Socket CF Mag Stripe Reader Card Series 4 Manual de usuario

CF Mag Stripe Reader Card

Series 4

User’s Guide

9/2012 Document # 6410-00274 L

Socket, the Socket logo, Battery Friendly, SoMo, CF Mag Stripe Reader Card and

SocketScan are trademarks or registered trademarks of Socket Mobile, Inc. All other

brand and product names are trademarks of their respective holders.

The CF Mag Stripe Reader Card includes technology licensed under United States Patent

No. 5,902,991.

Reproduction of the contents of this manual without the permission of Socket Mobile is

expressly prohibited. Please be aware that the products described in this manual may

change without notice.

Feel free to contact Socket Mobile at:

Socket Mobile, Inc.

39700 Eureka Drive

Newark, CA 94560-4808

USA

Other than the above, Socket Mobile can assume no responsibility for anything resulting

from the application of information contained in this manual.

Please refrain from any applications of the CF Mag Stripe Reader Card that are not

described in this manual. Please refrain from disassembling the CF Mag Stripe Reader

Card. Disassembly of this device will void the product warranty.

You can track new product releases, software updates and technical bulletins by visiting

the Socket Mobile website at: http://www.socketmobile.com

TABLE OF CONTENTS

1 | INTRODUCTION 4

About the Software 4

Package Contents 5

System Compatibility 5

Product Registration 5

Accessory 5

Software Development Kit (SDK) 5

2 | SETUP FOR THE SOMO 7

STEP 1: Start SocketScan Plug-in 8

STEP 2: Insert the Card 9

STEP 3: Open Your Application 10

STEP 4: Swipe Data into Your Application 10

3 | SOCKETSCAN FOR WINDOWS MOBILE 11

Reader Settings 11

Dual Device Support 12

APPENDICES

A SPECIFICATIONS 13

B RESTRAINING BRACKET INSTALLATION 14

C CAB FILE INSTALLATION 16

D SETUP FOR NON SOMO PDAS 17

E SETUP FOR WINDOWS XP / VISTA 20

F SOCKETSCAN PLUG-IN FOR WINDOWS XP / VISTA 24

G TROUBLESHOOTING 25

H TECHNICAL SUPPORT 26

LIMITED WARRANTY 27

REGULATORY COMPLIANCE 29

1|INTRODUCTION

Thank you for purchasing the CF Mag Stripe Reader Card 4E. The

card reads data from one, two, or three track magnetic stripes on ID

cards, driver’s licenses, royalty cards or credit/debit cards into a

Windows Mobile, XP or Vista based computer. It’s the perfect solution

for mobile Point of Sale applications, whether you want to eliminate

long lines inside a department store or need to process credit cards

at outdoor events.

The CF Mag Stripe Reader Card is great to combine with a cellular or wireless network to

perform credit card authorizations, manage inventory and prices, and look up credit

balances and other account information on the fly. For security applications, set up a

mobile authentication system that wirelessly accesses database records for identity

verification.

The CF Mag Stripe Reader Card can also be used with voter registration cards, health cards,

and other identity documents.

Sleekly designed with no cables or batteries, the CF Mag Stripe Reader Card works in the

CompactFlash or PC Card slot of compatible mobile computers.

ABOUT THE SOFTWARE

SocketScan Plug-in™ keyboard wedge software feeds swiped data directly into any

open program, as if the data were manually typed — no custom programming is

required.

For software updates, please visit: http://www.socketmobile.com/support/downloads/

CHAPTER 1: INTRODUCTION 5

PACKAGE CONTENTS

CF Mag Stripe

Reader Card

Restraining bracket for use with

the Socket SoMo®handheld

computer

SocketScan Plug-in™

installation CD (software &

manuals)

SYSTEM COMPATIBILITY

The CF Mag Stripe Reader Card works with computers that satisfy these minimum

requirements:

•Any of the following operating systems:

-Windows Embedded Handheld

-Windows Mobile 2003, 2003SE or 5.0 for Pocket PC

-Windows Mobile 6 Classic

-Windows XP Professional/Tablet PC (SP1, SP2, SP3)

-Windows Vista Business/Ultimate (SP1)

•Available CompactFlash or PC Card slot

(Operation in a PC Card slot requires a PC Card adapter)

•Windows Mobile: Software installation requires a Windows-based host computer with the

appropriate synchronization software (ActiveSync or the Windows Mobile Device Center),

available free on the Microsoft website.

Alternatively, advanced users can install a CAB file. See Appendix B for instructions.

PRODUCT REGISTRATION

Socket highly recommends that all customers register their products. Registered users

benefit from priority technical support and can choose to receive special offers for future

products and product upgrades and the latest new product information

ACCESSORY

Socket offers a Type II CF-to-PC Card adapter, sold separately.

http://www.socketmobile.com/products/plug-in-data-capture/

SOFTWARE DEVELOPMENT KIT (SDK)

The CF Mag Stripe Reader Card uses the same SocketScan Plug-in software and SDK

used with all Socket data collection products, which also include bar code and RFID

readers. The SocketScan Plug-in SDK (not included) is required for more complex

applications using parsed or encrypted data.

To learn about the SDK, visit: http://www.socketmobile.com/products/bluetooth-barcode-

scanners/software-development-kit/

CHAPTER 2: SETUP FOR THE SOMO 7

2|SETUP FOR THE SOMO

This chapter shows how to install, configure, and use the CF Mag

Stripe Reader Card on the Socket SoMo handheld computer.

SETUP SUMMARY

STEP 1: Start SocketScan Plug-in.

STEP 2: Insert the Card.

STEP 3: Open your application.

STEP 4: Swipe data into your application!

Note: SocketScan Plug-in is pre-installed on the SoMo. You can

choose to upgrade the software if a later version is available.

Check for updates at:

http://www.socktmobile.com/support/downloads

STEP 1: START SOCKETSCAN PLUG-IN

1. Tap Start | Programs | SocketScan Plug-in folder |SocketScan Plug-in.

2. Whenever SocketScan Plug-in is running, either of two icons will appear appears at

the bottom of the Today screen.

Icon

Meaning.

No device detected.

The CF Mag Stripe Reader Card is detected and ready to use.

CHAPTER 2: SETUP FOR THE SOMO 9

STEP2: INSERT THE CARD

Note: If desired, you can choose to install the Restraining Bracket included in the

package. See Appendix Bfor instructions.

1. Open the card slot cover on the top of the SoMo and insert the CF Mag Stripe Reader

Card into the CompactFlash card slot.

Be sure to insert the card all the way into the slot.

Do not insert the card upside-down.

Do not push the card in too hard, or you can damage the card and the card slot of your

device.

Beep and LED Patterns

Note: Make sure your computer sound is turned on.

Beep

Pattern

LED Behavior

Meaning

4 Beeps Blinking Green and

Red SocketScan Plug-in detects the CF Mag Stripe Reader

Card.

No Beep Solid Green The CF Mag Stripe Reader Card is ready to swipe data.

1 Beep Momentarily OFF Successful swipe.

3 Beeps Red Bad swipe. No data read.

2. Make sure the SocketScan Plug-in icon changes to indicate that the CF Mag

Stripe Reader Card is detected.

STEP 3: OPEN YOUR APPLICATION

Open the application that you want SocketScan Plug-in to feed swiped data into (e.g.,

Excel Mobile, Notepad, etc.). Place the cursor where you want the swiped data to go.

Note: If using Excel Mobile, you may want to increase the column width to fit the data.

STEP 4: SWIPE DATA INTO YOUR APPLICATION

1. Swipe a card through the reader, with the magnetic stripe facing the computer.

Swipe smoothly in one motion, making sure the card is pressed flush against the slot

for the entire length of the card. You can swipe the card either right-to-left or left-to-

right.

2. When data is read, the LED will turn off momentarily before turning green again, and

the Pocket PC will beep once. Additionally, data will appear in you document.

If no data was read, the LED will turn red, and the Pocket PC will beep three times.

3. After data is read, it should appear in your document. The cursor will automatically

advance to the next line or cell, ready for the next swipe.
