Smeg Dishwasher CA01-3 Manual de usuario
INSTRUCTION MANUAL
W
WA
AR
RN
NI
IN
NG
GS
SA
AN
ND
DR
RE
EC
CO
OM
MM
ME
EN
ND
DA
AT
TI
IO
ON
NS
S,
,G
GU
UI
ID
DE
EF
FO
OR
RT
TH
HE
EU
US
SE
EO
OF
FB
BA
AS
SK
KE
ET
TS
S
A
AN
ND
DF
FO
OR
RC
CL
LE
EA
AN
NI
IN
NG
GD
DI
IS
SH
HW
WA
AS
SH
HE
ER
RS
S
Contents
11
1. Description of the controls________________________________12
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
The individual sections are laid out to provide you with a step-by-step
guide to all your appliance's functions; the texts are easy to understand
and are complete with detailed illustrations.
This user-friendly manual will provide answers to all your questions
about use of the dishwasher.
For any other information about use and maintenance of the dishwasher,
read the enclosed manual carefully.
USER INSTRUCTIONS: useful information is provided for the use of the
washing programs and all the dishwasher's functions.
12
1. Description of the controls
1.1 Front panel
All the dishwasher controls are grouped on the front panel, which is of
different shape depending on the model.
1WASHING PROGRAM SELECTOR
2ON/OFF BUTTON
3
4
ECO PROGRAM BUTTON
5
POWER ON LIGHT
RECESSED DOOR HANDLE
35 1
4
35 1
4
2
2
SETTING THE WASHING PROGRAM
To select the most suitable washing program, refer to the table below
which indicates the recommended washing according to dish type and
the degree of soiling.
After using the table to identify the most appropriate washing program,
turn the PROGRAM SELECTION knob (1) (see section "3. Description
of the controls") to set the program of choice by aligning the pointer with
the program number.
Now simply pressing the ON/OFF key (2) will start the program.
The PILOT LIGHT (4) lights up.
User instructions
TABLE OF PROGRAMS
13
Only run the soak program with half loads.
(*) Reference program as per EN 50242 standard.
(–) Not present.
(1) Average power consumption with the softener set on level 2.
(2) The cycle duration and power consumption may vary according to the water and room
temperatures, and the type and amount of dishes.
The washing cycle will not take place if the dishwasher door is left open
or not properly closed.
DURATION CONSUMPTION
CYCLE SWITCH AND
BUTTON
TYPE AND DEGREE
OF DIRT ON DISHES
PROGRAM
SEQUENCE MINUTES
(2)
WATER
LITRES (1)
POWER
KWh (2)
SOAK
PANS AND DISHES
PENDING COMPLETION
OF THE LOAD
Cold prewash 6 4 0,01
NORMAL
65°C
PANS AND DISHES
WITH NORMAL DIRT
Cold prewash
Wash at65°C
2cold rinses
Rinse at65°C
Dry
130 24 1,65
INTENSIVE
65°C
VERY DIRTY PANS AND
DISHES, EVEN WITH
DRIED-ON DIRT
Cold prewash
Wash at65°C
Cold rinse
Rinse at65°C
Dry
180 21 1,62
DAILY
65°C
DISHES WITH
NORMAL DIRT
Wash at65°C
Cold rinse
Rinse at65°C
Dry
170 161,60
ECONOMY
55°C (*) + ECO BUTTON
DISHES WITH
LIGHT DIRT
Wash at55°C
Cold rinse
Rinse at65°C
Dry
160 17 1,05
RINSE
DISHES FOR RINSING
AND DRYING
Cold rinse
Rinse at65°C
Dry
70 11 0,90
1
2
3
4
4
5
User instructions
User instructions
14
Before starting a washing program make sure that:
•The water supply tap is open.
•The correct amount of detergent has been added to the
dispenser.
•The baskets have been correctly loaded.
•The spray arms are able to rotate freely and without
obstruction.
•The dishwasher door is securely closed.
CANCELLING THE CURRENT PROGRAM
To cancel the program in progress the dishwasher must be switched off
by pressing the ON/OFF key (2).
Turn the program selector to SOAK and wait for the dishwasher to start.
On completion of the program, switch off the dishwasher by pressing the
ON/OFF key (2).
1.2 Washing programs
CHANGING THE PROGRAM
To change the program in progress the dishwasher must be switched off
by pressing the ON/OFF key (2).
Turn the program selector to the program required and then switch the
dishwasher on again by pressing ON/OFF key (2). The dishwasher will
carry out the new program automatically.
35 1
4
35 1
4
2
2
User instructions
15
TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT
•Always try to run the dishwasher fully loaded.
•Do not wash the dishes in running water.
•Use the washing program that is most appropriate for each type of
load.
•Do not carry out any preliminary rinsing.
•If available, connect the dishwasher to a hot water supply up to 60°C.
•When possible, disable the drying cycle and leave the door open at
the end of the washing cycle: the residual air and heat will dry the
dishes perfectly.
TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT
THE ENVIRONMENT
The phosphates contained in dishwasher detergents are harmful to the
environment. To avoid using excessive amounts of detergent and to save
on electricity, observe the following:
•separate the more delicate items from dishes that are more resistant
to aggressive detergents and high temperatures;
•do not pour the detergent directly on the dishes.
35 1
4
35 1
4
2
2
16
If it is necessary to open dishwasher door during the washing cycle,
there will be a 1-minute delay before the program can be resumed.
After correctly closing the door, the washing program will start again from
where it was interrupted. This operation may negatively affective the
progress of the washing cycle.
END OF CYCLE
At the end of the washing program the selector will be on one of the
STOP markers, depending on the program carried out.
Switch off the dishwasher by pressing the ON/OFF key (2) (see section
"3. Description of the controls").
REMOVING THE DISHES
At the end of the washing program, wait at least 20 minutes before
removing the dishes, to allow them to cool down. To prevent any water
droplets on the upper basket from falling on the dishes in the lower
basket, it is advisable to unload the lower basket first, and then the
upper basket.
35 1
4
35 1
4
2
2
User instructions
User instructions
17
ADJUSTING THE WATER SOFTENING SYSTEM
The dishwasher is equipped with an device for the user to adjust the
water softening system according to the hardness of the water supply.
According to the machine model, the selector which acts on the
adjustment may be located:
•inside the plastic locking ring located on the right-hand side, inside
the dishwasher;
•inside the water softener, just below the cap.
Both allow for adjustment to 5settings:
WATER HARDNESS TABLE
WATER HARDNESS
German Degrees (°dH) French Degrees (°dF) SETTING
0 - 4 0 - 7 Setting N. 1 NO SALT
5 - 15 8 - 25 Setting N. 1
16 - 23 26 - 40 Setting N. 2
24 - 31 41 - 60 Setting N. 3
32 - 47 61 - 80 Setting N. 4
48 - 58 81 - 100 Setting N. 5
Contact your local water board for information on the hardness of your
water supply.
INSTRUCTION MANUAL
W
WA
AR
RN
NI
IN
NG
GS
S
A
AN
ND
D
R
RE
EC
CO
OM
MM
ME
EN
ND
DA
AT
TI
IO
ON
NS
S,
,
G
GU
UI
ID
DE
E
F
FO
OR
R
T
TH
HE
E
U
US
SE
E
O
OF
F
B
BA
AS
SK
KE
ET
TS
S
A
AN
ND
D
F
FO
OR
R
C
CL
LE
EA
AN
NI
IN
NG
G
D
DI
IS
SH
HW
WA
AS
SH
HE
ER
RS
S
Contents
1. Safety and operating instructions __________________________28
2. Installation and hook-up _________________________________31
3. Operating instructions ___________________________________35
4. Cleaning and maintenance _______________________________47
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
The individual sections are laid out to provide you with a step-by-step
guide to all your appliance's functions; the texts are easy to understand
and are complete with detailed illustrations.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
This user-friendly manual will provide answers to all your questions
about use of the dishwasher.
INSTALLATION INSTRUCTIONS: these are intended for the qualified
technician who must carry out the installation, hook-up and testing of
the appliance.
USER INSTRUCTIONS: useful advice is provided for the use of baskets,
spray arms, containers and filters.
