Smartgen HGM9120 Manual de usuario

HGM9120 Genset AMF Controller

USER MANUAL

Smartgen Technology

Chinese trademark

English trademark

Smartgen —make your generator smart

Smartgen Technology Co., Ltd.

No.28 Jinsuo Road

Zhengzhou

Henan Province

P. R. China

Tel: 0086-371-67988888/67981888

0086-371-67991553/67992951

0086-371-67981000(overseas)

Fax: 0086-371-67992952

Web: www.smartgenindia.in

Email: [email protected]

(including photocopying or storing in any medium by electronic means or other) without the

written permission of the copyright holder.

Applications for the copyright holder‟s written permission to reproduce any part of this

publication should be addressed to Smartgen Technology at the address above.

Any reference to trademarked product names used within this publication is owned by their

respective companies.

Smartgen Technology reserves the right to change the contents of this document without

prior notice.

Software Version

Date

Version

Note

2014-04-14

1.0

Original release

This manual is suitable for HGM9120 controller only.

Clarification of notation used within this publication.

SIGN

INSTRUCTION

NOTE

Highlights an essential element of a procedure to ensure correctness.

CAUTION!

Indicates a procedure or practice, which, if not strictly observed, could

result in damage or destruction of equipment.

WARNING!

Indicates error operation may cause death, serious injury and significant

property damage.

HGM9120 Genset Controller

HGM9120 Genset Controller Version: 1.0 2014-04-14 Page 4 of 58

CONTENTS

1OVERVIEW..............................................................................................................................................6

2PERFORMANCE AND CHARACTERISTICS..............................................................................7

3SPECIFICATION................................................................................................................................. 10

4OPERATION..........................................................................................................................................11

4.1 INDICATOR LIGHT........................................................................................................................... 11

4.2 KEYFUNCTIONS.............................................................................................................................12

4.3 LCD DISPLAY...................................................................................................................................14

4.3.1 Main Display.......................................................................................................................... 14

4.3.2 Parameters Setting Menu...................................................................................................... 16

4.4 AUTO START/STOP OPERATION...................................................................................................18

4.5 MANUALSTART/STOPOPERATION..............................................................................................19

4.6 SWITCH CONTROLPROCEDURES...............................................................................................20

4.6.1 HGM9120 Switch Control Procedures.................................................................................. 20

5 PROTECTION..............................................................................................................22

5.1 WARNINGS ......................................................................................................................................22

5.2 SHUTDOWNALARM........................................................................................................................24

5.3 TRIPAND STOPALARM..................................................................................................................26

5.4 TRIPALARM.....................................................................................................................................27

6WIRINGS CONNECTION............................................................................................. 28

7SCOPES AND DEFINITIONS OF PROGRAMMABLE PARAMETERS ......................31

7.1 CONTENTSAND SCOPES OF PARAMETERS ..............................................................................31

7.2 ENABLE DEFINITION OF PROGRAMMABLE OUTPUTPORTS....................................................40

7.2.1 Custom Period Output........................................................................................................... 44

7.2.2 Custom Combined Output..................................................................................................... 44

7.3 DEFINED CONTENTS OF CONFIGURABLE INPUT PORTS (ALLACTIVEWHEN CONNECTTO

GRAND (B-)) ...........................................................................................................................................46

7.4 SELECTION OF SENSORS.............................................................................................................48

7.5 CONDITIONS OF CRANK DINSCONNECTSELECTION...............................................................49

HGM9120 Genset Controller

HGM9120 Genset Controller Version: 1.0 2014-04-14 Page 5 of 58

8PARAMETERS SETTING............................................................................................ 50

9SENSORS SETTING ...................................................................................................51

10 COMMISSIONING........................................................................................................52

11 TYPICAL APPLICATION .............................................................................................53

12 INSTALLATION............................................................................................................ 54

13 GSM SHORT MESSAGE ALARM AND REMOTE CONTROL.................................... 56

13.1 GSM SHORTMESSAGEALARM ..............................................................................................56

13.2 GSM SHORTMESSAGE REMOTE CONTROL ........................................................................56

14 FAULT FINDING ..........................................................................................................58

HGM9120 Genset Controller

HGM9120 Genset Controller Version: 1.0 2014-04-14 Page 6 of 58

1OVERVIEW

HGM9120 genset controller is used for genset automation and monitor control system of

single unit to achieve automatic start/stop, data measure, alarm protection and “three

remote”(remote control, remote measuring and remote communication); especially for

auto mains failure (AMF) system composed by generator and mains. This module also can

be used as auto start module or engine control module.

HGM9120 genset controller adopts 32 bits micro-processor technology with precision

parameters measuring, fixed value adjustment, time setting and threshold adjusting and

etc. The majority of parameters can be set using front panel and all the parameters can be

adjusted and monitored using PC (via Link port).It can be widely used in a number of

automatic genset control system with compact structure, simple connections and high

reliability.

HGM9120 Genset Controller

HGM9120 Genset Controller Version: 1.0 2014-04-14 Page 7 of 58

2PERFORMANCE AND CHARACTERISTICS

♦AMF (Automatic Mains Failure) function; also can be used as a single genset auto start

module by shielding mains signal or as an engine control module simply by shielding

generator signal in parameter setting interface.

♦With ARM-based 32-bit SCM, highly integrated hardware, new reliability level.

♦132x64 LCD with backlight; English interface.

♦Improved LCD wear-resistance and scratch resistance due to hard screen acrylic;

♦Silicon panel and pushbuttons for better operation in high/low temperature environment;

♦Equipped with RS232/GSM communication port. “Three remote”(remote control, remote

measuring and remote communication) function will be implemented if it is used as

monitoring port (use MODBUS RTU protocol), while SMS (Short Message Service)

function will be implemented if it is used as GSM port (GSM MODEM must be fitted,

SG361 module produced by Smartgen is recommended.) When genset is alarming,

controller can send short messages via SMS automatically to max. 5 telephone numbers.

besides, generator status can be controlled and checked using SMS.

♦Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire

systems with voltage 120/240V and frequency 50/60Hz;

♦Collects and shows 3-phase voltage, current, power parameter and frequency of

generator or mains.

Mains Generator

Line voltage (Uab, Ubc, and Uca) Line voltage (Uab, Ubc, and Uca)

Phase voltage (Ua, Ub, and Uc) Phase voltage (Ua, Ub, and Uc)

Phase sequence Phase sequence

Frequency Hz Frequency Hz

Load

Current IA, IB, IC, IE

Each phase and total active power kW

Each phase and total reactive power Kvar

Each phase and total apparent power kVA

Each phase and average power factor PF

Accumulate total generator power kWh, kVarh, kVAh

♦For Mains, controller has over and under voltage, over and under frequency, loss of

HGM9120 Genset Controller

HGM9120 Genset Controller Version: 1.0 2014-04-14 Page 8 of 58

phase and phase sequence wrong detection functions; For generator, controller has

over and under voltage, over and under frequency, loss of phase, phase sequence

wrong, over and reverse power, over current functions;

♦Earth current detection function (earth fault protection);

♦There are 7 analog sensors, among which 5 are fixed sensors (temperature, oil pressure,

liquid level, oil temperature and canopy temperature) and other 2 are configurable

sensors (can be set as temperature sensor, oil pressure sensor or fuel level sensor);

♦Precision measure and display parameters about Engine,

Temp. (WT) °C/°F both be displayed

Oil pressure (OP) kPa/Psi/Bar all be displayed

Fuel level (FL) %(unit)

Speed (SPD) r/min (unit)

Voltage of Battery (VB) V (unit)

Voltage of Charger (VD) V (unit)

Hour count (HC) can accumulate to max. 65535 hours.

Start times can accumulate to max. 65535 times.

♦Protection: automatic start/stop of the gen-set, ATS(Auto Transfer Switch) control with

perfect failure indication and protection function;

♦All output ports are relay-out;

♦Parameter setting: parameters can be modified and stored in internal FLASH memory

and cannot be lost even in case of power outage; most of them (with the exception of

scheduled start/stop and alternative configured function only) can be adjusted using

front panel of the controller and all of them can be modified using PC via Link port.

♦More kinds of curves of temperature, oil pressure, fuel level can be used directly and

users can define the sensor curves using front panel by themselves;

♦Multiple crank disconnect conditions (speed sensor, oil pressure, generator frequency)

are optional;

♦Power on mode can be set (stop mode, manual mode and auto mode can be chosen);

♦PLC (programmable logic controller) function allows the controller can be

flexibly applied to complex applications;

♦Be applicable to high voltage units; voltage transformer can be externally connected with

AC voltage input ports.

♦Sampling frequency range: 10Hz~600Hz; It can be used not only in conventional

HGM9120 Genset Controller

HGM9120 Genset Controller Version: 1.0 2014-04-14 Page 9 of 58

50/60Hz units, but also in 400Hz units.

♦Widely power supply range DC(8~35)V, suitable to different starting battery voltage

environment;

♦100 pieces event logs; real-time clock; scheduled start & stop generator (can be set as

start genset once a day/week/month whether with load or not); scheduled not start (this

function can be set in the evening to prevent disturbing the residents);

♦Can be used as an indicating instrument (indicate and alarm are enable only, relay is

inhibited );

♦With maintenance function. Actions (warning and shutdown) can be set when

maintenance time out;

♦Fuel usage protection. Fuel consumption rate can be set to monitor the fuel usage.

♦Waterproof security level IP55 due to rubber seal installed between the controller

enclosure and panel fascia;

♦Metal fixing clips enable perfect in high temperature environment;

♦Modular design, anti-flaming ABS plastic enclosure, pluggable connection terminals and

embedded installation way; compact structure with easy mounting.

HGM9120 Genset Controller

HGM9120 Genset Controller Version: 1.0 2014-04-14 Page 10 of 58

3SPECIFICATION

Items

Contents

Operating Voltage

DC8.0V to DC35.0V, Continuous Power Supply.

Power Consumption

<3W (standby ≤0.9W)

Alternator Input Range

3-Phase 4-Wire

3-Phase 3-Wire

Single-Phase 2-Wire

2-Phase 3-Wire

AC15V - AC 360V (ph-N)

AC30V - AC620V (ph-ph)

AC15V - AC360V (ph-N)

Alternator Frequency

50Hz /60Hz

Speed sensor voltage

1.0V to 24.0V (RMS)

Speed sensor Frequency

10,000 Hz (max.)

Start Relay Output

7 A DC28V at supply output

Fuel Relay Output

7 A DC28V at supply output

Shutdown Alarm Output

7 A DC28V at supply output

Common Alarm Output

7 A DC28V at supply output

Mains Close Output

7A AC250V voltage free output

Gen Close Output

7A AC250V voltage free output

Programmable Relay Output (1)

7 A DC28V at supply output

Programmable Relay Output (2)

7A AC250V voltage free output

Case Dimension

237mm x 172mm x 45.8mm

Panel Cutout

214mm x160mm

C.T. Secondary

5A rated

Working Conditions

Temperature: (-25~+70)°C; Humidity: (20~93)%RH

Storage Condition

Temperature: (-25~+70)°C

Protection Level

IP55 Gasket

Insulating Intensity

Apply AC2.2kV voltage between high voltage terminal

and low voltage terminal;

The leakage current is not more than 3mA within 1min.

Net Weight

0.72kg

Tabla de contenidos

Otros manuales de Controladores de Smartgen

Smartgen

Smartgen HES7120-PV Manual de usuario

Smartgen

Smartgen HGM6100N Series Manual de usuario

Smartgen

Smartgen HGM8140D Manual de usuario

Smartgen

Smartgen HSC960 Manual de usuario

Smartgen

Smartgen HGM1790N Manual de usuario

Smartgen

Smartgen HGM4100LT Manual de usuario

Smartgen

Smartgen HMC9000 Manual de usuario

Smartgen

Smartgen HGM410DC Manual de usuario

Smartgen

Smartgen HGM7100N Series Manual de usuario

Smartgen

Smartgen HMU15 Manual de usuario

Smartgen

Smartgen HAT600P Series Manual de usuario

Smartgen

Smartgen HAT833 Series Manual de usuario

Smartgen

Smartgen FPC1700 Manual de usuario

Smartgen

Smartgen HAT552 Manual de usuario

Smartgen

Smartgen HGM6100LT SERIES Manual de usuario

Smartgen

Smartgen HEM4000 Manual de usuario

Smartgen

Smartgen HAT600R Series Manual de usuario

Smartgen

Smartgen HGM400 Series Manual de usuario

Smartgen

Smartgen HGM410E Manual de usuario

Smartgen

Smartgen APC715 Manual de usuario

Smartgen

Smartgen HAT828 Manual de usuario

Smartgen

Smartgen HGM6100U2C Series Manual de usuario

Smartgen

Smartgen GENSET CONTROLLER MGC310 Manual de usuario

Smartgen

Smartgen HAT163 Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
