Smeg SE2541 Manual de usuario

PIANI VETROCERAMICA SENSORIALI

TABLES VITROCERAMIQUES SENSITIVES

TOUCH-CONTROL CERAMIC HOBS

GLASKERAMIKKOCHFELDER MIT TASTENBEDIENUNG

ENCIMERAS VITROCERAMICAS SENSORIALES

GLASKERAMISCHE KOOKPLATEN TIPTOETSEN

Istruzioni per l'uso

Mode d'emploi

Instructions for use

Bedienungsanleitung

Instrucciones de uso

Gebruiksaanwijzing

Pagina 1 - 15

Page 17 - 31

Page 33 - 47

Seite 49 - 63

Página 65 - 79

Bladzijde 81 - 95

Contents

Installation advice................................................... 34

Installation instructions ......................................... 35

Presetting .................................................................. 35

Positioning................................................................. 35

Electrical connection ................................................. 37

Using the hob .......................................................... 39

Touch-control keys.................................................... 39

Switching on the cooking zones ............................... 41

Control disabling key................................................. 42

Switching off the cooking zones ............................... 42

Safety cut-out device ................................................ 43

Residual heat indicator ............................................. 43

Practical hints for use of the cooking zones ............. 43

General advice ........................................................ 44

Controls..................................................................... 44

Warnings................................................................... 44

Cleaning, maintenance and suggestions ............. 46

Installation advice

Touch-control ceramic hobs are particularly sensitive

electrical appliances.

Leaving aside the end result, these hobs, produced by

a specific technique, are completely different from

conventional hobs.

Since the electronic equipment is extremely sensitive,

special care must be taken when installing the hob,

which will be affected by knocks or humidity.

Moreover, because of their special structure touch-

control hobs have a built-in installation height which

exceeds 40 mm the standard maximum thickness of

ordinary hobs.

The unit below the hob has to be modified during built-

in installation and assembly.

To allow built-in installation, the engineer must remove

the front and rear stabilizer cross-pieces at each end of

the wooden unit.

Since this unit is often installed between other units, its

stability is not impaired.

However, this modification is not possible on all units.

Corner units, for example, usually have a swivel body

fixed at the bottom and top by means of a beam.

In this case, the top part cannot be removed because

the swivel body might fall if disconnected from the

stabilizer.

There may also be problems in installation if the unit

below the hob contains a built-in appliance which uses

water or produces steam (refrigerators, dishwashers,

washing machines and some types of oven).

Experience has shown that the heat generated between

the appliance and the hob without ventilation will cause

condensation which damages the hob.

Installation instructions

Presetting By connecting the device to the electric grid, the

electrical components checking procedure is

automatically activated. Numbers 1 to 9 appear in

sequence above the symbols and .

When they go out, the appliance is ready for use.

Positioning This ceramic hob can be installed in units of all kinds: in

brickwork, metal, wood, wood clad with melamine

laminates or plywood.

The opening for built-in installation must be of the

dimensions shown.

Optimum protection of the opening

The wood used in the tops of kitchen units may change

shape (e.g. swell) if humidity is present.

Apply a varnish or special adhesive to the sides of the

opening made for built-in installation to assure proper

protection.

Permitted level of protection against fire, and

instructions for use

The appliance has «type X» protection against

overheating (EN 60335-2-6/1990) and can be installed

against walls higher than the work top. For this, it is

important to leave a gap of 50 mm from the rear edge

of the unit and 110 mm from the left-hand side.

The hob is complete with a special adhesive seal «A»

which prevents any infiltration into the unit. The seal

must be carefully fixed around the edge of the opening

for built-in mounting, pressing lightly with the hand to

ensure that it sticks.

Remove the paper protection and place the hob on the

seal.

The seal guarantees a waterproof finish and a perfectly

smooth work top. Fix the hob to the unit using the

brackets already fitted to the appliance.

N.B. - The appliance must be installed by a skilled

engineer in accordance with the regulations in force in

your country.

Always disconnect the appliance from the electricity

supply before any adjustments, maintenance, etc.

Electrical

connection

Make sure that the mains electricity supply in the home

is of the voltage and power indicated on the date plate

underneath the hob.

The power supply lead is not supplied.

Use a cable of type H05RRF or H05RNF, bearing in

mind that the earth wire (yellow-green) must be about

20 mm. Longer at the end for connection to the

appliance. Make sure that the lead is not in contact with

heated zones.

On installation, provide an omnipolar circuit breaker

with minimum distance between contacts at least 3 mm

on the appliance power supply line, at a point easily

reached from the appliance.

The options for connection to the electrical mains are

indicated in the tables below or on the data plate

underneath the hob.

Cables H 05 RRF - H 05 RNF 230V~ 400V 3N~ 400V 2N~

Minimum gauge in mm22,5 1,5 2,5

To access the terminal board press the two side tabs as

indicated on the terminal board cover.

Modify the arrangement of the jumpers on the terminal

board if necessary, then fix the wires, making sure that

the earth wire is about 20 mm longer.

Fix the power supply lead to the terminal and pass it

through the hole in the lid.

Before making the connection to the electrical

mains and using the ceramic hob, check that the

protective lid has been fixed back in place, and

ensure that the earth connection is in good working

order.

N.B. NEVER TOUCH THE ELECTRONIC CIRCUIT

BOARD IN ANY CIRCUMSTANCES.

Our company declines any responsibility for injury

or damage deriving from failure to make the earth

connection or inadequate connection to earth.

Using the hob

The appliance has 4 cooking zones of different

diameter and power. Their positions are clearly

indicated by rings and the heat is only released inside

the diameters marked on the hob.

Radiant high-light zones switch on after a few

seconds and have 9 heat settings (minimum 1,

maximum 9).

This device is equipped with capacitive recognition

keys. Touching any of the keys with a fingertip will

activate the corresponding command. The appliance

will recognize your request and give a short beep.

Touch-control keys (see page 40)

Mod. SE 2741 Mod. SE 2752

1Front left-hand cooking zone 210 (120) 1400+700 W 210 (120) 1400+800 W

2Back left-hand cooking zone 145 1200 W 145 1200 W

3Back right-hand cooking zone 180 1800 W 170 x 265 1400+800 W

4Front right-hand cooking zone 145 1200 W 180 1800 W

5Dual circuit light switch-on

6Residual heat indicators by zone (+60°C) ("H"blinking)

7Master on/off key

8Control disabling key

9Cooking zone controls

10 Heat power regulator switch (9 positions - from 1 to 9)
