Snom IP Phone

Configuration Guides

Version 2.0

Date: September 28, 2015

Yeastar Information Technology Co. Ltd.

Snom IP Phone Configuration Guides

2/14

Contents

1. Introduction ..........................................................................................................3

2. Register with MyPBX Manually...........................................................................4

3. Provisioning for MyPBX ......................................................................................7

3.1 Phone Provisioning via PnP Mode ................................................................... 8

3.2 Phone provisioning via DHCP Mode ...............................................................11

Snom IP Phone Configuration Guides

3/14

1. Introduction

This guide shows you how to manually configure Snom IP phones with MyPBX and

how to provision the Snom IP phones with MyPBX. It has been tested with the latest

firmware version supported by MyPBX firmware version X.19.0.47.

Applicable Models:

370

360

320

300

710

715

720

760

820

821

870

Please note that different firmware revisions may have different web interface formats

and functionality.

Snom IP Phone Configuration Guides

4/14

2. Register with MyPBX Manually

1. Start up the phone and identify its IP Address by pressing the "Help" or "7"

button. For this example we will assume the IP Address of the phone is

192.168.5.126, and IP Address of the MyPBX Phone System machine is

192.168.5.250

2. Point your browser to the web interface of the phone: http://192.168.5.126.

3. We now need to set the phone to register with MyPBX Phone System. Go to

the "Setup -> Identity 1" page, and in the "Login" tab:

1) Set the "Identity Active" field to "on"

2) Set the "Display name" field to the name you want to appear on the Phone

display

3) Set the "Account" field to the extension number you want to associate with

this phone

4) Set the "Password" field to the extension's Authentication Password

5) Set the "Register" field to the IPAddress of the MyPBX Phone System –in

this example, 192.168.5.250:5060.

6) Set the "Authentication Name" field to the extension's Authentication ID

7) Set the "Mailbox" field to your system's Special Voice Mail Extension

Number.

4. Next, we need to adjust the audio parameters. Click on the "RTP" tab and set

the "RTP Encryption" field to "off" if you disable the SRTP in extension settings

Snom IP Phone Configuration Guides

5/14

of MyPBX Management Console

5. Click the "Save" button, and then click the "Reboot" button that appears at the

top of the page. Your phone will restart. After rebooting, the phone will retrieve

its configuration files and register with MyPBX Phone System. This can be

verified via the "Extension Status" page of MyPBX Management Console.

Snom IP Phone Configuration Guides

6/14

6. For some issues about function of intercom, please refer to the following

setting on Snom web interface

Snom IP Phone Configuration Guides

7/14

3.Provisioning for MyPBX

The easiest way to set up a Snom phone for use with MyPBX is to use the built-in plug

and play provisioning functionality inside MyPBX. This will allow the phone to

configure itself by retrieving a generated phone configuration file. Alternatively you

can configure using DHCP and option. For more information, see this configuration

guide.

1. Verify Firmware Installed on your Phone

Verify the firmware version currently installed on the phone as older firmware will not

have the plug and play feature. You can power up the phone and press “Menu >

Status > Firmware”to check. Go to Snom Support Website to download the latest

firmware for your phone.

2. Plug phone into the network

Plug your Snom phone into your LAN. (The Phone must be on the same LAN as that

of MyPBX IP PBX).

3. Approve phone and Assign an Extension

To do provisioning with Snom IP phones, you can choose PnP mode or DHCP mode.

When you phone provisioning via PnP mode, there is no need to set MyPBX working

as the only DHCP server any more.

Snom IP Phone Configuration Guides

8/14

3.1 Phone Provisioning via PnP Mode

Step1. Log in Snom IP phone web user interface, go to “Setup->Advanced->Update ”

to enable PnP feature on your phone.

Step2. Check MAC address of your Snom IP Phone on “Status->System

Information”page.

Step3. Reboot Snom IP phone.

Snom IP Phone Configuration Guides

9/14

Step4. Search MAC address you would like configure in “Phone Provisioning->Not

Configured Phone”page

Fill in the phone detail message on the pop-up windows.

Input Name, Call waiting, Line, Extension, Label, Line active and so on for the phone.

Snom IP Phone Configuration Guides

10/14

Step5. Save the settings and reboot the IP phone. After you save the changes,

system will prompt you to save the changes and reboot to save changes without

rebooting. Click OK to reboot the IP phone and provisioning the phone.

Then IP phone will reboot twice to apply the configurations take effect, when done,

you can find the account 506 is registered in MyPBX’s line status page and Snom IP

phone’s status page.
