3PERFORMANCE AND CHARACTERISTICS
With ARM-based 32-bit SCM, high integration of hardware and more reliable;
480x272 LCD with backlight, multilingual interface (including English, Chinese or other languages) which
can be chosen at the site, making commissioning convenient for factory personnel;
Improved LCD wear-resistance and scratch resistance due to hard screen acrylic;
Silicon panel and pushbuttons for better operation in high/low temperature environment;
RS485 communication port enables remote control, remote measuring, remote communication via
ModBus protocol;
Fitted with CANBUS port and can communicate with J1939 genset. Not only can you monitor
frequently-used data (such as water temperature, oil pressure, engine speed, fuel consumption and so on)
of ECU machine, but also control start, stop, raising speed and speed droop via CANBUS port;
Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire systems with voltage
120/240V and frequency 50/60Hz;
Collects and shows 3-phase voltage, current, power parameter and frequency of Bus/Gens;
For Bus, controller has loss of phase and reverse phase sequence detection functions; For generator,
controller has over voltage, under voltage, over frequency, under frequency, over current, over power,
reverse power, loss of phase, reverse phase sequence detection functions;
Synchronization parameters: Voltage Difference Between Bus and Gens, Frequency Difference Between
Bus and Gens, Phase Difference Between Bus and Gens;
Multiple running modes in auto state: with load running, off load running, demand parallel running;
Ramp on and ramp off function;
3 fixed sensors (temperature, oil pressure and liquid level);
2 configurable sensors can be set as sensor of temperature, oil pressure or fuel level;
More kinds of curves of temperature, oil pressure, fuel level can be used directly and users can define the
sensor curves by themselves;
Precision measure and display parameters about Engine,
Temp. (WT) °C/°F (unit) both be displayed
Oil pressure (OP) kPa/psi/bar(unit) all be displayed
Fuel level (FL) % (unit)
Speed (SPD) r/min (unit)
Battery Voltage (VB) V (unit)
Charger Voltage (VD) V (unit)
Hour count (HC) can accumulate Max. 65535 hours
Start times can accumulate Max. 65535 times
Protection: automatic start/stop of the gen-set, ATS (Auto Transfer Switch) control with perfect fault
indication and protection function;
All output ports are relay output;
