Smart Technologies Smart Board Manual de usuario
Installation Guide
FCC Warning
This equipment has been tested and found to comply with the limits for a "Class B" digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception (this can be determined by turning the equipment off and on) the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this "Class B" digital device that have not been expressly approved by SMART
Technologies Inc. could void the user's authority to operate the equipment.
z
z
z
z
All rights reserved.
Contents
Contents
The SMART Board ................................................................................... 1
Supplied SMART Board Software ................................................................................ 1
About this Guide ........................................................................................................... 2
Installing the SMART Board.................................................................... 3
Before You Begin: Unpacking and Checking Components .......................................... 3
Attaching the Pen Tray to the Whiteboard.................................................................... 4
Finding and Marking a Suitable Location...................................................................... 8
Attaching the Wall Bracket ........................................................................................... 9
Mounting the SMART Board....................................................................................... 12
Connecting the Pen Tray to the Computer and Power Source .................................. 14
Setting Up a SMART Board with Projection ............................................................... 18
Installing SMART Board Software ........................................................ 22
SMART Board Software ............................................................................................. 22
Windows System Requirements ................................................................................ 22
Macintosh System Requirements............................................................................... 22
Software Installation ................................................................................................... 23
Configuring and Orienting the SMART Board ..................................... 25
Configuring the SMART Board ................................................................................... 25
Orienting the Projected SMART Board....................................................................... 26
Customer Support ................................................................................. 29
Contacting SMART Technical Support....................................................................... 29
Other SMART Contacts.............................................................................................. 29
Warranty..................................................................................................................... 29
User Registration Card ............................................................................................... 30
Appendix A: Glossary of Technical Terms .......................................... 31
Index ....................................................................................................... 33
Contents
SMART Board Installation Guide 1
The SMART Board™
The SMART Board is an interactive, electronic whiteboard that can be
used with or without a projector. The three SMART Board models – the
340, the 360 and the 380 – can be mounted either on a floor stand or on
a wall. The SMART Board 340 can also be mounted on a table stand or
the partition wall of an office cubicle.
The SMART Board’s touch-sensitive screen enables you to do everything
you can do at a computer workstation −open files, conference with
others, create new or edit existing documents, play video clips, etc. −
simply by touching the Board. You can also write over applications in
electronic ink using a Pen Tray pen or your finger, and then save your
annotations to a computer file for future reference and distribution.
Supplied SMART Board Software
The SMART Board comes with two programs – the SMART Board driver
and SMART Notebook™ – collectively called SMART Board Software.
The SMART Board driver activates your SMART Board, allowing you to
use your finger as a mouse, annotate over an application with electronic
ink, and use Board-aware applications. SMART Notebook allows you to
create and organize notes on either a SMART Board or at your desktop,
and then save, print or e-mail those notes.
These programs are distributed with the SMART Board and are also
available free-of-charge from our Web site at www.smarttech.com.
The use of these programs is described in detail in the companion
manual to this installation guide, the SMART Board User’s Guide.
However, the procedure for installing the SMART Board Software is
described in the section of this guide entitled “Installing SMART Board
Software.”
2 SMART Board Installation Guide
About this Guide
A SMART Board can be mounted on a floor stand or on a wall; the
SMART Board 340 can also be mounted on a table stand. The specific
instructions for mounting a SMART Board on a floor stand are described
in the set of instructions provided with the floor stand.
This guide describes all the procedures for mounting a SMART Board on
a wall. It also provides instructions for other important procedures that
apply to both wall-mounted and floor stand-mounted SMART Boards.
These include SMART Pen Tray™ attachment, Pen Tray connection to
the computer and power source, SMART Board Software installation, and
projector set-up and alignment.
This manual is for both Windows®and Macintosh®users of the SMART
Board. Almost all of the procedures and descriptions in this manual apply
to either system. However, any information that applies solely to
Windows users is accompanied by a window icon in the margin, and
information relating only to Macintosh users is distinguished by a similarly
placed apple icon.
NOTE: Procedures common to both Windows and Macintosh are
described in terms of Windows conventions.
SMART Board Installation Guide 3
Installing the SMART Board
Installing a SMART Board involves the following series of simple
procedures:
•Attaching the Pen Tray to the whiteboard
•Finding and marking a suitable location
•Attaching the wall-mounting bracket to the wall
•Mounting the whiteboard
•Connecting the Pen Tray to the computer and power source
•Installing the SMART Board Software
•Configuring and orienting the SMART Board
Before You Begin: Unpacking and Checking
Components
Unpack the contents of the shipping container, checking each item
removed against the shipping check list. If any items are missing, contact
SMART Technical Support.
Each SMART Board includes the following components:
•whiteboard
•Pen Tray, including a set of four bullet-tip dry erase markers, four
styluses, and an eraser
•pair of Pen Tray brackets to attach the Pen Tray to the SMART
Board
•pair of brackets to mount the whiteboard on the wall (found on the
back of the whiteboard)
•MOD4, MOD6, and power supply cables
•Windows or Macintosh SMART Board Software (SMART
Notebook and SMART Board driver), located in a plastic
envelope.
If you are setting up a
SMART Board with
projection, “Setting
Up a SMART Board
with Projection” on
page 18 provides
special projector and
Board mounting
instructions.
4 SMART Board Installation Guide
Recommended Tools
While the following tools are not shipped with the SMART Board, we
recommend that you have them on hand to help you in the assembly and
mounting process.
•bubble level
•measuring tape
•masking tape
•a pencil
Attaching the Pen Tray to the Whiteboard
Hardware Required
•two Pen Tray mounting brackets
•Pen Tray
•Robertson screwdriver (supplied)
•MOD4 cable (the shorter, black cable with mini RJ11 4-wire
connectors at either end)
Activity Overview
To attach the Pen Tray to the whiteboard, you will:
1. Attach the Pen Tray brackets to the Pen Tray
2. Connect the MOD4 cable to the whiteboard
3. Attach the Pen Tray to the whiteboard
4. Connect the MOD4 cable to the Pen Tray
The series of steps involved in each of these activities is described in
detail below.
Step 1: Attach the Pen Tray brackets to the Pen Tray
1. Place the Pen Tray topside down on a flat surface.
2. Using the Robertson screwdriver supplied, remove all four
Robertson screws from the underside of the Pen Tray.
3. Lay the flat side of the brackets on the back of the Pen Tray.
Robertson Screwdriver
MOD4 cable with mini
RJ11 4-wire connector
SMART Board Installation Guide 5
4. Align the holes in the brackets with the holes in the underside of
the Pen Tray.
5. Insert the four screws you removed in step 2 into the holes in the
flat side of the brackets (two screws on each side). Tighten the
screws with the Robertson screwdriver just enough to hold the
Pen Tray securely. Do not overtighten these screws; the brackets
should be securely, but not rigidly, fixed.
Step 2: Connect the MOD4 cable to the whiteboard
1. Place the whiteboard on its side, with the mini RJ11 socket on
the underside of the whiteboard bezel (frame) facing toward you.
2. Grasp the mini RJ11 connector at one end of the MOD4 cable so
that the locking tab faces down and the contacts face up.
Warning
Do not overtighten the
Robertson screws
when attaching the
Pen Tray brackets to
the Pen Tray. The
brackets must be
sufficiently moveable
for a later attachment
step.
angular side of bracket
flat side of bracket underside of Pen Tray
bracket-to-Pen Tray
machine hole screws
Pen Tray and Mounting Brackets
Mini RJ11 Connector in Insertion Position
6 SMART Board Installation Guide
3. Insert the mini RJ11 connector into the mini RJ11 socket on the
underside of the whiteboard.
Step 3: Attach the Pen Tray to the whiteboard
1. Remove the two Robertson screws from the rear of the
whiteboard (located on the bottom edge).
2. Place the angled side of the Pen Tray bracket over each screw
hole, then replace the screws and fasten loosely.
NOTE: If the screws do not align correctly with the holes, loosen
the bracket screws on the underside of the Pen Tray, align the
holes, and then tighten the bracket screws again.
mini RJ11 socket, on
underside of whiteboard
bezel
mini RJ11 connector
Inserting the Mini RJ11 Connector into the Whiteboard
Otros manuales para Smart Board
13
Tabla de contenidos
Otros manuales de Pizarra interactiva de Smart Technologies
Smart Technologies
Smart Technologies Hub PE Manual de usuario
Smart Technologies
Smart Technologies SB680i2-SE240 Manual de usuario
Smart Technologies
Smart Technologies HAWM-600i2 Manual de usuario
Smart Technologies
Smart Technologies SMART Board X800 Series Manual de usuario
Smart Technologies
Smart Technologies SMART Board 600i5 Manual de usuario
Smart Technologies
Smart Technologies SMART Board 3000i Manual de usuario
Smart Technologies
Smart Technologies SMART Board 800i5e-SMP Manual de usuario
Smart Technologies
Smart Technologies SMART Board 8070ie-SMP Manual de usuario
Smart Technologies
Smart Technologies SMART Board 2000i-DVX Manual de usuario
Smart Technologies
Smart Technologies SMART Board 480iv Manual de usuario
Smart Technologies
Smart Technologies SMART Board 800i5-SMP Manual de usuario
Smart Technologies
Smart Technologies SMART Board 2000i-DVX Manual de usuario
Smart Technologies
Smart Technologies SMART Board 680i3 Manual de usuario
Smart Technologies
Smart Technologies SMART Board 600i5 Manual de usuario
Smart Technologies
Smart Technologies Smart Board Manual de usuario
Smart Technologies
Smart Technologies SMART Board 3000i Manual de usuario
Smart Technologies
Smart Technologies SMART Board 800ixe-SMP Manual de usuario
Smart Technologies
Smart Technologies Board 660 Manual de usuario
Smart Technologies
Smart Technologies Smart Board Instrucciones de operación
Smart Technologies
Smart Technologies SMART Board V280 Manual de usuario
