2/28/2019 Auto Provision YOUR snom 7/D7 IP Phones for 3CX v15

https://www.3cx.com/sip-phones/snom-710-720-760/ 1/5

How to configure snom 700/ D7XX Series for 3CX

This guide applies to v15.5 only.

On this topic

Supported Models: snom 700/D7XX series

snom 700 series

snom D7XX series

End of Life

Step 1: Upgrade to the Required firmware

Step 2: Factory Reset the IP Phone

Step 3: Provision the phone

Local LAN or SBC: Provision via Plug’n’Play

Remote phones: Provision via RPS server

Step 4: Extended Phone Configuration

Known Limitations

Supported Models: snom 700/D7XX series

snom 700 series

● snom 715

snom D7XX series

● snom D712

● snom D715

● snom D725

● snom D745

2/28/2019 Auto Provision YOUR snom 7/D7 IP Phones for 3CX v15

https://www.3cx.com/sip-phones/snom-710-720-760/ 2/5

● snom D765

● snom D785

End of Life

● snom 710 **See Limitations

● snom D710 **See Limitations

● snom 720 **See Limitations

● snom 760 **See Limitations

Step 1: Upgrade to the Required firmware

Ensure that the phone is running on the required firmware by 3CX. In case the device needs manual updating

download the latest distributed required firmware by 3CX here. Read how to check what firmware the phones

are running on and how to upgrade them in this guide: How to manual upgrade snom IP phones.

Step 2: Factory Reset the IP Phone

Before provisioning the IP phone, the phone must be brought back to factory defaults in case the device has

residual settings of a previous configuration. To reset the device read our How to Factory Reset the snom 7 or

D7 series phones document.

Step 3: Provision the phone

There are several methods to provision a phone:

● Plug & Play - For phones on the local LAN or behind the 3CX SBC.

● RPS - For phones on remote networks that will connect directly to 3CX and use STUN

For more information, see “When can I use which provisioning method?”

Local LAN or SBC: Provision via Plug’n’Play

1. Connect the phone to the network. A PnP request will be sent automatically to 3CX.

2. Go to the 3CX Management Console ⇒ “Phones” page. The new phone will be marked in Bold.

3. Click on the BOLD entry and choose between “Assign Ext” or “Add Ext”, depending on whether

you want to assign the phone to an existing extension or create a new one.

2/28/2019 Auto Provision YOUR snom 7/D7 IP Phones for 3CX v15

https://www.3cx.com/sip-phones/snom-710-720-760/ 3/5

4. All major provisioning settings are pre-populated. If your PBX has multiple network cards, select to

which network this IP phone is connected.

5. Click “OK”. The phone will configure automatically and will reboot to finalize the setup.

Remote phones: Provision via RPS server

1. Take note of the phone’s MAC address, usually written at the back.

2. Navigate to the 3CX Management Console ⇒ “Phones” and press “+ Add Phone”.

3. From the dropdown list select the extension to which this phone must be assigned.

4. In the next dialog select the Vendor/Model of the phone and enter the device’s MAC address.

2/28/2019 Auto Provision YOUR snom 7/D7 IP Phones for 3CX v15

https://www.3cx.com/sip-phones/snom-710-720-760/ 4/5

5. Switch the “Provisioning Method” to “Direct SIP (Stun - Remote)” and click “OK”.

6. You can make sure that the extension is ready to be configured via RPS by checking the “Event Log”

from the dashboard:

If the message appears as a “Warning” follow the instructions outlined in the message and use the Manual

Link Provisioning method outlined here.

7. The phone is now ready to be provisioned - you can boot up the phone anywhere in the world with

access to the internet.

8. The phone will prompt for username and a password: Enter the extension number as username and

the voicemail pin as the password.

2/28/2019 Auto Provision YOUR snom 7/D7 IP Phones for 3CX v15

https://www.3cx.com/sip-phones/snom-710-720-760/ 5/5

Note: Ensure that the input mode is set to digits (green box).

Step 4: Extended Phone Configuration

IP phones can be tweaked to match the user’s needs. Those might be skipped if they are not desired and the

phone will be rolled out in a default configuration. Also they can be altered at a later stage and changes

applied via the Management Console → Phones → Select Device → Re-Provision :

● IP Phone Configuration Options, configurable per device of the extension

● IP Phone BLF/DSS assignment, global for all devices of the extension

● IP Phone Vlan management, configurable per device of extension

● Customizing the IP Phone background logo

Known Limitations

● Devices with only green BFL LED (snom710, snom715, snomD712) will show monitored extensions in

idle: ON-Green, ringing: Fast-Flash-Green and talking in Slow-Flash-Green

● Sidecar follows indication schema of the main device
