the hot water nozzle.

7.3 When no more steam is nee-

ded, turn the rotary switch off

again. Swing the steam nozzle back to

the cup tray or leave in an empty con-

tainer. Turn off the steam switch

7.4 With the steam switch off,

turn the rotary knob, activate the

pump switch again and allow the

appliance to vent/cool down until water

emerges from the nozzle in a steady

stream. Then, turn the rotary switch off

again.The appliance is now ready to

make coffee again.

IMPORTANT: After steam has been

used, the appliance must be vented

and allowed to cool (see also under

Point 3.4). The steam nozzle can beco-

me very hot. To prevent scalding, avoid

direct contact with the skin.

Note: We recommend that you clean

the steam nozzle immediately after use.

Otherwise, milk can leave residues

which are difficult to remove.

SOLIS CREMA SL 70 User’s manual

9.0 Care and cleaning

If you always keep your SOLIS CREMA

machine clean, you will be sure of

good quality coffee and will extend the

useful life of the appliance.

9.1 Daily and weekly care:

Regularly clean the water container,

the drip tray, the cup tray, the filter hol-

der and the filter inserts. Simply use

hot water and, when necessary, a non-

scouring detergent.

DO NOT place in the dishwasher!

Brewing unit: Remove coffee resi-

dues regularly and wipe with a clean

damp cloth. We recommend you to let

about half a litre of hot water run

through from time to time, as this

keeps the brewing unit clear of fat resi-

dues.

SOLIS CREMA SL 70

User’s manual

If the brewing filter becomes very stai-

ned , remove it with a screwdriver and

brush both sides thoroughly.

Filter inserts: Rinse the 1 and 2 cup

filter inserts from time to time to keep

them clean. To do so, place the filter

holder with empty filter inserts in the

SOLIS Crema, position a cup under the

filter holder and switch on the pump

until the cup is full. Switch off the

pump. The rinsing operation is now

complete.

Housing: Where necessary, the hou-

sing should be cleaned with a damp

cloth and then rubbed dry with a cloth.

IMPORTANT: The appliance must not

be immersed in water. Switch off the

appliance and remove the plug during

all cleaning and care operations.

Tabla de contenidos

Otros manuales de Cafetera de SOLIS

SOLIS

SOLIS CAFFESPRESSO pro 117 Manual de usuario

SOLIS

SOLIS Palazzo Manual de usuario

SOLIS

SOLIS Crema SL90 Manual de usuario

SOLIS

SOLIS X 100 Manual de usuario

SOLIS

SOLIS SOL8930 Manual de usuario

SOLIS

SOLIS BARISTA GRAN GUSTO Manual de usuario

SOLIS

SOLIS GRIND & INFUSE PERFETTA Manual de usuario

SOLIS

SOLIS 1,2,3 SPRESSO Oh EXPRESSO Manual de usuario

SOLIS

SOLIS BARISTA PERFECT 118 Manual de usuario

SOLIS

SOLIS BARISTA PERFETTA PLUS Manual de usuario

SOLIS

SOLIS BARISTA TRIPLE HEAT Manual de usuario

SOLIS

SOLIS SOL8920 Manual de usuario

SOLIS

SOLIS BarVista 111 Manual de usuario

SOLIS

SOLIS PERSONAL BARISTA Manual de usuario

SOLIS

SOLIS Espresso Master 113 Manual de usuario

SOLIS

SOLIS PRIMAROMA 1010 Manual de usuario

SOLIS

SOLIS GRIND & INFUSE PERFETTA Manual de usuario

SOLIS

SOLIS PRIMAROMA 1010 Manual de usuario

SOLIS

SOLIS GRIND & INFUSE PERFETTA Manual de usuario

SOLIS

SOLIS GRIND & INFUSE COMPACT Manual de usuario

SOLIS

SOLIS 109 Manual de usuario

SOLIS

SOLIS BARISTA PERFETTA PLUS Manual de usuario

SOLIS

SOLIS Master Top Guía

SOLIS

SOLIS MASTER 5000 DIGITAL Manual de usuario

Manuales populares de Cafetera de otras marcas

Taurus

Taurus Livorno 6 Manual de usuario

Delta-q

Delta-q QUICK Manual de usuario

Bunn

Bunn LCA-1 Guía de solución de problemas

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instrucciones de instalación

Saeco

Saeco Vienna Plus Sup 018M Manual de usuario

DeLonghi

DeLonghi DC300 Manual de usuario

INCAPTO

INCAPTO BXCO1470E Manual de usuario

Bosch

Bosch TASSIMO finesse TAS16B Series Manual de usuario

Exido

Exido 245-072 Manual de usuario

Animo

Animo OptiVend Choco Manual de usuario

Siemens

Siemens TQ505DF Series Manual de usuario

DeLonghi

DeLonghi ECI341 Manual de usuario

Krups

Krups KT406511 Manual de usuario

Cimbali

Cimbali M32 Classic Manual de usuario

Philips

Philips HL3844N Manual de usuario

Bosch

Bosch TES 515 SERIES Manual de usuario

Tekmatix

Tekmatix TMFM - 65 Manual de usuario

Scarlett

Scarlett SC-CM33005 Manual de usuario
