Snapper PRO HYDRO SPA521 Manual de usuario

Parts Manual fo

Revision 4,

PRO HYDRO

SERIES 1 & 2

2006

McDonough, GA, 30253 U.S.A.

TP 400-5023-4-CW-N

11/7/2006 Manual No. 7006928

SNAPPER PRODUCTS, INC.

MID-SIZE WALK BEHIND MOWER

POWER UNIT

MODELS MOWER

MODELS

SPLH141KH SP360

SPLH141K

SP480

SPLH141KW

SP520

SPLH151KH SPA360

SPLH152K

SPA361

SPLH171K

SPA480

SPLH221KH

SPA481

SPLH231KH

SPA520

SPA521

SPA610

SPA611

Table Of Content

TP 400-5023-4-CW-N

Manual No. 7006928PRO HYDRO

SERIES 1 & 2 3

PAGE GROUP

4LOOP HANDLE & CONTROL ASSEMBLIES

8TRACKING CONTROL ASSEMBLY

10 OIL TANK ASSEMBLY (Model SPLH231KHE)

12 OIL TANK ASSEMBLY (All Except SPLH231KHE)

14 TANK BRACKET ASSEMBLY

16 FUEL TANK ASSEMBLY

18 REAR DECK ASSEMBLY

22 PUMP AND SHELF ASSEMBLIES

24 HOSE ASSEMBLY

26 POWER UNIT IDLER ASSEMBLY

28 TRACTION, REAR WHEEL ASSEMBLY

30 ENGINE GROUP

32 CASTER, WHEEL & TIRE ASSEMBLY

34 36" MOWER DECK ASSEMBLY (Fixed Height)

36 36" MOWER DECK ASSEMBLY (Adjustable Height)

40 48" & 52" MOWER DECK ASSEMBLY (Fixed Height)

42 48", 52" & 61" MOWER DECK ASSY (Adj. Height) Pt.1

46 48", 52" & 61" MOWER DECK ASSY (Adj. Height) Pt.2

48 36" DECK IDLER ASSEMBLY

50 48" & 61" DECK IDLER ASSEMBLY

52 52" DECK IDLER ASSEMBLY

54 CUTTER HOUSING ASSEMBLY

56 DECALS - Left & Right Panels

58 DECALS - Instructions, Caution, Warning, Danger

60 ELECTRICAL WIRING (Manual Start)

62 ELECTRICAL WIRING- LOOP HANDLE (Electric Start)

64 WIRING SCHEMATIC (Manual Start)

66 WIRING SCHEMATIC (Electric Start)

LOOP HANDLE & CONTROL ASSEMBLIES

TP 400-5023-4-CW-N

Manual No. 7006928 PRO HYDRO

SERIES 1 & 2

LOOP HANDLE & CONTROL ASSEMBLIES

Footnotes:

TP 400-5023-4-CW-N

Manual No. 7006928PRO HYDRO

SERIES 1 & 2 5

Part No Descri

tionItem Qt

Note

1 7011138 1 IGNITION KEY, Pair

2 7012685 1 NUT, 5/8-32 Hex (Ignition Switch)

3 7012686 1 NUT, 1/2-27 Hex (Special)

4 7014341 2 RETAINING RING Truarc #5133-50

5 7017817 1 SWITCH, Ignition, 2-Pole, Recoil Start (except Kohler 23HP)

5 7027698 1 SWITCH, Ignition used on Kohler 23HP

6 7022166 1 ROD, Pivot, 1/2” Dia. x 18.542 w/2 retaining Ring Grooves

7 7027141 2 SWIVEL

8 7027225 1 SWITCH, OPC, Single Pole (NC) used on Loop Handle except

Kohler 23HP

8 7023355 1 SWITCH, OPC, (NO/NC) used on Kohler 18HP

9 7028856 2 CONTROL ROD (Traction)

10 7028857 4 BEARING, Nyliner

11 7074648 1 ROD, Operator Presence Control

12 7029139 1 SPRING, OPC- Loop Handle

13 7029715 1 SWITCH, Toggle

14 7034827 1 PANEL, Left

15 7034828 1 PANEL, Right

16 7041748 1 BAIL, Operator Presence Control (Weldment)

17 7091303 4 BOLT, 5/16-18 x 1” Short Neck Carriage, GR 5

18 7090977 2 NUT, 1/4-20 Hex Jam

19 7091222 2 BOLT, 1/4-20 x 1-3/4” Hex Head Cap, GR 5

20 7091030 2 BUSHING, 1/2” Machine

21 7091122 8 SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap

22 7091297 2 NUT, 5/16-24 Hex, GR 5

23 7091299 4 NUT, 3/8-16 Hex Nyloc

24 7077873 2 SCREW, #12-14 x 1/2” Hex Flange Self-Tap

25 7091594 2 COTTER PIN, 1/2” Self-Locking

26 7091686 2 SCREW, 1/4-20 x 3/4” Hex Washer Self-Tap

27 7034820 1 WELDMENT, Traction Lever, RH

28 7034821 1 WELDMENT, Traction Lever, LH

29 7043869 1 HANDLE, Loop (Weldment)

30 7029100 1 THROTTLE CONTROL, 40.50/1.46 used on Kawasaki 14HP &

Kohler 15HP

30 7072597 1 THROTTLE CONTROL, 51.50/0.90 used on Kawasaki 17HP

30 7036431 1 THROTTLE CONTROL, 48.50/0.90 used on Kohler 23HP

31 7012080 4 CABLE TIE, 7”

32 7073118 1 * WIRE HARNESS not shown; for all models except

for Kohler 23HP

32 7073117 1 * WIRE HARNESS not shown; used on Kohler 23HP

NOTE: * See Electrical Wiring pages for Illustration.

LOOP HANDLE & CONTROL ASSEMBLIES

TP 400-5023-4-CW-N

Manual No. 7006928 PRO HYDRO

SERIES 1 & 2

LOOP HANDLE & CONTROL ASSEMBLIES

Footnotes:

TP 400-5023-4-CW-N

Manual No. 7006928PRO HYDRO

SERIES 1 & 2 7

Part No Descri

tionItem Qt

Note

33 7041692 1 * HARNESS, Wiring Pigtail not shown; used on

SPLH171KW only

33 7027226 1 * HARNESS, Wiring Pigtail not shown; used on

SPLH141KW only

33 7046901 1 * HARNESS, Regulator not shown, used on

SPLH141KWE only

34 7073141 1 SWITCH, Interlock, Sealed (NC)

34 7073140 1 SWITCH, Interlock, Sealed (NO/NC) used on Electric Start only

35 7073139 1 BRACKET, Interlock Switch

36 7090376 2 NUT, #10-32 Hex Nyloc

37 7091240 2 SCREW, #10-32 x 5/8” Hex Machine

NOTE: * See Electrical Wiring pages for Illustration.

TRACKING CONTROL ASSEMBLY

TP 400-5023-4-CW-N

Manual No. 7006928 PRO HYDRO

SERIES 1 & 2

TRACKING CONTROL ASSEMBLY

Footnotes:

TP 400-5023-4-CW-N

Manual No. 7006928PRO HYDRO

SERIES 1 & 2 9

Part No Descri

tionItem Qt

Note

1 7011879 1 GRIP, Vinyl

2 7013550 1 PIN, 3/16 x 1” Roll

3 7011121 2 WASHER, 5/8” I.D., 1-1/4” O.D. Belleville

4 7027125 1 SPRING, Compression

5 7027168 2 SCREW, 5/16-18 X 1” Hex Head Cap, GR 5

6 7027169 1 SCREW, 3/8-16 x 5” Hex Head Cap, GR 5

7 7028859 1 LEVER

8 7028860 2 BUSHING

9 7029040 4 WASHER, Slipper

10 7034803 2 PIN, Shoulder

11 7034830 1 CAM, Track

12 7034877 2 PLATE, Speed, Accutrack

13 7091299 1 NUT, 3/8-16 Hex Nyloc

14 7091706 2 NUT, 5/16-18 Hex Top Lock, GR B

15 7019376 1 HANDLE, Shift Lever

16 7059115 1 WELDMENT, Neutral Latch

17 7041772 1 TRACK, Welded

18 7091300 3 WASHER, .44 x 1.0 x .08 Flat

19 7091130 1 WASHER, .33 x .88 x .09 Flat

OIL TANK ASSEMBLY (Model SPLH231KHE)

TP 400-5023-4-CW-N

Manual No. 7006928 PRO HYDRO

SERIES 1 & 2
