Snapper LWE07B Manual de usuario

Parts Manual fo

Revision 1,

19" 120 VOLT ELECTRIC

SERIES

2005

McDonough, GA, 30253 U.S.A.

TP 400-5098-1-WB-N

9/16/2005 Manual No. 7006112

SNAPPER PRODUCTS, INC.

WALK BEHIND MOWERS

MODEL

19E07B

LWE07B

Table Of Content

TP 400-5098-1-WB-N

Manual No. 700611219" 120 VOLT ELECTRIC

SERIES 7 3

PAGE GROUP

4Upper, Middle & Lower Handles

6Deck, Wheels, & Motor

8Grass Bag, Adapter & Decals

Upper, Middle & Lower Handles

TP 400-5098-1-WB-N

Manual No. 7006112 19" 120 VOLT ELECTRIC

SERIES 7

Upper, Middle & Lower Handles

Footnotes:

TP 400-5098-1-WB-N

Manual No. 700611219" 120 VOLT ELECTRIC

SERIES 7 5

Part No Descri

tionItem Qt

Note

1 7051884 ASSEMBLY Upper Handle (Includes Item 2)

2 7014903 TUBING, Heat Shrink

3-- CONTROL,Electric B&S #399192 (Includes items 5

thru 7)

4 7014879 DECAL, Starting Procedure

5 7014907 DECAL, Circuit Breaker Reset

6 7014894 STRAIN-RELIEF, Harness

7 7015114 2 INSULATOR, Handle

8 7090894 2 SCREW, #10-24 x 1-3/8" Slotted Cap

9 7012080 2 TIE, Cable

10 7036350 HANDLE, Middle

11 7091013 2 SCREW, 5/16-18 x 2" Curved Head

12 7023735 2 KNOB, 5/16-18

13 7046502 HANDLE, Lower L.H. Was 38467

14 7035342 HANDLE, Lower R.H. Was 38466

15 7090799 4 BOLT, 5/16-18 x 5/8" Short Neck Carriage Was 91026

16 7091601 4 NUT, 5/16-18 Hex Flange Lock Was 90585

*NOTE: Purchase engine components directly from engine manufacturer dealer.

Deck, Wheels, & Motor

TP 400-5098-1-WB-N

Manual No. 7006112 19" 120 VOLT ELECTRIC

SERIES 7

Deck, Wheels, & Motor

Footnotes:

TP 400-5098-1-WB-N

Manual No. 700611219" 120 VOLT ELECTRIC

SERIES 7 7

Part No Descri

tionItem Qt

Note

1 7019712 BLADE, Cutting

2 7014262 HUB, Blade

3 7018960 FAN, Cooling (Includes item 27)

4 7047974 DECK (Weldment)

5 7032406 CLIP, Strain Relief

6 -- PLATE, Adapter *B&S #223184

7 -- MOTOR, Electric Model #748001-0326-01 *

8-- FILTER *B&S #271711

9 -- SHROUD, Motor *B&S #280413 (Includes 10 &

11)

10 7014937 DECAL, Grass Bag Warning

11 7014898 DECAL, Discharge Warning

12 7032118 2 CLIP, Guard Retaining

13 7018444 GUARD, Rear Foot

14 7013320 4 BUSHING, Height Adjusting

15 7013027 2 SPRING, Rear Axle

16 7034357 AXLE, Front & Rear Was 37946

17 7013307 Spring, Front Axle

18 7013024 4 HUB-CAP 3/8 I.D.

19 7022260 2 WHEEL, Rear 8 x 2.00 Was 19194

20 7019193 2 WHEEL, Front 7 x 1.75

21 7090871 SCREW, 5/16-24 x 1-1/4" Hex Cap Gr. 5

22 7014263 WASHER, Cone

23 7014897 WASHER, 5/8 Spring

24 7090122 2 WASHER, 3/8" Flat

25 7090799 3 BOLT, 5/16-18 x 5/8" Short Neck Carriage Was 91026

26 7011791 3 RETAINER, 5/16 Bolt

27 7015903 KEY, Square

28 7090951 3 NUT, 5/16-18 Hex Lock

29 7090541 3 SCREW, 1/4-28 x 3/4" Hex Cap

30 7090053 3 WASHER, 1/4 Internal Tooth

31 7090095 3 NUT, 1/4-28 Hex

32 7091021 3 SCREW, 5/16-24 x 3/4" Hex Cap

33 7090480 3 NUT, 5/16-24 Hex Flange Lock

34 14895 2 NUT, #10-24 Hex

35 7044640 NAME PLATE, SNAPPER Was 19279

*NOTE: Purchase engine components directly from engine manufacturer dealer.

Available through Briggs & Stratton

Grass Bag, Adapter & Decals

TP 400-5098-1-WB-N

Manual No. 7006112 19" 120 VOLT ELECTRIC

SERIES 7

Grass Bag, Adapter & Decals

Footnotes:

TP 400-5098-1-WB-N

Manual No. 700611219" 120 VOLT ELECTRIC

SERIES 7 9

Part No Descri

tionItem Qt

Note

1 7059322 KIT, Grass Bag Catcher Was 60932 (Includes 2 thru 5)

7061918 KIT, Grass Bag Catcher Was 60934 (Includes 2 thru 6)

2 7059322 ASSEMBLY, Grass Bag Was 51899 (Incl. items 2 thru 5)

3 7017069 BAG, Door Type

4 7051906 ASSEMBLY, Bag Wire

5 7042489 CONNECTOR, Grass Bag Was 47969

6 7053681 ADAPTER, Grass Bag Was 16088

7 7014808 DECAL, Warning

8 7015263 DECAL, CPSC Warning

9 -- DECAL, UL Listing Was 14893, Not Available
