Socomec COUNTIS M13 Manual de usuario

CORPORATE HQ CONTACT:

SOCOMEC SAS, 1-4 RUE DE WESTHOUSE, 67235 BENFELD, FRANCE

http://www.socomec.com

SINGLE PHASE DIN RAIL ENERGY METER

COUNTIS M13

MANUAL V1.1

CORPORATE HQ CONTACT:

SOCOMEC SAS, 1-4 RUE DE WESTHOUSE, 67235 BENFELD, FRANCE

http://www.socomec.com

Statement

All rights reserve . Without the written permission of SOCOMEC, the contents of any pages an chapters

in this manual shall not be copie or repro uce or isseminate in any form. Otherwise, all

consequences shall be borne by the violator.

SOCOMEC reserves all legal rights.

SOCOMEC reserve the right to mo ify the pro uct specifications escribe in this manual without prior

notice. Before or ering, please contact our company or local agent for the latest specifications of this

pro uct.

CORPORATE HQ CONTACT:

SOCOMEC SAS, 1-4 RUE DE WESTHOUSE, 67235 BENFELD, FRANCE

http://www.socomec.com

Contents

Part 1 Product overview

1.1 Brief Intro uction --------------------------------------------------------------------------------------------------------------1

1.2 Pro uct characteristics -------------------------------------------------------------------------------------------------------1

1.3 Application ----------------------------------------------------------------------------------------------------------------------1

Part 2 General Specifications

2.1 Specifications-------------------------------------------------------------------------------------------------------------------2

2.2 Accuracy -------------------------------------------------------------------------------------------------------------------------2

2.3 RS485 Communication-------------------------------------------------------------------------------------------------------3

2.4 Environment--------------------------------------------------------------------------------------------------------------------3

2.5 Dimensions---------------------------------------------------------------------------------------------------------------------4

2.6 Wiring Diagram----------------------------------------------------------------------------------------------------------------4

Part 3. Operation Instructions

3.1 Display an Operation-------------------------------------------------------------------------------------------------------5

3.1.1Display -------------------------------------------------------------------------------------------------------------------------5

3.1.2 Button Definition-----------------------------------------------------------------------------------------------------------5

3.2 Measurement-----------------------------------------------------------------------------------------------------------------5

3.3 Setting by button--------------------------------------------------------------------------------------------------------------9

Part 4. Modbus re ister Map-------------------------------------------------------------------------------------------------14

- 1 -

Part 1 Product overview

1.1 Brief Intro uction

COUNTIS M13 energy-meter “with a white back-lighte LCD screen for perfect rea ing” are use to

measure single-phase like resi ential, utility an In ustrial application. The unit measures an isplays

various important electrical parameters; provi e a RS485 communication port for remote rea ing an

monitoring. Bi- irectional energy measurement makes the unit a goo choice for solar PV energy metering.

The compact esign an DIN rail installation provi es an easy an economical solution for your metering

eman .

COUNTIS M13 equippe with 2 channels of pulse output. The pulse constant, pulse wi th an output unit

is configurable. Built-in interfaces provi es RS485 Mo bus RTU outputs, RS485 high-spee communication

supports the highest communication rate of 9600 bps, it is an i eal choice for power energy monitoring.

Configuration is passwor protecte .

1.2 Pro uct characteristics

Measures kWh, Kvarh, KW, Kvar, KVA, PF, Hz, m , V, A, etc.

Bi- irectional measurement IMP & EXP

Two pulse outputs

RS485 Mo bus

100A irect connection

1.3 Application

COUNTIS M13 is a multi-functional single phase energy meter, esigne for power system, public facilities,

in ustrial applications an resi ential power monitoring nee s. It can also be use in AC charging pile,

solar photovoltaic an other occasions. Its complete communication function makes it very suitable for

real-time power monitoring systems.

- 2 -

Part 2 General Specifications

2.1 Specifications

Voltage： Rate Voltage ( Un) : 230V AC

Operational voltage：±20% of Un

Current： Rate Current (Ib)：5A

Max Current (Imax)：100A

Over current withstan : 30 Imax for 0.01s

Operational frequency：Rate ：50/60Hz

Range：45-65 Hz

Insulation capabilities： AC voltage withstan 4KV/1min

Impulse voltage withstan 6kV – 1.2µS waveform

Internal Power Consumption：≤ 2W.

Pulse Output 1：Configurable

Pulse Output 2：Fixe 1000imp/kWh

Display：LCD with backlit

Max rea ing：999999.9 kWh

2.2 Accuracy

Voltage：0.5%

Current：0.5%

Frequency：0.2%

Power Factor：1%

Active Power：1%

Reactive Power：±1%

- 3 -

Apparent power：±1%

Active energy：Class1

Reactive energy：Class2

2.3 RS485 Communication

Bus Type：RS485

Communication Protocol：Mo bus RTU

Bau rate：1200/2400/4800/9600bps

Mo bus A ress：1-247

Bus loa ：64pcs

Communication istance：1000m

Parity：EVEN /ODD/NONE

Data bit：8

Stop bit：1

2.4 Environment

Operating humi ity： ≤90%

Storage humi ity： ≤95%

Operating temperature： -25℃~+55℃

Storage temperature： -40℃~+70℃

Stan ar ： IEC 63052-11/IEC62053-21

Accuracy： Class 1

Installation category： CAT II

Protection against penetration of ust an water: IP51（in oor）

Insulating encase meter of protective class: II

Altitu e： ≤2000m

- 4 -

2.5 Dimensions

Height: 63 mm

Wi th: 36 mm

Length: 99 mm

2.6 Wiring Diagram

- 5 -

Part 3. Operation Instructions

3.1 Display an Operation

3.1.1 Display

When the meter is powere on, the meter will initialize an o self-checking

Display as following:

Full screen

Software version

3 Mo bus A ress

4 Bau rate

Total active energy(kWh)

3.1.2 Button Definition

In measurement mo e: Click the button, the LCD isplay will scroll

the measurements；

In Set mo e: Click the button to Switch the menu of the same level

or increase the number of igits; Long press to get out of set-up

menu an return to the menu of the previous level.

In measurement mo e, Click the button: unlock/lock,

communication setting function; long press to enter setting mo e;

In setting mo e, Click the button to move cursor (The cursor is the

number bit that is flickering in setting state); Long press for the

menu item selection confirmation an parameter mo ification

confirmation.

3.2 Measurement

Click the button, the LCD isplay will scroll the measurements.

Total kWh Import kWhExport kWhResettable kWhTotal KVarhImport KVarhExport kVarh

- 6 -

Resettable kVarh Max. Power Deman Voltage CurrentWVarVAPower factor 

FrequencyPulse ConstantMo bus ID Bau rate  Continuous Running Time

Item Display Description

1 Total kWh

Example:70.00kWh

2 Import kWh

Example: 50.00kWh

3 Export kWh

Example: 20.00kWh

Resettable kWh

Example: 2.68kWh

5 Total KVarh

Example: 10.00kVarh

6 Import KVarh

Example: 5.00kVarh

- 7 -

7 Export KVarh

Example: 5.00kVarh

Resettable kVArh

Example: 1.49kVarh

9 Max. Power Deman

Example: 6930W

10 Voltage

Example: 229.8V

11 Current

Example: 30.156A

12 Active Power (W)

Example: 4700W

13 Reactive Power (Var)

Example: 1030Var
