SMART KAPP42 Manual de usuario

Help us make this document bett er

smarttech.com/docfeedback170769

USER’S GUIDE

FOR MODEL KAPP42

smarttech.com/kb/170769

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

Trademark notice

DViT, kapp, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of SMARTTechnologiesULC in the U.S. and/or other

countries. Apple, App Store, iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries. Android and GooglePlay are trademarks

of Google Inc. The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative

Commons 3.0 Attribution License. The Bluetooth word mark is owned by the Bluetooth SIG, Inc. and any use of such marks by SMARTTechnologiesULC is under

license. All other third-party product and company names may be trademarks of their respective owners.

translated into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to change

without notice and does not represent a commitment on the part of SMART.

This product and/or use thereof covered by one or more of the following U.S. patents.

www.smarttech.com/patents

10/2014

i smarttech.com/kb/170769

Important information

WARNING

lYour SMART product includes instructions for installation on metal and wood stud walls and

certain masonry wall types only. A SMART hardware kit is available for these types of

installation (Part No. 1024563). In the event that you need to install your SMART product on

reinforced concrete walls, walls with plaster lath finishing or other types of walls, refer to

your local building authority for instructions, recommendations and safe work practices.

lDo not open or disassemble the SMART product. You risk electrical shock from the high

voltage inside the casing. Opening the casing also voids your warranty.

lEnsure that any cables extending across the floor to your SMART product are properly

bundled and marked to avoid a trip hazard.

lEnsure your installation complies with local building and electrical codes.

lFailure to follow the installation instructions shipped with your SMART product could result in

personal injury and product damage which may not be covered by your warranty.

lTo reduce the risk of fire or electric shock, do not expose the SMART product to rain or

moisture.

lUse SMART supplied mounting hardware or hardware that is designed to properly support

the weight of your product.

lUse the power cable provided with this product. If a power cable is not supplied with this

product, please contact your supplier. Use only power cables that match the AC voltage of

the power outlet and that comply with your country’s safety standards.

lDo not place any heavy objects on the power cable. Damage to the cable could cause

shock, fire or product damage which may not be covered by your warranty.

iii smarttech.com/kb/170769

Contents

Important information i

Chapter 1: Welcome 1

About your capture board 1

About this guide 3

Other documentation and resources 3

Specifications 3

Installation instructions 3

Tutorial and Help 4

Training 4

Frequently asked questions 4

Support center and knowledge base 4

This chapter introduces you to your SMARTkapp™ capture board and this guide.

About your capture board

The SMARTkapp capture board enables you to collaborate with others in a simple but powerful

way. Write and draw on the capture board like you would a regular dry erase board. You can then

connect a Bluetooth®-enabled mobile device to the capture board by scanning a QuickResponse

(QR) code or by tapping the NearField Communication (NFC) tag. When you first connect your

mobile device, you’re directed to the AppleAppStore or GooglePlay™ to download the

SMARTkapp app. After you download and install the app, you can use it to connect to your

capture board and share content with others.

The SMARTkapp capture board product consists of the following components:

lCapture board

lDry erase markers and eraser

lMounting bracket and hardware

lSMARTkapp app

CHAPTER 1

WELCOME

2 smarttech.com/kb/170769

Capture board

The capture board features SMART’s proprietary DViT® (DigitalVisionTouch)

technology on a 42" (107cm) writing surface. DViT technology captures the

notes you make on the capture board using the dry erase markers and eraser.

The capture board’s Bluetooth® 4.0 wireless technology (for Apple mobile

devices) or Bluetooth 2.1 + EDR wireless technology (for Android™ mobile

devices) then transfers your notes as a digital image to a connected mobile

device. Alternatively, you can save your notes to a FAT-formatted USB drive by

connecting it to the capture board’s USB 2.0 Type-A receptacle. You can also

use the capture board’s standard 500 mA USB 2.0 Type-A receptacle to charge

your smart phone.

Dry erase markers and eraser

Your capture board comes with three dry erase markers and an eraser that are specially designed

to work with the captureboard.

The capture board includes holders for one marker and the eraser as well as a storage area (on the

back of the capture board) for the other two markers.

Use the markers to write or draw, and use the eraser to erase.

Mounting bracket and hardware

You can mount your capture board on a wall using the supplied mounting bracket and hardware.

Alternatively, you can mount the capture board using a standard VESA® 400 mm × 400 mm

mounting bracket.

CHAPTER 1

WELCOME

3 smarttech.com/kb/170769

SMARTkapp app

The SMARTkapp app enables you to connect your Apple or Android mobile device to your

capture board and then do the following:

lView notes you write on your capture board on your mobile device

lShare your notes with others

lSave your notes

About this guide

This guide explains how to use your capture board. It includes the following information:

lHow to use your capture board and the SMARTkapp app

lHow to maintain your capture board for years of use

lHow to troubleshoot issues with your capture board

This guide is intended for individuals who use and maintain capture boards. Other documentation

and resources are available for individuals who install capture boards.

Other documentation and resources

SMART provides an extensive library of documentation and resources for your capture board.

Specifications

The

SMARTkapp 42" capture board specifications

(smarttech.com/kb/170770) define the

captureboard’s dimensions, weight, recommended operating and storage temperatures, power

specifications and other important information.

Installation instructions

Your capture board comes with installation instructions that explain how to mount the

captureboard using the supplied mounting bracket and hardware.

If you misplaced the installation instructions, you can download them from

smarttech.com/kb/170768.

CHAPTER 1

WELCOME

4 smarttech.com/kb/170769

Tutorial and Help

When you first start the SMARTkapp app on your mobile device, a tutorial opens. This tutorial

explains how to connect your mobile device to your capture board and share and save your notes

(see

Installing the app and starting it for the first time

on page8).

If you want to view the tutorial subsequent times, you can open it by pressing Settings on the

app home screen and then pressing Tutorial. You can also view troubleshooting and support

information in the Help.

Training

The SMART training website (smarttech.com/trainingforbusiness) includes an extensive library of

training resources you can refer to when learning how to use your capture board.

Frequently asked questions

For answers to common questions about the capture board, see

SMARTkapp capture board

frequently asked questions

(smarttech.com/kb/170793).

Support center and knowledge base

The Support center (smarttech.com/support) includes documentation and a knowledge base that

you can refer to when performing maintenance on your capture board or troubleshooting issues

with your captureboard.
