SMART SPNL-4055 Manual de usuario

Help us make this document better

smarttech.com/docfeedback/170800

SMARTBoard® 4000 series

interactive flat panels

USER’S GUIDE

FOR MODELS SPNL-4055, SPNL-4065, SPNL-4075 AND SPNL-4084

smarttech.com/kb/170800

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

Licenses

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

FCC warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

Trademark notice

SMARTBoard, SMARTNotebook, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of SMARTTechnologiesULC in

the U.S. and/or other countries. Windows is either a registered trademark or a trademark of Microsoft Corporation in the U.S. and/or other countries. All other

third-party product and company names may be trademarks of their respective owners.

or translated into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to

change without notice and does not represent a commitment on the part of SMART.

This product and/or use thereof is covered by one or more of the following U.S. patents:

www.smarttech.com/patents

05/2016

i smarttech.com/kb/170800

Important information

WARNING

lFailure to follow the installation instructions shipped with the interactive flat panel could

result in injury and product damage which may not be covered by the warranty.

lDo not open or disassemble the interactive flat panel. You risk electrical shock from the high

voltage inside the casing. Opening the casing also voids the warranty.

lDo not stand (or allow children to stand) on a chair to touch the surface of the interactive flat

panel. Rather, mount the product at the appropriate height.

lTo reduce the risk of fire or electric shock, do not expose the interactive flat panel to rain or

moisture.

lIf the interactive flat panel requires replacement parts, make sure the service technician

uses replacement parts specified by SMARTTechnologies or parts with the same

characteristics as the original.

lEnsure that any cables that cross the floor to the interactive flat panel are properly bundled

and marked to avoid a trip hazard.

lUseonly extension cords and outlets that can fully accommodate the interactive flat panel’s

polarized plug.

lUse the power cable provided with the interactive flat panel. If a power cable is not

supplied with the interactive flat panel, please contact your supplier. Use only power cables

that match the AC voltage of the power outlet and that comply with your country’s safety

standards.

lIf the glass is broken, do not touch the liquid crystal. To prevent injury, handle glass

fragments with care when disposing of them.

lUse only VESA®-approved mounting hardware.

lDo not insert objects inside the cabinet ventilation holes, because they could touch

dangerous voltage points and cause electric shock, fire or product damage which may not

be covered by the warranty.

lDo not place any heavy objects on the power cable. Damage to the cable could cause

shock, fire or product damage which may not be covered by the warranty.

IMPORTANT INFORMATION

ii smarttech.com/kb/170800

lDisconnect all the interactive flat panel’s power cables from the wall outlet and seek

assistance from qualified service personnel if any of the following occurs:

oThe power cable or plug is damaged

oLiquid is spilled into the interactive flat panel

oObjects fall into the interactive flat panel

oThe interactive flat panel is dropped

oStructural damage, such as cracking, occurs

oThe interactive flat panel behaves unexpectedly when you follow operating

instructions

iii smarttech.com/kb/170800

Contents

Important information i

Chapter 1: About your interactive flat panel 1

SMARTBoard 4055 interactive flat panel feature highlights 1

SMARTBoard 4065 interactive flat panel feature highlights 2

SMARTBoard 4075 interactive flat panel feature highlights 3

SMARTBoard 4084 interactive flat panel feature highlights 3

Included accessories 4

Other documentation and resources 5

Specifications 5

Installation instructions 5

Training 5

Knowledge base 5

This chapter describes the features of your SMARTBoard® 4000 series interactive flat panel and

provides information about product parts and accessories.

SMARTBoard 4055 interactive flat panel feature

highlights

Designed for classrooms, the SMARTBoard® 4055

interactive flat panel combines a premium touch

experience with the power of SMARTNotebook®

collaborative learning software on a 55" (139.7 cm) display.

CHAPTER 1

ABOUT YOUR INTERACTIVE FLAT PANEL

2 smarttech.com/kb/170800

The high-definition LED display features low friction coated glass that enables fingers to glide

smoothly over the surface, creating a natural touch experience. The interactive flat panel virtually

eliminates glare and provides an optimal view from any angle in the classroom. It delivers an

unparalleled viewing and writing experience and offers the best value for classrooms. With eight

simultaneous touch points for Windows, multiple students can use gestures, like zoom, rotate and

flip, at the same time.

SMARTBoard 4065 interactive flat panel feature

highlights

Designed specifically for classrooms, the SMARTBoard

4065 interactive flat panel combines a premium touch

experience with the power of SMART Notebook

collaborative learning software on a 65" (164.5 cm)

display.

The high-definition LED display features low-friction

coated glass that lets fingers glide smoothly over the

surface, creating a natural touch experience. The

SMARTBoard 4065 interactive flat panel virtually

eliminates glare and provides an optimal view from any

angle in the classroom. It delivers an unparalleled

viewing and writing experience, and offers the best

value for classrooms. With eight simultaneous touch points for Windows, multiple students can use

gestures, like zoom, rotate and flip, at the same time.

CHAPTER 1

ABOUT YOUR INTERACTIVE FLAT PANEL

3 smarttech.com/kb/170800

SMARTBoard 4075 interactive flat panel feature

highlights

Designed specifically for classrooms, the SMART Board

4075 interactive flat panel combines a premium touch

experience with the power of SMART Notebook

collaborative learning software on a 75" (190.5 cm) LED

display.

The interactive flat panel’s 4K ultra-high-definition

display provides optimal image clarity and features low-

friction coated glass that lets fingers glide smoothly over

the surface, creating a natural touch experience. The

SMARTBoard 4075 interactive flat panel virtually

eliminates glare and provides an optimal view from any

angle in the classroom. It delivers an unparalleled

viewing and writing experience, and offers the best value for classrooms. With 10 simultaneous

touch points for Windows operating systems and one touch point for Mac computers, multiple

students can use gestures, such as zoom, rotate and flip, at the same time.

SMARTBoard 4084 interactive flat panel feature

highlights

Designed specifically for classrooms, the SMARTBoard

4084 interactive flat panel combines a premium touch

experience with the power of SMARTNotebook

collaborative learning software on a 84" (213.4 cm)

display.

The 4K ultra-high-definition resolution display provides

optimal image clarity and features low-friction coated

glass that lets fingers glide smoothly over the surface,

creating a natural touch experience. The SMARTBoard

4084 interactive flat panel virtually eliminates glare and

provides an optimal view from any angle in the

classroom. It delivers an unparalleled viewing and

writing experience, and offers the best value for classrooms. With 10 simultaneous touch points for

Windows operating systems and one touch point for Mac computers, multiple students can use

gestures, such as zoom, rotate and flip, at the same time.

CHAPTER 1

ABOUT YOUR INTERACTIVE FLAT PANEL

4 smarttech.com/kb/170800

Included accessories

The following accessories are included with your interactive flat panel.

Pen and pen tray

Two pens are included with your interactive flat panel.

Remote control

The remote control enables you to access the on-screen menus and to change the display and

input settings.

Included cables

VGA - RGB video input

Power cable for your region: AU/NZ, NA, UK or EU

USB cable - touch interface
