COLOUR SURVEILLANCE CAMERA UK 8 B1

IAN 273338

105x148mm

COLOUR SURVEILLANCE

CAMERA

Assembly, operating and safety instructions

FARB-ÜBERWACHUNGS-

KAMERA

Montage-, Bedienungs- und Sicherheitshinweise

GB/IE Assembly, operating and safety instructions Page 5

DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 19

Before reading, unfold both pages containing illustrations and familiarise yourself with all

functions of the device.

Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich

anschließend mit allen Funktionen des Gerätes vertraut.

100x148mm

white

yellow

5GB/IE

Introduction....................................................................... Page 7

Intended use............................................................................ Page 7

Description of parts................................................................. Page 8

Technical Data ........................................................................ Page 8

Scope of delivery.................................................................... Page 9

Safety instructions....................................................... Page 10

Installing the camera................................................. Page 12

Hooking up the camera.......................................... Page 13

Adjusting the camera................................................ Page 14

Troubleshooting ............................................................ Page 14

Cleaning and Care....................................................... Page 15

Storage ................................................................................. Page 15

Disposal................................................................................ Page 15

Warranty and Service.............................................. Page 16

Warranty Declaration............................................................. Page 16

Service address....................................................................... Page 16

Information about the EU declaration

of conformity.................................................................... Page 17

6 GB/IE

List of pictograms used

Read the instructions!

Safety instructions

Directions for use

Spray-proof

DANGER: These symbols with the label “DANGER“ signify

a danger which can lead to

serious injury or death

not

observed. To avoid the da

nger, follow

the instruction.

WARNING: These symbols with the label

“

WARNING“

signify a danger which can lead to serious injury or death

if not observed. To avoid the danger, follow the instruction.

Keep out of reach of children!

Dispose of the packaging and the product in an

environmentally compatible manner!

7GB/IE

Colour Surveillance Camera UK 8 B1

Introduction

Congratulations on the purchase of your new camera. You

have selected a high quality product. Familiarise yourself

with the product before using it for the ﬁrst time. In addition,

please carefully refer to the instructions for use and the safety instruc-

tions below. Only use the product as described and for its indicated

purpose. The instructions for use are a part of this product. Keep these

instructions. If you pass the product on to anyone else, please ensure

that you also pass on all the documentation with it.

Please read first

Observe the laws in the country of use before installing surveillance

cameras. Areas under surveillance must be marked so a person can

identify the area being monitored or related notices before entering

the area.

Intended use

The surveillance camera is a consumer electronics device. It is suitable

for indoor use and in protected outdoor areas to monitor garages, car

parks, entrances, etc. The camera has a night vision function with 8 in-

frared LEDs to light the area under surveillance. A microphone is also

integrated, which can record surrounding sounds. It will transmit on tel-

evision receivers/monitors and record with video input (Cinch). Any

use other than that described above or any modiﬁcation of the product

is not permissible and will result in damage. The manufacturer is not

8 GB/IE

liable for damage caused by improper use. The product is not intended

for commercial use.

Description of parts

(see front ﬂap)

1camera

2pre-drilled holes

3locking screw

4extension cable

5screws

6dowel

7mains adapter

Technical Data

Camera:

Type of device: UK 8 B1

Measurements: approx. 4.3 x 9.0 x 7.0cm (W x H x D)

Image sensor: ¼ CMOS, 640 x 480 pixel

Focal length: 6mm

Resolution (horizontal TV lines): 380

Picture angle: 35°

Infrared LED lighting (each): 850nm, 1.5 V, 60mW

Infrared range (Night vision

mode black and white): 5m

Light sensitivity: 0.5LUX

Electronic shutter speed: 1/50sec. ~1/100000 sec.

S/R ratio: >48dB

Operating temperature: -10°C – +50°C

9GB/IE

Humidity during use: ≤ 85% RH

Storage temperature: -20°C to +60°C

Connectivity: TV, DVR, VCR via Cinch

Extension cable: 18m

Protection type: IP44 (splash-proof)

Power supply (for dry indoor use only):

Model/type: NBS05B120030VK

Manufacturer: Mass Power electronic limited

Input voltage: 100–240V AC, 50/ 60Hz

Input current: 0.2A

Output voltage: 12V DC

Output current: 0.3 A

Protection class: II/

Operating temperature: -10°C – +45°C

Humidity during use: ≤ 85% RH

Storage temperature: -20°C to +60°C

Scope of delivery

Remove all parts from the packaging and remove all packaging mate-

rial. Verify the product is complete and undamaged immediately after

unpacking. If parts are missing or defective, please contact the manu-

facturer within two days.

1 camera

1 mains supply

1 extension cable

3 wall plugs

3 screws

1 set of assembly instructions and instructions for use

10 GB/IE

Safety instructions

Damage due to failure to comply with these operating instructions

will invalidate the warranty! We assume no liability for consequential

damage! We assume no liability for material damage or personal

injury due to improper handling or failure to comply with the safety

instructions!

DANGER TO LIFE AND RISK

OF ACCIDENTS FOR INFANTS AND CHILDREN!

Never leave children unsupervised with the packaging

material. The packaging material represents a danger

of suffocation. Packaging materials are not toys. Children fre-

quently underestimate the dangers. Please keep out of the reach

of children at all times.

This device may be used by children age 8 years and up, as well

as by persons with reduced physical, sensory or mental capacities,

or lacking experience and/or knowledge, so long as they are su-

pervised or instructed in the safe use of the device and understand

the associated risks.

Never allow children to play with this device. Cleaning and user

maintenance should not be performed by children without

supervision.

DANGER TO LIFE! During installation keep children away from

the area in which you are working. A large number of screws and

other small parts are included within the scope of delivery. These

may prove life-threatening if swallowed or inhaled.

This product emits infrared rays.

Never use the product if it is damaged in any way.

Contact your service centre or a specialist if the product is dam-

aged, needs to be repaired or if there is another problem with it.
