SOLAR VISION LX25 Manual de usuario

installation ManUal

LX commerciaL soLar Lighting FiXtUre

Solar Vision inc. www.solar-vision.ca info@solar-vision.ca T. 1-819-729-0450

Revision 4.0

IMPORTANT NOTES:

• Alwaysinstallthelightingxtureonthepolebeforeinstallingthebattery.

• Thelightingxtureshouldneverbehandledwithbatteryinstalledinside.

• Thebatterycompartmentcontainsa“quickconnector”toconnectthebattery.

STEP 2, 3, 4, 5

STEP 6 STEP 7

Indicator lights

INSTALLATION

1. Usingthesuppliedboltsandhardware,fastenthebatterycom-

partmenttothesolarmoduleasindicatedontheimage#1.Orien-

tationofthebatteryboxiscritical.

2. Installthelightingxtureonapolewithanouterdiameterof:

• 102mm(4in)LX25&LX50(squareorroundsleeve);

• 127mm(5in)LX95(squaresleeveonlyontheLX95);

3. Usetheproperdrillingpattern(4inor5in)attheendofthisdocu-

ment.

4. Slidethelightingxtureontopofthepole;

5. Usethe1/4”-20bolttosecuretheluminairetothepole,thedrilling

patternisattheendofthisdocument;

6. Oncethelightisinplace,openthebatteryboxdoorandinsertthe

battery.

7. Makeaquickconnectionwiththequickconnectcable;

8. Agreenindicatorlightindicatesthattheluminaireisfunctionnal.

9. Closethebatteryboxdoor,theinstallationisnowcomplete.

LEARNING DELAY

Thelightrequiresa24-hourdelaytooperateproperlyaccordingtoit’s

program.

Image #1 (step #1)

P.1/5

installation ManUal

LX commerciaL soLar Lighting FiXtUre

Solar Vision inc. www.solar-vision.ca info@solar-vision.ca T. 1-819-729-0450

Revision 4.0

Solar Module

Orientation Period Autonomy

losses

South

(≈optimal)

Annual 0%

Summer 0%

Winter 0%

East / West

Annual -17%

Summer -9.8%

Winter -28%

North

Annual -35.8%

Summer -21.6%

Winter -54.8%

ORIENTATION AND AUTONOMY 1.1 INSTALLATION GUIDELINES

Toavoidalossofautonomyandamalfunction:

• Theluminairemustbeinstalledhorizontallyandmustneverbetilted;

• Theluminairemustbeinstalledattheendofthepost;

• The luminaire must be installed in an open space with no trees or

structuresnearby,thiscouldfavoursnowaccumulationandshading;

• Thesolarmodulemustbeideallyorientedtowardsthesouth,other-

wiseseetable“ORIENTATIONANDAUTONOMY”.

Failingtofollowtheserecommendationscanresultinlossofsystemper-

formance.

FACTORSAFFECTINGAUTONOMY:

Lackofsunshine,verylowambienttemperature,snowaccumulationdue

totreesorstructuresnearby,shadingduetonearbytreesorstructures,

solarmoduleorientation(seetable),toomanyunplannedoccupancyde-

tections(road,unusualactivitiesandevents),sunshinebelowthemonthly

averages,timedelaytoohighontheoccupancysensor.

P.2/5

installation ManUal

LX commerciaL soLar Lighting FiXtUre

Solar Vision inc. www.solar-vision.ca info@solar-vision.ca T. 1-819-729-0450

Revision 4.0

1.2 STORAGE AND HANDLING:

Ifyouwishtostoretheluminaire,thebatteryneedstoberechargedbeforestoringforaperiodof15daysormore

inordertopreventdamagetothebattery.Theluminairemustbestoredat20°Croomtemperature.

The luminaire should never be manipulated when the battery is inside. Use the quick access door to

remove the battery before handling.

1.3 DEEP DISCHARGE PROTECTION

Thisprotectionsignicantlyincreasesbatterylifespan.Thisprotectionalsopreventspermanentdamagetothe

batterycausedbyverydeepdischargesduringcoldweather.When the battery reaches a 50% state of charge,

the battery is automatically disconnected from the system until it’s state of charge reaches 85% i.e.about

1dayofsunshineinsummerandabout4daysofsunshineinwinter.

1.4 DAY-NIGHT TRANSITION

The xture uses the solar panel to detect day and night periods. The night transition requires a very low

brightnesslevelfor5continuousminutes.Thisconstraintpreventsfalsenighttransitions.Avoidexposingthe

luminairetoanarticiallightsourcethatmaycausesynchronizationerrorsbysimulatingtheday.Ifthexture

operateserratically,makesurethesolarmoduleisnotcoveredwithdebrisorheavysnow.Theluminaireau-

tomaticallycorrectssynchronizationerrorsafter24hours.Theoccupancysensorhasitsownphotocell,which

doesnotactivatewhentheambientbrightnessistoohigh.

P.3/5

4.13

.45 X4

2.00

NOTE:

The installation of

the solar system

must be made

using one bolt

which passes

through the post.

Follow this drilling

pattern for the

position of holes.

The hole should be

pointing in the

direction of the

desired lighting

orientation.

DIRECTION OF LIGHTING

REV.

DESCRIPTION

DATE

PAR

DRAWING PER MODEL

15 SEP 2022

JFOL

MOUNTING HOLE

27 JUN 2022

JFOL

HOLES SIZE AND POSITION ADJUSTED

13 OCT 2020

JFOL

UPDATE OF THE NOTE

26 MAR 2020

JFOL

A A

B B

PROJECT:

WEIGHT:

THICKNESS

THE INFORMATION CONTAINED IN THIS

DRAWING IS THE SOLE PROPERTY OF

VISION SOLAIRE INC ANY

REPRODUCTION IN PART OR AS A WHOLE

WITHOUT THE WRITTEN PERMISSION OF

VISION SOLAIRE COM IS

PROHIBITED.

PROPRIETARY AND CONFIDENTIAL

DIMENSIONS ARE IN INCHES

DEFAULT TOLERANCES:

ANGULAR

1°

TWO PLACE DECIMAL

.06"

THREE PLACE DECIMAL

.031"

HOLES

.005"

MATERIAL

FINISH

DRAWN

DATE

NAME

TITLE:

SIZE

DWG. NO.

REV

SCALE: 1:5

UNLESS OTHERWISE SPECIFIED:

JFOL

24MAY2019

SHEET 1 OF 1

H44_DRL_LXZX

DO NOT SCALE DRAWING

4IN POST

DRILLING PATTERN FOR

LX & ZX

P.4/5

LX25-LX50

.45 x4

6.63

2.50

DIRECTION OF LIGHTING

NOTE:

The installation of

the lamp on the
