Compact Electro-pneumatic Regulator

Series ITV0000

Compact and lightweight electro-pneumatic regulator

Compact Elctro-pneumatic Regulator

Series

ITV0000

 Cable connectors

Straight type and right angle type are available.

 Built-in One-touch fitting

 With error indication LED

 Brackets

Flat and L brackets are available.

• Equivalent to IP65

• Linearity within ±1% (full span)

Hysteresis 0.5% (full span)

Repeatability ±0.5% (full span)

•

High-speed response time 0.1sec (without load)

• High stability

Stable pressure control is possible even when a metal

cylinder is used.

Mist separator

(0.01 µm or less) (0.3 µm or more)

ITV (Electro-pneumatic regulator)

Air filter

(5 µm or less)

(Precision regulator)

Full scale

Model

ITV001

ITV003

ITV005

ITV009

Pressure

range

0.1MPa

0.5MPa

0.9MPa

–100kPa

Power supply

voltage

24VDC

12VDC

Output signal

Analog output

1 to 5V

Option

• Cable connectors

Straight type

Right angle type

• Brackets

Flat bracket

L bracket

Input signal

4 to 20mA

0 to 20mA

0 to 5VDC

0 to 10VDC

Flat bracket L bracket

Lightweight100g

Compact15mm

With a simplified high-density circuit

board design, an extremely

compact size has been achieved.

Stations can easily be

increased or decreased

due to DIN rail mount

design.

Straight type Right angle type

Realizes space savings

and reduction of weight

for manifold use

Features 1

PWR

ERR

How to Order

Single unit and single unit for manifolds

ITV00 1 0 3 N

Cable connector (option)

Without cable connector

Straight type 3m

Right angle type 2m

Nil

ø4

ø5/32"

Nil

Bracket

(option for single unit only)

Without bracket

Nil

Base type

For single unit

For manifold

9∗

Pressure range

0.1MPa

0.5MPa

0.9MPa

–100kPa

∗Option

Built-in One-touch fitting type

0∗

1∗

2∗

Input signal

Current type 4 to 20mADC

Current type 0 to 20mADC

Current type 0 to 5VDC

Current type 0 to 10VDC

∗Option

1∗

Power supply voltage

24VDC

12 to 15VDC

∗Option

Manifolds

IITV00 02 n

Stations

2 stations

3 stations

10 stations

…

Option

Flat bracket

L bracket

PWR

ERR

For single unit

Nil

SUP

(VAC) EXH

(ATM)

Metric size

(light gray)

Inch size

(orange)

Metric size

(light gray)

Inch size

(orange)

OUT xzc

For manifolds

SUP

(VAC) EXH

(ATM)

OUT xzc

ø6

ø1/4"

ø4

ø5/32"

ø6

ø1/4" How to Order Manifold Assemblies (Example)

IITV00-03 ............1 set (Manifold part number)

∗

ITV0030-3MS

...

2 sets [Electro-pneumatic regulator part number (1, 2 stations)]

∗

ITV0030-3ML

...

1 set [Electro-pneumatic regulator part number (3 stations)]

Note: Due to the common supply/exhaust feature,

different pressure range combinations are not available.

ITV0030-3MS

ITV0030-3ML

DIN rail

PWR

ERR

PWR

ERR

PWR

ERR

Dside

1 2 3 ...

Symbol

Indicate the part numbers of electro-pneumatic regulators and options to be

mounted below the manifold part number.

The asterisk (∗) specifies mounting.

Add an astarisk (∗) at the beginning of electro-pneumatic regulator part

numbers to be mounted.

Example)

Due to the common supply/exhaust feature, note that different pressure range

combinations are not available.

Indicate part numbers in order starting from the first

station on the D side.

Note) A DIN rail with the length specified by the number of stations is

attached to the manifold. For dimensions of the DIN rail, refer to

page 8.

If a DIN rail longer than the

specified stations is required,

specify the applicable stations

in two digits.

(Maximum10 stations)

Example) IITV00-05-07

Compact Electro-pneumatic Regulator

Series ITV0000

Specifications

Voltage

Current

consumption

Voltage type

Current type

Voltage type

Current type

Analog output

Model

Minimum supply pressure

Maximum supply pressure

Set pressure range

Maximum flow rate

Power supply

Input signal

Input impedance

Output signal

Linearity

Hysteresis

Repeatability

Sensitivity

Temperature characteristics

Operating temperature range

Enclosure

Connection type

Connection size

Weight Note 1)

24VDC ±10%, 12 to 15VDC

0 to 5VDC, 0 to 10VDC

4 to 20mADC, 0 to 20mADC

Approx. 10kΩ

Approx. 250kΩ

Within ±1% (full span)

Within ±0.5% (full span)

Within 0.2% (full span)

Within ±0.12% (full span)/°C

0 to 50°C (with no condensation)

Equivalent to I

P65∗

Built-in One-touch fitting

100g or less (without options)

ITV001

0.2MPa

0.001 to 0.1MPa

3.5l/min (ANR)

(Supply pressure:

0.2MPa)

6l/min (ANR)

(Supply pressure:

0.6MPa)

6l/min (ANR)

(Supply pressure:

0.6MPa)

2l/min (ANR)

(Supply pressure:

–101kPa)

ITV003

Set pressure + 0.1MPa

0.001 to 0.5MPa

ITV005

0.001 to 0.9MPa

ITV009

Accessories (Optional)

Bracket Cable connector

For single unit

Manifold

Metric size

Inch size

Metric size

Inch size

Set pressure

1kPa

101kPa

1 to

100kPa

1.0MPa

Power supply voltage 24VDC type: 0.12A or less

Power supply voltage 12 to 15VDC type: 0.18A or less

1 to 5 VDC (Load impedance: 1kΩor more)

Output accuracy: Within ±6% (full span)

z, x, c: ø4

z, x, c: ø5/32"

z, c: ø6, x: ø4

z, c: ø1/4", x: ø5/32"

Flat bracket assembly

P39800022

L bracket assembly

P39800023

Straight type

M8-4DSX3MG4

Right angle type

ELWIKA-KV4408 PVC025 2M

Note 1) Indicates the weight of a single unit.

For IITV00-n

Total weight (g) ≤Stations (n) x 100 + 130 (Weight of end block A, B assembly) + Weight (g) of DIN rail

Note 2) Specifications other than the following are optional.

Pressure range: 0.1MPa, 0.5MPa, 0.9MPa, Power supply voltage: 24VDC, Input signal: 0 to 10VDC

Note 3) When there is a downstream flow consumption, pressure may become unstable depending on piping

conditions.

∗ When used under conditions equivalent to IP65, use the regulator after piping a fitting/tube to the breathing hole.

(For details, refer to "Specific Product Precautions 1" on page 11.)

Compact Electro-pneumatic Regulator Series ITV0000

Working Principle

Block diagram

When the input signal rises, the air supply solenoid valve (1) turns ON. Due to this, part of the supply pressure passes through the

air supply solenoid valve (1) and changes to output pressure. This output pressure feeds back to the control circuit (4) via the

pressure sensor (3). Here, pressure corrections continue until output pressure becomes proportional to the input signal, enabling

output pressure that is proportional to the input signal.

Working principle diagram

Control circuit (4)

Power supply

Input signal

Air supply solenoid valve (1) Exhaust solenoid valve (2)

Pressure sensor (3)

Power supply and

error LED indication

Output signal

SUP

EXH OUT

Control circuit (4)

Air supply solenoid

valve (1)

Exhaust solenoid

valve (2)

Pressure sensor (3)

Discharged to atmosphere

Output pressure

Input signal +

–

Supply pressure

Series ITV0000

Series ITV001

Linearity, hysteresis

0 255075

0.6

0.8

0.4

0.2

0.6

0.4

0.2

0.8

100

Output deviation factor % F.S.

Input signal % F.S.

Out

Return

Series ITV003

Out

Return

Out

Return

Repeatability

1234

–1

–0.5

0.5

Output deviation factor % F.S.

Repetition

Pressure characteristics

0.15 0.16 0.17 0.18 0.19

0.5

0.20

Output deviation factor % F.S.

Supply pressure MPa

Flow characteristics

0 1 1.50.5 2 2.5 3 3.5

100

120

Set pressure kPa

Flow rate l/min (ANR)

20kPa

40kPa

60kPa

100kPa

10kPa

With 50% of signal input

Supply pressure: 0.2MPaSet pressure: 0.05MPa

With 50% of signal input

Supply pressure: 0.6MPaSet pressure: 0.25MPa

Linearity, hysteresis

0255075

0.6

0.8

0.4

0.2

0.6

0.4

0.2

0.8

100

Output deviation factor % F.S.

Input signal % F.S.

Repeatability

1234

0.5

Output deviation factor % F.S.

Repetition

Pressure characteristics

0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9

0.5

1.0

Output deviation factor % F.S.

Supply pressure MPa

Flow characteristics

0213456

100

200

500

400

300

600

Set pressure kPa

Flow rate l/min (ANR)

Out

Return

100kPa

200kPa

300kPa

400kPa

500kPa

50kPa

80kPa

Compact Electro-pneumatic Regulator Series ITV0000

Series ITV005

Linearity, hysteresis

0255075

–1

–0.6

–0.8

–0.4

–0.2

0.6

0.4

0.2

0.8

100

Output deviation factor % F.S.

Input signal % F.S.

Repeatability

1234

0.5

Output deviation factor % F.S.

Repetition

With 50% of signal input

Supply pressure: 1.0MPa

Set pressure: 0.45MPa

Pressure characteristics

0.4 0.6 0.8 1.0

0.5

1.2

Output deviation factor % F.S.

Supply pressure MPa

Flow characteristics

0123456

200

300

100

400

900

800

500

600

700

1000

Set pressure kPa

Flow rate l/min (ANR)

Out

Return

Out

100kPa

200kPa

300kPa

800kPa

900kPa

600kPa

500kPa

400kPa

50kPa

Series ITV009

With 50% of signal input

Linearity, hysteresis

0255075

0.5

100

Output deviation factor % F.S.

Input signal % F.S.

Repeatability

1234

0.5

Output deviation factor % F.S.

Repetition

Pressure characteristics

120

100

0.5

Output deviation factor % F.S.

Supply pressure MPa

Flow characteristics

0 1 1.50.5 2 2.5 3 3.5

120

100

Set pressure kPa

Flow rate l/min (ANR)

Out

Return

Out

Return

–100kPa

–10kPa –20kPa

–40kPa

–60kPa

–80kPa

Return

700kPa

Series ITV0000

Dimensions

Single unit

M8 x 1

Cable connection threads

Flat bracket

(optional)

2-M3 x 0.5 thread depth 3.5

Bracket mounting hole

OUTx

SUPz

VACz

EXHc

ATMc

Cable connector (4-wire)

Right angle type (optional)

L bracket

(optional)

Cable connector (4-wire)

Straight type (optional)

L bracket

(optional)

Flat bracket

(optional)

Breathing holeNote)

(M3 x 0.5)

OUT port

(ø4, ø5/32")

EXH, ATM port

(ø4, ø5/32")

SUP, VAC port

(ø4, ø5/32")

PWR

ERR

38

4-ø6

6-ø3.5

2-ø3.5

Minimum bending

radius 80

Minimum bending

radius 80

2-ø6

+50

3000

15 35

8.7

(30.9)

714

8.3

4.3

9.9

ø4

ø10.2

3.4

513.7

Body

No.

ITV00 

ITV009

EXHSUP

ATMVAC

OUT

Port position

zxc

ø4.5

3.7 3.7

Note) When used under conditions

equivalent to IP65, use the regulator

after piping a fitting/tube to the

breathing hole.

(For details, refer to "Specific

Product Precautions 1" on Page 11.)

Compact Electro-pneumatic Regulator Series ITV0000

Dimensions

Single unit for manifolds

M8 x 1

Cable connection threads

Bushing assembly

OUTx

Breathing hole Note)

(M3 x 0.5)

OUT port

(ø4, ø5/32")

15 15

18.5

26.5

2.7

3.7

Note) For dimensions of the cable connector, refer to single unit on page 6.

Note) When used under the conditions equivalent

to IP65, use the regulator after piping a

fitting/tube into a breathing hole.

(For details, refer to "Specific Product

Precautions 1" on Page 11.)

PWR

ERR

Series ITV0000

Otros manuales para ITV0000 Series

Tabla de contenidos

Otros manuales de Controladores de SMC Networks

SMC Networks

SMC Networks LEYG25M Manual

SMC Networks

SMC Networks JXC5H Manual de usuario

SMC Networks

SMC Networks LEFS Series Manual de usuario

SMC Networks

SMC Networks ITV1000-IO Series Manual de usuario

SMC Networks

SMC Networks LEF Series Manual de usuario

SMC Networks

SMC Networks CRA1 Series Manual de usuario

SMC Networks

SMC Networks JXCL1 Series Manual de usuario

SMC Networks

SMC Networks PSE200-M Series Manual de usuario

SMC Networks

SMC Networks VBA10A Manual de usuario

SMC Networks

SMC Networks CRJ Series Manual de usuario

SMC Networks

SMC Networks PSE300 Series Manual de usuario

SMC Networks

SMC Networks IR1000 Series Manual de usuario

SMC Networks

SMC Networks EX260-SPR1 Manual de usuario

SMC Networks

SMC Networks LEY series Manual de usuario

SMC Networks

SMC Networks ITV1000-CC Series Manual de usuario

SMC Networks

SMC Networks MY3 Series Manual de usuario

SMC Networks

SMC Networks LEJ Series Manual de usuario

SMC Networks

SMC Networks Sentry 5000-32-IT Manual de usuario

SMC Networks

SMC Networks ITV0000 Series Manual de usuario

SMC Networks

SMC Networks LEJS Series Manual de usuario

SMC Networks

SMC Networks AR20MK Series Manual de usuario

SMC Networks

SMC Networks LECP6 Series Manual de usuario

SMC Networks

SMC Networks HYC Series Manual de usuario

SMC Networks

SMC Networks ClimateWorx FieldServer ProtoNode FPC-N34 Guía del usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
